Page 1 Network Video Recorder User Manual UD04701B...
Page 2 (hereinafter referred to be “the Manual”) cannot be reproduced, changed, translated, or distributed, partially or wholly, by any means, without the prior written permission of Hikvision. Unless otherwise stipulated, Hikvision does not make any warranties, guarantees or representations, express or implied, regarding to the Manual.
Page 3 Network Video Recorder User Manual Regulatory Information FCC Information Please take attention that changes or modification not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. FCC compliance: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules.
Page 4 Network Video Recorder User Manual Safety Instructions • Proper configuration of all passwords and other security settings is the responsibility of the installer and/or end-user. • In the use of the product, you must be in strict compliance with the electrical safety regulations of the nation and region.
Page 5 Network Video Recorder User Manual Applicable Models This manual is applicable to the models listed in the following table. Series Models DS-7604NI-E1, DS-7608NI-E1, DS-7616NI-E1 DS-7604NI-E1/4P DS-7604NI-E1/4N DS-7600NI-E1/E2 series DS-7608NI-E2, DS-7616NI-E2, DS-7632NI-E2 DS-7608NI-E2/8P, DS-7616NI-E2/8P, DS-7616NI-E2/16P, DS-7632NI-E2/8P DS-7608NI-E2/8N, DS-7616NI-E2/8N, DS-7632NI-E2/8N DS-7708NI-E4, DS-7716NI-E4, DS-7732NI-E4 DS-7700NI-E4 series DS-7708NI-E4/8P, DS-7716NI-E4/16P, DS-7732NI-E4/16P DS-8600NI-E8 series...
Page 6: Product Key Features
Network Video Recorder User Manual Product Key Features General  Connectable to network cameras, network dome and encoders.  Connectable to the third-party network cameras like ACTI, Arecont, AXIS, Bosch, Brickcom, Canon, PANASONIC, Pelco, SAMSUNG, SANYO, SONY, Vivotek and ZAVIO, and cameras that adopt ONVIF or PSIA protocol.
Page 7 Network Video Recorder User Manual  Holiday recording schedule configuration.  Continuous and event video recording parameters.  Multiple recording types: manual, continuous, alarm, motion, motion | alarm, motion & alarm, and VCA.  8 recording time periods with separated recording types each day. ...
Page 8 Network Video Recorder User Manual  The dual-NIC network 10 /100/1000 Mbps self-adaptive Ethernet interfaces are provided for the DS-8600NI-E8 and DS-7700NI-E4 series NVR; one 10 /100 Mbps self-adaptive Ethernet interface for DS-7604/7608NI-E1(E2) series NVR; and one 10 /100/1000 Mbps self-adaptive Ethernet interface for other models.
Page 9: Table Of Contents
Network Video Recorder User Manual TABLE OF CONTENTS Product Key Features ..........................5 Chapter 1 Introduction ........................13 Front Panel ............................ 14 DS-8600NI-E8 Series........................14 DS-7700NI-E4 Series........................16 DS-7600NI-E1(E2) Series ....................... 18 IR Remote Control Operations ...................... 19 USB Mouse Operation ........................22 Input Method Description ......................
Page 10 Network Video Recorder User Manual 4.2.6 Calling Patterns ......................... 66 4.2.7 Customizing Linear Scan Limit ..................67 4.2.8 Calling Linear Scan ......................68 4.2.9 One-touch Park ......................... 68 PTZ Control Panel ......................... 70 Chapter 5 Recording Settings......................71 Configuring Parameters ......................... 72 Configuring Recording Schedule ....................
Page 11 Network Video Recorder User Manual Detecting Video Loss Alarm ......................123 Detecting Video Tampering Alarm ....................125 Handling Exceptions Alarm ......................127 Setting Alarm Response Actions ....................128 Triggering or Clearing Alarm Output Manually ................131 Chapter 9 VCA Alarm ........................132 Face Detection ..........................
Page 12 Network Video Recorder User Manual 12.2 Managing Network HDD ......................178 12.3 Managing HDD Group ........................ 181 12.3.1 Setting HDD Groups ....................... 181 12.3.2 Setting HDD Property ..................... 182 12.4 Configuring Quota Mode......................184 12.5 Checking HDD Status ......................... 185 12.6 HDD Detection ..........................
Page 13 Network Video Recorder User Manual 16.5 List of Compatible IP Cameras ....................236 16.5.1 List of Hikvision IP Cameras ..................236 16.5.2 List of Third-party IP Cameras ..................243...
Page 14: Chapter 1 Introduction
Network Video Recorder User Manual Chapter 1 Introduction...
Page 15: Front Panel
Network Video Recorder User Manual 1.1 Front Panel DS-8600NI-E8 Series Figure 1. 1 DS-8600NI-E8 Series Table 1. 1 Description of Control Panel Buttons Name Function Description ALARM Turns red when a sensor alarm is detected. READY Turs blue when the device is functioning properly. Turns blue when device is controlled by an IR remote.
Page 16 Network Video Recorder User Manual Name Function Description Automatically scans in the PTZ control menu. ZOOM+ Zooms in the PTZ camera in the PTZ control setting. Adjusts focus in the PTZ Control menu. A/FOCUS+ Switches between input methods (upper and lower case alphabet, symbols and numeric input).
Page 17: Ds-7700Ni-E4 Series
Network Video Recorder User Manual DS-7700NI-E4 Series Figure 1. 2 DS-7700NI-E4 Series Table 1. 2 Description of Control Panel Buttons Name Function Description POWER Turns green when NVR is powered up. READY Turns green when the device is running normally. Turns green when the IR remote control is enabled;...
Page 18 Network Video Recorder User Manual Name Function Description In PTZ Control mode, turns on/off PTZ light and when the image is zoomed in, use it to zoom out. Enters numeral “3”; Enters letters “DEF”; 3/DEF/F2 Uses the F2 button to change the tab pages. Zooms in the image in PTZ control mode.
