Cooper Lighting Lumiere Maui 1503 Specification Sheet

`
LUMIERE
MAUI 1503
18W (max) S8 Incandescent
50W (max) T4 Halogen
Low Voltage (12V)
5W (max)
Compact Fluorescent
Line Voltage
FEATURES
• 12V source includes mounting spike
• Die-cast & machined aluminum
• UL / cUL listed
• Three (3) year warranty
MAUI 1507
18W (max) S8 Incandescent
20W (max) T4 Halogen
Low Voltage (12V)
FEATURES
• Includes cast zinc mounting spike
• Die-cast & machined aluminum
• Stainless steel hardware
• UL / cUL listed
• Three (3) year warranty
• Includes cast zinc mounting spike
MAUI 1510
18W (max) S8 Incandescent
35W (max) T4 Halogen
Low Voltage (12V)
FEATURES
• Includes cast zinc mounting spike
• Adjustable fixture head pivots 90°
• Die-cast & machined aluminum
• Stainless steel hardware
• UL / cUL listed
• Three (3) year warranty
1044
COOPER LIGHTING
®
MODEL
1503 Solid housing with 1/2" NPS post
MODEL
1507 Stationary housing with 1/2"
NPS post
MODEL
1510 Adjustable housing with 1/2"
NPS post
Note: See "Accessories" section for Low Voltage Cable & Transformers, Mounting Accessories and Lamps.
SOURCE VOLTS
Incandescent / Halogen
INC18 18W / S8 / D.C. bayonet 12
50T4 50W / T4 / G6.35
12V remote transformer required - not included
Lamp included
Compact Fluorescent
CF5 5W / twin tube / G23 120
Lamp included
SOURCE VOLTS
Incandescent / Halogen
INC18 18W / S8 / D.C. bayonet 12
20T4 20W / T4 / G6.35
12V remote transformer required - not included
Lamp included
SOURCE VOLTS
Incandescent / Halogen
INC18 18W / S8 / D.C. bayonet 12
35T4 35W / T4 / GY6.35
12V remote transformer required - not included
Lamp included
SAMPLE NUMBER: 1503-INC18-12-BK
FINISH
Painted
BK Black
BZ Bronze
CS City silver
VE Verde
WT White
SAMPLE NUMBER: 1507-INC18-12-BK
FINISH
Painted
BK Black
BZ Bronze
CS City silver
VE Verde
WT White
SAMPLE NUMBER: 1510-INC18-12-BK
FINISH OPTIONS
Painted
BK Black MS 3-1/2" mini
BZ Bronze post in lieu of
CS City silver standard 20"
VE Verde
WT White
