Using the Easy Mode

The easy mode is for spraying areas with defined boundaries, allowing you to select the jobs and display
the spraying area.
1. System-information icon
2. Guidance icon
3. Job-information icon
4. Sprayer-controller icon
Using the Easy Mode with a New
Job
1. Start the machine and keep the key in the
position.
2. Open the sprayer-controller icon
All manuals and user guides at all-guides.com
Figure 8
Easy-mode screen
5. Inventory-manager icon
6. Setup icon
7. Sprayer dashboard
8. Master-switch icon
RUN
(Figure 9).
9. Job-menu icon
10. Field-menu icon
11. Job-assistant icon
12. Zoom-function icon
1. Sprayer-controller icon
8
13. Screen-view icon
14. Center-map view
15. Boundary-selection icon
16. Boom-display icon
Figure 9
g030907
g031532