Page 19: Ds-7600Ni-E1(E2) Series
Network Video Recorder User Manual DS-7600NI-E1(E2) Series Figure 1. 3 DS-7600NI-E1(E2) Series Table 1. 3 Description of Control Panel Buttons Name Description Power Turns green when system is running. Status Status Flickers red when data is being read from or written to HDD. Indicator Tx/Rx Flickers green when network connection is functioning properly.
Page 20: Ir Remote Control Operations
IR Remote to a specific NVR by changing the Device ID#, as follows: Pairing (Enabling) the IR Remote to a Specific DVR (optional) You can pair an IR Remote to a specific Hikvision DVR by creating a user-defined Device ID#. This feature is useful when using multiple IR Remotes and DVRs.
Page 21 Network Video Recorder User Manual - Unpairing (Disabling) an IR Remote from a DVR To unpair an IR Remote from a DVR so that the unit cannot control any DVR functions, proceed as follows: Press the DEV key on the IR Remote. Any existing Device ID# will be erased from the unit’s memory and it will no longer function with the DVR.
Page 22 Network Video Recorder User Manual INFO Reserved Switches between main and spot output VOIP Zooms out the image in PTZ control mode Return to Main menu (after successful login) MENU Show/hide full screen in Playback mode Navigate between fields and menu items Use Up/Down buttons to speed up/slow down recorded video, and Left/Right DIRECTION buttons to advance/rewind 30 secs in Playback mode...
Page 23: Usb Mouse Operation
Network Video Recorder User Manual 1.2 USB Mouse Operation A regular 3-button (Left/Right/Scroll-wheel) USB mouse can also be used with this NVR. To use a USB mouse: Plug USB mouse into one of the USB interfaces on the front panel of the NVR. 2.
Page 24: Input Method Description
Network Video Recorder User Manual 1.3 Input Method Description Refer to the following figures for the soft keyboard: Figure 1. 1 Soft Keyboard (1) Figure 1. 2 Soft Keyboard (2) Figure 1. 3 Soft Keyboard (3) Description of the buttons on the soft keyboard: Table 1.
Page 25: Rear Panel
Network Video Recorder User Manual 1.4 Rear Panel The rear panel vaires according to different models. DS-8600NI-E8, DS-7700NI-E4 and DS-7700NI-E4/P Series Figure 1. 5 DS-8600NI-E8 and DS-7700NI-E4 Series Figure 1. 6 DS-7700NI-E4/P Series Table 1. 7 Description of Rear Panel Interfaces Item Description LAN Interface...
Page 26: Ds-7600Ni-E1, Ds-7600Ni-E1/4N, Ds-7600Ni-E2 And Ds-7600Ni-E2/8N Series
Network Video Recorder User Manual DS-7600NI-E1, DS-7600NI-E1/4N, DS-7600NI-E2 and DS-7600NI-E2/8N Series Figure 1. 7 DS-7600NI-E1/E2 Series Figure 1. 8 DS-7600NI-E1/4N Series Figure 1. 9 DS-7600NI-E2/8N Series Table 1. 8 Description of Rear Panel Interfaces Item Description Power Supply DC 12V power supply. Audio In RCA connector for audio input.
Page 27 Network Video Recorder User Manual Figure 1. 11 DS-7600NI-E2/8P Series Table 1. 9 Description of Rear Panel Interfaces Item Description Power Supply 48 VDC power supply for DS-7600NI-E1/4P and 100~240 VAC for DS-7600NI-E2/8P. Audio In RCA connector for audio input. HDMI Interface HDMI...
Page 28: Chapter 2 Getting Started
Network Video Recorder User Manual Chapter 2 Getting Started...
Page 29: Device Startup And Activation
Network Video Recorder User Manual 2.1 Device Startup and Activation 2.1.1 Starting Up and Shutting Down the NVR Purpose: Proper startup and shutdown procedures are crucial to expanding the life of the NVR. Before you start: Check that the voltage of the extra power supply is the same with the NVR’s requirement, and the ground connection is working properly.
Page 30 Network Video Recorder User Manual Figure 2. 2 Shutdown Attention  OPTION 2: By operating the front panel (supported by DS-8600NI-E8 and DS-7700NI-E4(/P) series) Steps: Press and hold the button on the front panel for 3 seconds. Enter the administrator’s username and password in the dialog box for authentication if required. Click the Yes button.
Page 31: Activating Your Device
Network Video Recorder User Manual 2.1.2 Activating Your Device Purpose: For the first-time access, you need to activate the device by setting an admin password. No operation is allowed before activation. Steps: 1. Input the same password in the text field of Create New Password and Confirm New Password. Figure 2.
Page 32: Using The Unlock Pattern For Login
Network Video Recorder User Manual Figure 2. 5 Export GUIDE File Please keep your GUID file properly for future password resetting. 5. When the device is activated, the system pops up the message box to remind you to remember the password. For the old version device, if you update it to the new version, the following dialog box will pop up once the device starts up.
Page 33 Network Video Recorder User Manual Figure 2. 7 Set Unlock Pattern Steps: Use the mouse to draw a pattern among the 9 dots on the screen. Release the mouse when the pattern is done. Figure 2. 8 Draw the Pattern Connect at least 4 dots to draw the pattern.
Page 34 Network Video Recorder User Manual Figure 2. 9 Confirm the Pattern If the two patterns are different, you must set the pattern again. Figure 2. 10 Re-set the Pattern Logging in via Unlock Pattern Only the admin user has the permission to unlock the device. ...
Page 35: Login And Logout
Network Video Recorder User Manual Figure 2. 11 Draw the Unlock Pattern Draw the pre-defined pattern to unlock to enter the menu operation. If you have forgotten your pattern, you can select the Forget My Pattern or Switch User option to enter the ...
