Exporting Job Information - Toro GeoLink 41624 Operator's Manual

Figure 20
1. Job-notes icon

Exporting Job Information

Note:
Ensure a job is in session before exporting job
information.
1. Insert a USB storage device into the left side of
the console.
2. Select the the job-menu icon
3. Select the data-exchange icon
4. Confirm the job-report options listed below:
•
Auto adjust ranges—The colors used in
the report-map shading are altered so that
the maximum variation in colors is used to
illustrate the yield rates.
•
Create shape files—The
shape file data is exported to
D:/Client/Farm/Field/CoverageShapefiles
and
D:/Client/Farm/Field/BoundaryShapefiles.
•
Task data—Exporting a job report also
exports XML based task data into a folder
named TASKDATA.
Note:
This saves the job information to the
USB storage drive.
Note:
Before removing the USB storage
devise, always disconnect first by touching the
USB Eject button on the base of the console
(Figure 3). If you do not do this, you may create
a missing or corrupt report.
All manuals and user guides at all-guides.com
g031536
2. Job-information icon
(Figure 21).
(Figure 21).
1. Job-menu icon
2. Data-exchange icon
12
Figure 21
3. List of information to
change
g031537
