50-250W
MH/HPS/MERCURY
22 1/4" [565mm]
O R D E R I N G I N F O R M AT I O N
S A M P L E N U M B E R
: M P W 5 0 S R 2 5 5
PRODUCT
LAMP WATTAGE
50=50W
FAMILY
70=70W
MPW=Woodbridge
10=100W
15=150W
17=175W
25=250W
1
O P T I O N S + A C C E S S O R I E S
[ M u s t b e o r d e r e d i n a l p h a n u m e r i c o r d e r ]
OPTIONS (add as suffix)
1=Single Fuse (120, 277 or 347V)
2=Double Fused (208, 240 or 480V)
3=Three Place Terminal Block
4=Internal NEMA Photocontrol Receptacle
5=Top Mount NEMA Photocontrol Receptacle
WH=White
BK=Black
O P T I O N A L C O L O R S
[ S t a n d a r d c o l o r i s g r e y, o t h e r f i n i s h c o l o r s a v a i l a b l e . C o n s u l t y o u r C o o p e r L i g h t i n g r e p r e s e n t a t i v e ]
BK
WH
White
Black
P H O T O M E T R I C S
[ C o m p l e t e I E S f i l e s a v a i l a b l e a t w w w. c o o p e r l i g h t i n g . c o m ]
A
B
5
4
3
2
1
0
1
2
3
M P W 1 5 S 3 3 . I E S
150-Watt HPS
16,000-Lumen Lamp
Type III
NOTE: 1 Metal Halide only. 2 50W through 150W MH are medium-base socket. All others are mogul-base. 3 120 volt only. 4 50W through 150W HPS only. 5 Order OA1202 for field installation.
C o o p e r L i g h t i n g
21 1/2"
[546mm]
LAMP TYPE
BALLAST TYPE
M=Metal Halide
2
R=Reac./NPF
S=High Pressure Sodium
H=Reac./HPF
V=Mercury
N=Hi. Reac./NPF
P=Hi. Reac./HPF
W=CWA
K=10KV CWA
BZ=Bronze
B=House Side Shield
5
P=Polycarbonate Refractor
S=Scrolls
U=U.L./CSA Listed
G=Glass Refractor
BZ
Bronze
5
4
3
2
1
C
0
D
1
2
3
4
5
5
4
3
2
1
0
1
4
5
M P W 1 5 S 5 5 . I E S
150-Watt HPS
16,000-Lumen Lamp
Type V
MPW
VOLTAGE
2=120V
3
3
0=208V
4=240V
7=277V
8=480V
9=347V
4
N=Multi-Tap wired 277V
W=Multi-Tap wired 120V
P=240/120 PCR
ACCESSORIES (order separately)
OA1202=House Side Shield
5
F O O T C A N D L E TA B L E
Select mounting height and read across for footcandle
4
values of each isofootcandle line. Distance in units of
3
mounting height.
2
Mounting
Height
1
A
B
C
0
MPW15S33.IES
12'
1
15'
2
18'
3
MPW15S55.IES
12'
4
15'
5
18'
2
3
4
5
S T R E E T W O R K S O u t d o o r L i g h t i n g S o l u t i o n s
WOODBRIDGE
P O S T- T O P A R E A L U M I N A I R E
DISTRIBUTION
OPTIONS +
22=Type II
ACCESSORIES
33=Type III
(See Below)
55=Type V
Footcandle Values for
Isofootcandle Lines
A
B
C
D
1.56
0.78
0.31
0.16
1.00
0.50
0.20
0.10
0.69
0.35
0.13
0.07
0.78
0.31
0.15
0.50
0.20
0.10
0.34
0.13
0.06
D E C O R AT I V E
STREETWORKS
™
H O U S I N G + T O P
Die-cast aluminum housing with
spun and stamped aluminum top.
Over-center latch for relamping
and ballast power module access.
Top is completely removable
without the use of tools. Standard
color is grey. Other finish colors
available. Consult your
Streetworks Representative.
1" ANSI wattage/source label.
R E F R A C T O R
Injection molded acrylic refractors
available in Type II, III or V
distributions. Optional glass
refractor available.
S O C K E T
Mogul-base socket for 50W
through 150W HPS and 175W and
250W MH; 50W through 150W
MH is medium-base socket.
All sockets are 4KV pulse rated.
B A L L A S T
Power module designed for
easy removal of all electrical
components for servicing by
loosening two screws.
Encapsulated plug-in
starter may be replaced through
top access. Two-position tunnel
type compression terminal block
with housing grounding screw.
Removable tethered door
assembly for easy access to
wiring connections with stainless
steel captive screw.
P H O T O C O N T R O L
Optional internal NEMA twistlock
photocontrol available. Accessible
through door assembly.
M O U N T I N G
Post top mount fits 3" O.D.
tenons. Secured by square head
3/8" stainless steel mounting
bolts.
E P A :
Effective Projective Area:
1.7
S H I P P I N G D ATA
Approximate Net Weight:
34 lbs. (14 kgs.)
75