Page 36 Network Video Recorder User Manual Figure 2. 13 Login Interface Input password. Click OK to log in. When you forget the password of the admin, you can click Forget Password to reset the password. Please refer to Chapter 2.1.5Resetting Your Password for details. The device gets locked for 60 seconds if the admin user performs 7 failed password attempts (5 attempts for the guest/operator).
Page 37: Resetting Your Password
Network Video Recorder User Manual 2.1.5 Resetting Your Password When you forget the password of the admin, you can reset the password by importing the GUID file. The GUID file must be exported and saved in the local U-flash disk after you have activated the device (refer to Chapter 2.1.2Activating Your Device).
Page 38 Network Video Recorder User Manual of the NVR. Figure 2. 16 Start Wizard Interface Steps: 1. If you don’t want to use the setup wizard at that moment, click the Exit button. You can also choose to use the Setup Wizard next time by leaving the “Start wizard when the device starts?” checkbox checked. Click the Next button to enter the Date and Time Settings interface.
Page 39 Network Video Recorder User Manual Figure 2. 18 Network Settings  The dual-NIC network 10 /100/1000 Mbps self-adaptive Ethernet interfaces are provided for the DS-8600NI-E8 and DS-7700NI-E4 series NVR;one 10 /100 Mbps self-adaptive Ethernet interface for DS-7604/7608NI-E1(E2) series NVR; and one 10 /100/1000 Mbps self-adaptive Ethernet interface for other models.
Page 40 Network Video Recorder User Manual Figure 2. 20 Advanced Network Parameters 6. After configuration finishes, click Next button to enter HDD Management interface. Figure 2. 21 HDD Management 7. To initialize the HDD, click the Init button. Initialization removes all the data saved in the HDD. 8.
Page 41 Network Video Recorder User Manual Figure 2. 22 IP Camera Management 10. Click Next button. Configure the recording for the searched IP Cameras. Figure 2. 23 Record Settings 11. Click OK to complete the startup Setup Wizard.
Page 42: Adding And Connecting The Ip Cameras
Network Video Recorder User Manual 2.3 Adding and Connecting the IP Cameras 2.3.1 Activating the IP Camera Purpose: Before adding the camera, make sure the IP camera to be added is in active status. Steps: 1. Select the Add IP Camera option from the right-click menu in live view mode or click Menu> Camera> Camera to enter the IP camera management interface.
Page 43: Adding The Online Ip Cameras
Network Video Recorder User Manual admin password of the operating NVR. Figure 2. 26 Set New Password Create New Password: If the admin password is not used, you must create the new password for the camera and confirm it. STRONG PASSWORD RECOMMENDED–We highly recommend you create a strong password of your own choosing (Using a minimum of 8 characters, including at least three of the following categories: upper case letters, lower case letters, numbers, and special characters.) in order to increase the security of your product.
Page 44 Network Video Recorder User Manual 3. Select the detected IP camera and click the Add button to add it directly, and you can click the Search button to refresh the online IP camera manually. Figure 2. 28 Quick Adding IP Camera Interface Or you can choose to custom add the IP camera by editing the parameters in the corresponding textfiled and then click the Add button to add it.
Page 45 Network Video Recorder User Manual Make sure the camera to add has already been activated. (For the encoders with multiple channels only) check the Channel Port in the pop-up window, as checkbox shown in the following figure, and click OK to add multiple channels. Figure 2.
Page 46 Network Video Recorder User Manual Icon Explanation Icon Explanation Edit basic parameters of the camera Add the detected IP camera. The camera is disconnected; you can click the icon to get the exception Delete the IP camera information of camera. Play the live video of the connected Advanced settings of the camera.
Page 47: Editing The Connected Ip Cameras And Configuring Customized Protocols
Network Video Recorder User Manual 2.3.3 Editing the Connected IP Cameras and Configuring Customized Protocols After the adding of the IP cameras, the basic information of the camera lists in the page, you can configure the basic setting of the IP cameras. Steps: 1.
Page 48 Network Video Recorder User Manual Figure 2. 36 Password Configuration of the Camera 3. Click OK to save the settings and exit the interface. Configuring the customized protocols Purpose: To connect the network cameras which are not configured with the standard protocols, you can configure the customized protocols for them.
Page 49: Editing Ip Cameras Connected To The Poe Interfaces
Network Video Recorder User Manual Example: rtsp://192.168.1.55:554/ch1/main/av_stream.  Protocol Name: Edit the name for the custom protocol.  Enable Substream: If the network camera does not support sub-stream or the sub-stream is not needed leave the checkbox empty.  Type: The network camera adopting custom protocol must support getting stream through standard RTSP. ...
Page 50 Network Video Recorder User Manual Menu> Camera> Camera Figure 2. 39 List of Connected Cameras The cameras connecting to the PoE interface cannot be deleted in this menu. 2. Click the button, and select the Adding Method in the drop-down list. •...
Page 51 Network Video Recorder User Manual Figure 2. 41 Edit IP Camera Interface - Manual...
Page 52: Chapter 3 Live View
Network Video Recorder User Manual Chapter 3 Live View...
Page 53: Introduction Of Live View
Network Video Recorder User Manual 3.1 Introduction of Live View Live view shows you the video image getting from each camera in real time. The NVR automatically enters Live View mode when powered on. It is also at the very top of the menu hierarchy, thus pressing the ESC many times (depending on which menu you’re on) brings you to the Live View mode.
Page 54: Operations In Live View Mode
Network Video Recorder User Manual 3.2 Operations in Live View Mode In live view mode, there are many functions provided. The functions are listed below. • Single Screen: showing only one screen on the monitor. • Multi-screen: showing multiple screens on the monitor simultaneously. •...
Page 55: Quick Setting Toolbar In Live View Mode
Network Video Recorder User Manual Name Description Switch to the single full screen by choosing channel number from the dropdown Single Screen list. Adjust the screen layout by choosing from the dropdown list. Multi-screen Previous Screen Switch to the previous screen. Switch to the next screen.
Page 56 Network Video Recorder User Manual Figure 3. 2 Quick Setting Toolbar Table 3. 4 Description of Quick Setting Toolbar Icons Icon Description Icon Description Icon Description Enable/Disable Instant Playback Mute/Audio on Manual Record PTZ Control Digital Zoom Image Settings Live View Face Detection Information Strategy...
Page 57: Adjusting Live View Settings
Network Video Recorder User Manual Figure 3. 4 Image Settings- Customize Live View Strategy can be selected to set strategy, including Real-time, Balanced, Fluency. Figure 3. 5 Live View Strategy Move the mouse onto the icon to show the real-time stream information, including the frame rate, bitrate, resolution and stream type.
Page 58 Network Video Recorder User Manual time for screen to be shown, mute or turning on the audio, the screen number for each channel, etc. Steps: Enter the Live View Settings interface. Menu > Configuration > Live View Figure 3. 7 Live View-General The settings available in this menu include: •...
Page 59: Channel-Zero Encoding
Network Video Recorder User Manual Select the small window, and double-click on the channel number to display the channel on the window. If you do not want the camera to be displayed on the live view interface, click the corresponding to stop it.
Page 60 Network Video Recorder User Manual...
Page 61: Chapter 4 Ptz Controls
Network Video Recorder User Manual Chapter 4 PTZ Controls...
Page 62: Configuring Ptz Settings
Network Video Recorder User Manual 4.1 Configuring PTZ Settings Purpose: Follow the procedure to set the parameters for PTZ. The configuring of the PTZ parameters should be done before you control the PTZ camera. Steps: Enter the PTZ Settings interface. Menu >...
Page 63 Network Video Recorder User Manual All the parameters should be exactly the same as the PTZ camera parameters. Click Apply button to save the settings.
Page 64: Setting Ptz Presets, Patrols & Patterns
Network Video Recorder User Manual 4.2 Setting PTZ Presets, Patrols & Patterns Before you start: Please make sure that the presets, patrols and patterns should be supported by PTZ protocols. 4.2.1 Customizing Presets Purpose: Follow the steps to set the Preset location which you want the PTZ camera to point to when an event takes place. Steps: Enter the PTZ Control interface.
Page 65: Customizing Patrols
Network Video Recorder User Manual 1. Click the button PTZ in the lower-right corner of the PTZ setting interface; Or press the PTZ button on the front panel or click the PTZ Control icon in the quick setting bar, or select the PTZ option in the right-click menu to show the PTZ control panel.
Page 66: Calling Patrols
Network Video Recorder User Manual Click the Set button to add key points for the patrol. Figure 4. 6 Key point Configuration 4. Configure key point parameters, such as the key point No., duration of staying for one key point and speed of patrol.
Page 67: Customizing Patterns
Network Video Recorder User Manual 4.2.5 Customizing Patterns Purpose: Patterns can be set by recording the movement of the PTZ. You can call the pattern to make the PTZ movement according to the predefined path. Steps: Enter the PTZ Control interface. Menu >...
Page 68: Customizing Linear Scan Limit
Network Video Recorder User Manual Figure 4. 9 PTZ Panel - General Click the Call Pattern button to call it. Click the Stop Pattern button to stop calling it. 4.2.7 Customizing Linear Scan Limit Purpose: The Linear Scan can be enabled to trigger the scan in the horizantal direction in the predefined range. This function is supported by some certain models.
Page 69: Calling Linear Scan
180º. 4.2.8 Calling Linear Scan Before operating this function, make sure the connected camera supports the linear scan and is in HIKVISION protocol. Purpose: Follow the procedure to call the linear scan in the predefined scan range.
Page 70 Network Video Recorder User Manual Or press the PTZ button on the front panel or click the PTZ Control icon in the quick setting bar to enter the PTZ setting menu in live view mode. Click the button to show the one-touch function of the PTZ control. Figure 4.
Page 71: Ptz Control Panel
Network Video Recorder User Manual 4.3 PTZ Control Panel To enter the PTZ control panel, there are two ways supported. OPTION 1: In the PTZ settings interface, click the PTZ button on the lower-right corner which is next to the Back button. OPTION 2: In the Live View mode, you can press the PTZ Control button on the front panel or on the remote control, or choose the PTZ Control icon...
Page 72: Chapter 5 Recording Settings
Network Video Recorder User Manual Chapter 5 Recording Settings...
Page 73: Configuring Parameters
Network Video Recorder User Manual 5.1 Configuring Parameters Purpose: By configuring the parameters you can define the parameters which affect the image quality, such as the transmission stream type, the resolution and so on. Before you start: 1. Make sure that the HDD has already been installed. If not, please install a HDD and initialize it. (Menu > HDD >...
Page 74 Network Video Recorder User Manual Parameters Setting for Recording 1) Select Record tab page to configure. You can configure the stream type, the resolution, and other parameters on your demand. Enable H.264+ Mode: check the checkbox to enable. Once enabled, the Max. Bitrate Mode, ...
Page 75 Network Video Recorder User Manual  The redundant record is to decide whether you want the camera to save the recording files in the redundant HDD. You must configure the redundant HDD in HDD settings. For detailed information, see Chapter12.3.2 Setting HDD Property. ...
Page 76: Configuring Recording Schedule
Network Video Recorder User Manual 5.2 Configuring Recording Schedule Purpose: Set the recording schedule, and then the camera automatically starts/stops recording according to the configured schedule. Steps: Enter the Record Schedule interface. Menu > Record > Schedule Configure Record Schedule Select Record Schedule.
Page 77 Network Video Recorder User Manual Figure 5. 7 Recording Schedule Interface You can click the button to set the accurate time of the schedule. II. To schedule an all-day recording, check the checkbox after the All Day item. Figure 5. 8 Edit Schedule III.
Page 78 Network Video Recorder User Manual Figure 5. 9 Draw the Schedule Click the Apply button to validate the settings. 3. (Optional) If the settings can also be used to other channels, click Copy, and then choose the channel to which you want to copy. 4.
Page 79: Configuring Motion Detection Recording
Network Video Recorder User Manual 5.3 Configuring Motion Detection Recording Purpose: Follow the steps to set the motion detection parameters. In the live view mode, once a motion detection event takes place, the NVR can analyze it and do many actions to handle it. Enabling motion detection function can trigger certain channels to start recording, or trigger full screen monitoring, audio warning, notify the surveillance center and so on.
Page 80 Network Video Recorder User Manual 4) Click Settings, and the message box for channel information pop up. Figure 5. 12 Motion Detection Handling 5) Select the channels which you want the motion detection event to trigger recording. 6) Click Apply to save the settings. 7) Click OK to back to the upper level menu.
Page 81: Configuring Alarm Triggered Recording
Network Video Recorder User Manual 5.4 Configuring Alarm Triggered Recording Purpose: Follow the procedure to configure alarm triggered recording. Steps: 1. Enter the Alarm setting interface. Menu > Configuration > Alarm Figure 5. 13 Alarm Settings 2. Click Alarm Input tab and set the alarm parameters. Figure 5.
Page 82 Network Video Recorder User Manual Figure 5. 15 Alarm Settings Choose the alarm triggered recording channel. Check the checkbox to select channel. Click Apply to save settings. Click OK to back to the upper level menu. Repeat the above steps to configure other alarm input parameters. If the settings can also be applied to other alarm inputs, click Copy and choose the alarm input number.
Page 83: Configuring Vca Event Recording
Network Video Recorder User Manual 5.5 Configuring VCA Event Recording Purpose: The event triggered recording can be configured through the menu. Then events include the motion detection, alarm and VCA events (face detection/face capture, line crossing detection, intrusion detection, region entrance detection, region exiting detection, loitering detection, people gathering detection, fast moving detection, parking detection, unattended baggage detection, object removal detection, audio loss exception detection, sudden change of sound intensity detection, and defocus detection).
Page 84: Manual Recording
Network Video Recorder User Manual Figure 5. 18 Set Trigger Camera of VCA Alarm The PTZ Linking function is only available for the VCA settings of IP cameras. 4. Enter Record Schedule settings interface (Menu > Record > Schedule > Record Schedule), and then set VCA as the record type.
Page 85: Configuring Holiday Recording
Network Video Recorder User Manual 5.7 Configuring Holiday Recording Purpose: Follow the steps to configure the record schedule on holiday for that year. You may want to have different plan for recording on holiday. Steps: 1. Enter the Record setting interface. Menu >...
Page 86: Configuring Redundant Recording
Network Video Recorder User Manual 5.8 Configuring Redundant Recording Purpose: Enabling redundant recording, which means saving the recording files not only in the R/W HDD but also in the redundant HDD, will effectively enhance the data safety and reliability. . Steps: Enter HDD Information interface.
Page 87 Network Video Recorder User Manual Figure 5. 24 Record Parameters Check the checkbox of Redundant Record. Click OK to save settings and back to the upper level menu. Repeat the above steps for configuring other channels.
Page 88: Configuring Hdd Group For Recording
Network Video Recorder User Manual 5.9 Configuring HDD Group for Recording Purpose: You can group the HDDs and save the record files in certain HDD group. Steps: 1. Enter HDD setting interface. Menu > HDD Figure 5. 25 HDD General 2.
Page 89: Files Protection
Network Video Recorder User Manual 5.10 Files Protection Purpose: You can lock the recording files or set the HDD property to Read-only to protect the record files from being overwritten. 5.10.1 Locking the Recording Files Lock File when Playback Steps: 1.
Page 90 Network Video Recorder User Manual Figure 5. 28 Locked File Management In the File Management interface, you can also click to change it to to unlock the file and the file is not protected.  Lock File when Export Steps: 1.
Page 91: Setting Hdd Property To Read-Only
Network Video Recorder User Manual Figure 5. 30 Export- Search Result 5. Protect the record files. 1) Find the record files you want to protect, and then click the icon which will turn to , indicating that the file is locked. The record files of which the recording is still not completed cannot be locked.
Page 92 Network Video Recorder User Manual Figure 5. 33 HDD General- Editing To edit HDD property, you need to set the storage mode of the HDD to Group. See Chapter 12.3 Managing HDD Group. 3. Set the HDD property to Read-only. 4.
Page 93: Chapter 6 Playback
Network Video Recorder User Manual Chapter 6 Playback...
Page 94: Playing Back Record Files
Network Video Recorder User Manual 6.1 Playing Back Record Files 6.1.1 Instant Playback Purpose: Play back the recorded video files of a specific channel in the live view mode. Channel switch is supported. Instant playback by channel Step: Choose a channel in live view mode and click the button in the quick setting toolbar.
Page 95 Network Video Recorder User Manual Figure 6. 2 Right-click Menu under Live View Pressing numerical buttons will switch playback to the corresponding channels during playback process. Playback by Time Purpose: Play back video files recorded in specified time duration. Multi-channel simultaneous playback and channel switch are supported.
Page 96 Network Video Recorder User Manual If there are record files for that camera in that day, in the calendar, the icon for that day is displayed in different colors for different recording types: blue for continuous recording and red for event recording. Click the radio button to start playing the continuous recorded files.
Page 97: Playing Back By Smart Search
Network Video Recorder User Manual intrusion detection the target characters Operations Audio on/Mute Start/Stop clipping Digital Zoom Lock File Add default tag Add customized tag File management for video clips, captured pictures, locked files and tags Playing Pause/Play Reverse play/ Pause Control Slow forward Stop...
Page 98 Network Video Recorder User Manual Figure 6. 6 Playback by Smart Search 5. Click the radio button to switch to the playback by smart search. 6. Set the rules and areas for smart search of line crossing detection, intrusion detection or motion detection event triggered recording.
Page 99: Playing Back By Event Search
Network Video Recorder User Manual Figure 6. 7 Set Result Filter 6.1.4 Playing Back by Event Search Purpose: Play back record files on one or several channels searched out by event type (e.g., alarm input, motion detection and VCA). Steps: Enter the Playback interface.
Page 100: Playing Back By Tag
Network Video Recorder User Manual For configuring the VCA recording, please refer to Chapter 5.5 Configuring VCA Event Recording and Capture; and for details of VCA detection types, please refer to Chapter 9 VCA Alarm. Select the camera (s) for searching, and set the Start time and End time. Click Search button to get the search result information.
Page 101 Network Video Recorder User Manual You can use video tag(s) to search for record files and position time point. Before playing back by tag: 1. Enter Playback interface. Menu>Playback 2. Search and play back the record file(s). Refer to Chapter 6.1.1 for the detailed information about searching and playback of the record files.
Page 102 Network Video Recorder User Manual Playing back by Tag Steps: Select the Tag from the drop-down list in the Playback interface. Choose channels, edit start time and end time, and then click Search to enter Search Result interface. Figure 6. 13 Interface of Playback by Tag You can enter keyword in the textbox to search the tag on your command.
Page 103: Playing Back By System Logs
Network Video Recorder User Manual buttons on the toolbar. 6.1.6 Playing Back by System Logs Purpose: Play back record file(s) associated with channels after searching system logs. Steps: Enter Log Information interface. Menu>Maintenance>Log Information Click Log Search tab to enter Playback by System Logs. Set search time and type and click Search button.
Page 104: Playing Back External File
Network Video Recorder User Manual Figure 6. 16 Result of System Log Search Playback interface. The toolbar in the bottom part of Playback interface can be used to control playing process. Figure 6. 17 Interface of Playback by Log 6.1.7 Playing Back External File Purpose: Perform the following steps to look up and play back files in the external devices.
Page 105: Playing Back By Sub-Periods
Network Video Recorder User Manual Figure 6. 18 Interface of External File Playback 6.1.8 Playing Back by Sub-periods The DS-8600NI-E8, DS-7700/E4, DS-7600-E1(E2) series NVR supports playback by sub-periods. Purpose: The video files can be played in multiple sub-periods simultaneously on the screens. Steps: Enter Playback interface.
Page 106: Auxiliary Functions Of Playback
Network Video Recorder User Manual 07-05-2016 Tue 00:28:32 07-05-2016 Tue 08:07:37 07-05-2016 Tue 08:07:37 07-05-2016 Tue 12:11:04 Figure 6. 19 Interface of Sub-periods Playback According to the defined number of split-screens, the video files on the selected date can be divided into average segments for playback.
Page 107: Thumbnails View
Network Video Recorder User Manual 6.2.2 Thumbnails View With the thumbnails view on the playback interface, you can conveniently locate the required video files on the time bar. Steps: 1. Enter the playback interface and start to play the video files. Figure 6.
Page 108: Digital Zoom
Network Video Recorder User Manual Figure 6. 21 Playback Interface 2. Use the mouse to hold and drag through the playing time bar to fast view the video files. 3. Release the mouse to the required time point to enter the full-screen playback. The fast view is supported only in the 1X single-camera playback mode.
Page 109: File Management
Network Video Recorder User Manual 6.2.5 File Management You can manage the video clips, locked files and tags you have added in the playback mode. Steps: Enter the playback interface. Click on the toolbar to enter the file management interface. Figure 6.
Page 110: Chapter 7 Backup
Network Video Recorder User Manual Chapter 7 Backup...
Page 111: Backing Up Record Files
Network Video Recorder User Manual 7.1 Backing up Record Files 7.1.1 Quick Export Purpose: Export record files to backup device(s) quickly. Steps: 1. Enter Video Export interface. Menu > Export > Normal Choose the channel(s) you want to back up and click Quick Export button. The time duration of record files on a specified channel cannot exceed one day.
Page 112 Network Video Recorder User Manual Figure 7. 2 Quick Export using USB1-1 Stay in the Exporting interface until all record files are exported. Figure 7. 3 Export Finished Check backup result. The Player player.exe will be exported automatically during record file export. Figure 7.
Page 113: Backing Up By Normal Video Search
Network Video Recorder User Manual 7.1.2 Backing up by Normal Video Search Purpose: The record files can be backup to various devices, such as USB devices (USB flash drives, USB HDDs, USB writer), SATA writer and e-SATA HDD. Backup using USB flash drives and USB HDDs Steps: Enter Export interface.
Page 114 Network Video Recorder User Manual Figure 7. 6 Result of Normal Video Search for Backup Export the video files or picture files. Click Export All button to export all the files. Or you can select recording files you want to back up, and click Export button to enter Export interface. If the inserted USB device is not recognized: •...
Page 115: Backing Up By Event Search
Network Video Recorder User Manual Figure 7. 8 Export Finished The backup of video files using USB writer or SATA writer has the same operating instructions. Please refer to steps described above. 7.1.3 Backing up by Event Search Purpose: Back up event-related record files using USB devices (USB flash drives, USB HDDs, USB writer), SATA writer or eSATA HDD.
Page 116: Backing Up Video Clips
Network Video Recorder User Manual Figure 7. 10 Result of Event Search 6. Export the video files. Please refer to step5 of Chapter 7.1.2 Backing up by Normal Video Search for details. 7.1.4 Backing up Video Clips Purpose: You may also select video clips in playback mode to export directly during Playback, using USB devices (USB flash drives, USB HDDs, USB writer), SATA writer or eSATA HDD.
Page 117: Managing Backup Devices
Network Video Recorder User Manual 7.2 Managing Backup Devices Management of USB flash drives, USB HDDs and eSATA HDDs Steps: 1. Enter the Export interface. Figure 7. 12 Storage Device Management 2. Backup device management. Click New Folder button if you want to create a new folder in the backup device. Select a record file or folder in the backup device and click button if you want to delete it.
Page 118: Chapter 8 Alarm Settings
Network Video Recorder User Manual Chapter 8 Alarm Settings...
Page 119: Setting Motion Detection Alarm
Network Video Recorder User Manual 8.1 Setting Motion Detection Alarm Steps: 1. Enter Motion Detection interface of Camera Management and choose a camera you want to set up motion detection. Menu > Camera > Motion Set up detection area and sensitivity. Tick Enable Motion Detection, and use the mouse to draw detection area(s) and drag the sensitivity bar to set sensitivity.
Page 120 Network Video Recorder User Manual Set up arming schedule of the channel. 1) Select Arming Schedule tab to set the arming schedule of handling actions for the motion detection. 2) Choose one day of a week and up to eight time periods can be set within each day. 3) Click Apply to save the settings Time periods shall not be repeated or overlapped.
Page 121: Setting Sensor Alarms
Network Video Recorder User Manual 8.2 Setting Sensor Alarms Purpose: Set the handling action of an external sensor alarm. Steps: Enter Alarm Settings of System Configuration and select an alarm input. Menu> Configuration> Alarm Select Alarm Input tab to enter Alarm Input Settings interface. Figure 8.
Page 122 Network Video Recorder User Manual 4. Select Trigger Channel tab and select one or more channels which will start to record or become full-screen monitoring when an external alarm is input, and click Apply to save the settings. Select Arming Schedule tab to set the arming schedule of handling actions. Figure 8.
Page 123 Network Video Recorder User Manual If you want to set handling action of another alarm input, repeat the above steps. Or you can click the Copy button on the Alarm Input Setup interface and check the checkbox of alarm inputs to copy the settings to them. Figure 8.
Page 124: Detecting Video Loss Alarm
Network Video Recorder User Manual 8.3 Detecting Video Loss Alarm Purpose: Detect video loss of a channel and take alarm response action(s). Steps: Enter Video Loss interface of Camera Management and select a channel you want to detect. Menu > Camera > Video Loss Figure 8.
Page 125 Network Video Recorder User Manual Click the OK button to complete the video loss settings of the channel.
Page 126: Detecting Video Tampering Alarm
Network Video Recorder User Manual 8.4 Detecting Video Tampering Alarm Purpose: Trigger alarm when the lens is covered and take alarm response action(s). Steps: 1. Enter Video Tampering interface of Camera Management and select a channel you want to detect video tampering.
Page 127 Network Video Recorder User Manual Figure 8. 12 Set Arming Schedule of Video Tampering 4. Select Linkage Action tab to set up alarm response actions of video tampering alarm (please refer to Chapter 8.6 Setting Alarm Response Actions). Click the OK button to complete the video tampering settings of the channel.
Page 128: Handling Exceptions Alarm
Network Video Recorder User Manual 8.5 Handling Exceptions Alarm Purpose: Exception settings refer to the handling action of various exceptions, e.g. • HDD Full: The HDD is full. • HDD Error: Writing HDD error or unformatted HDD. • Network Disconnected: Disconnected network cable. •...
Page 129: Setting Alarm Response Actions
Network Video Recorder User Manual 8.6 Setting Alarm Response Actions Purpose: Alarm response actions will be activated when an alarm or exception occurs, including Event Hint Display, Full Screen Monitoring, Audible Warning (buzzer), Notify Surveillance Center, Upload Picture to FTP, Trigger Alarm Output and Send Email.
Page 130 Network Video Recorder User Manual You must select during “Trigger Channel” settings the channel(s) you want to make full screen monitoring. Audible Warning Trigger an audible beep when an alarm is detected. Notify Surveillance Center Sends an exception or alarm signal to remote alarm host when an event occurs. The alarm host refers to the PC installed with Remote Client.
Page 131 Network Video Recorder User Manual Figure 8. 17 Set Arming Schedule of Alarm Output 3. Repeat the above steps to set up arming schedule of other days of a week. You can also use Copy button to copy an arming schedule to other days. Click the OK button to complete the video tampering settings of the alarm output No.
Page 132: Triggering Or Clearing Alarm Output Manually
Network Video Recorder User Manual 8.7 Triggering or Clearing Alarm Output Manually Purpose: Sensor alarm can be triggered or cleared manually. If “Manually Clear” is selected in the dropdown list of dwell time of an alarm output, the alarm can be cleared only by clicking Clear button in the following interface. Steps: Select the alarm output you want to trigger or clear and make related operations.
Page 133: Chapter 9 Vca Alarm
Network Video Recorder User Manual Chapter 9 VCA Alarm...
Page 134: Face Detection
Network Video Recorder User Manual The NVR supports the VCA detection alarm (face detection, vehicle detection, line crossing detection and intrusion detection, region entrance detection, region exiting detection, unattended baggage detection, object removal detection, audio loss exception detection, sudden change of sound intensity detection, and defocus detection) sent by IP camera.
Page 135 Network Video Recorder User Manual detection sensitivity. Sensitivity: Range [1-5]. The higher the value is, the more easily the face can be detected. Figure 9. 2 Set Face Detection Sensitivity Click Apply to activate the settings.
Page 136: Vehicle Detection
Network Video Recorder User Manual 9.2 Vehicle Detection Purpose: Vehicle Detection is available for the road traffic monitoring. In Vehicle Detection, the passed vehicle can be detected and the picture of its license plate can be captured. You can send alarm signal to notify the surveillance center and upload the captured picture to FTP server.
Page 137 Network Video Recorder User Manual Figure 9. 4 Rule Settings Click Save to save the settings. Please refer to the User Manual of Network Camera for the detailed instructions for the vehicle detection.
Page 138: Line Crossing Detection
Network Video Recorder User Manual 9.3 Line Crossing Detection Purpose: This function can be used for detecting people, vehicles and objects cross a set virtual line. The line crossing direction can be set as bidirectional, from left to right or from right to left. And you can set the duration for the alarm response actions, such as full screen monitoring, audible warning, etc.
Page 139 Network Video Recorder User Manual Up to 4 rules can be configured. Figure 9. 6 Draw Line for Line Crossing Detection Click Apply to activate the settings.
Page 140: Intrusion Detection
Network Video Recorder User Manual 9.4 Intrusion Detection Purpose: Intrusion detection function detects people, vehicle or other objects which enter and loiter in a pre-defined virtual region, and some certain actions can be taken when the alarm is triggered. Steps: Enter the VCA settings interface.
Page 141 Network Video Recorder User Manual Figure 9. 8 Draw Area for Intrusion Detection Click Apply to save the settings.
Page 142: Region Entrance Detection
Network Video Recorder User Manual 9.5 Region Entrance Detection Purpose: Region entrance detection function detects people, vehicle or other objects which enter a pre-defined virtual region from the outside place, and some certain actions can be taken when the alarm is triggered. Steps: Enter the VCA settings interface.
Page 143: Region Exiting Detection
Network Video Recorder User Manual 9.6 Region Exiting Detection Purpose: Region exiting detection function detects people, vehicle or other objects which exit from a pre-defined virtual region, and some certain actions can be taken when the alarm is triggered. Please refer to the Chapter 9.5 Region Entrance Detection for operating steps to configure the region exiting ...
Page 144: Audio Exception Detection
Network Video Recorder User Manual 9.9 Audio Exception Detection Purpose: Audio exception detection function detects the abnormal sounds in the surveillance scene, such as the sudden increase / decrease of the sound intensity, and some certain actions can be taken when the alarm is triggered. Steps: Enter the VCA settings interface.
Page 145: Defocus Detection
Network Video Recorder User Manual Scene change detection function detects the change of surveillance environment affected by the external factors; such as the intentional rotation of the camera, and some certain actions can be taken when the alarm is triggered. Please refer to the Chapter 9.1 Face Detection for operating steps to configure the scene change detection.
Page 146: Chapter 10 Vca Search
Network Video Recorder User Manual Chapter 10 VCA Search...
Page 147: Face Search
Network Video Recorder User Manual With the configured VCA detection, the NVR supports the VCA search for the behavior analysis, face capture, people counting and heat map results. The DS-7600 series NVR supports the behavior search only. 10.1 Face Search Purpose: When there are detected face picture captured and saved in HDD, you can enter the Face Search interface to search the picture and play the picture related video file according to the specified conditions.
Page 148 Network Video Recorder User Manual Figure 10. 2 Face Search Interface 5. Play the face picture related video file. You can double click on a face picture to play its related video file in the view window on the top right, or select a picture item and click to play it.
Page 149: Behavior Search
Network Video Recorder User Manual 10.2 Behavior Search Purpose: The behavior analysis detects a series of suspicious behavior based on VCA detection, and certain linkage methods will be enabled if the alarm is triggered. Steps: Enter the Behavior Search interface. Menu>VCA Search>...
Page 150: Plate Search
Network Video Recorder User Manual Figure 10. 5 Behavior Search Results Play the behavior analysis picture related video file. You can double click on a picture from the list to play its related video file in the view window on the top right, or select a picture item and click to play it.
Page 151: People Counting
Network Video Recorder User Manual Figure 10. 6 Plate Search Select the country from the drop-down list for searching the location of the vehicle plate. Input the plate No. in the field for search. 7. Click Search to start searching. The search results of detected vehicle plate pictures are displayed in list or in chart.
Page 152 Network Video Recorder User Manual Figure 10. 7 People Counting Interface 6. You can click the Export button to export the statistics report in excel format.
Page 153: Heat Map
Network Video Recorder User Manual 10.5 Heat Map Purpose: Heat map is a graphical representation of data represented by colors. The heat map function is usually used to analyze the visit times and dwell time of customers in a configured area. The heat map function must be supported by the connected IP camera and the corresponding configuration must be set.
Page 154: Chapter 11 Network Settings
Network Video Recorder User Manual Chapter 11 Network Settings...
Page 155: Configuring General Settings
Network Video Recorder User Manual 11.1 Configuring General Settings Purpose: Network settings must be properly configured before you operate NVR over network. Steps: Enter the Network Settings interface. Menu > Configuration > Network Select the General tab. Figure 11. 1 Network Settings Interface of DS-8600NI-E8 and DS-7700NI-E4 ...
Page 156 Network Video Recorder User Manual Two 10M/100M/1000M NIC cards are provided by the DS-8600NI-E8 and DS-7700NI-E4 series device, which allows the device to work in the Multi-address and Net-fault Tolerance modes. Multi-address Mode: The parameters of the two NIC cards can be configured independently. You can select LAN1 or LAN2 in the NIC type field for parameter settings.
Page 157: Configuring Advanced Settings
Network Video Recorder User Manual 11.2 Configuring Advanced Settings 11.2.1 Configuring Hik-Connect Purpose Hik-Connect enables the mobile phone application and the service platform page (www.hik-connect.com) to access and manage your connected NVR, providing a convenient remote access to the surveillance system. The Hik-Connect can be enabled via operation on SADP software, GUI and Web browser.
Page 158 Network Video Recorder User Manual Figure 11. 3 Service Terms 1) Create the verification code and enter the code in the Verification Code text field. 2) Check the checkbox of The Hik-Connect service will require internet access. Please read Service Terms and Privacy Statement before enabling the service. 3) Scan the QR code on the interface to read the Service Terms and the Privacy Statement.
Page 159: Configuring Ddns
Network Video Recorder User Manual 6. Click the Apply button to save the settings. After configuration, you can access and manage the NVR by your mobile phone on which the Hik-Connect application is installed or by the website (www.hik-connect.com). Please refer to the help file on the official website (www.hik-connect.com) and the Hik-Connect Mobile Client User Manual for adding the device to Hik-Connect and more operation instructions.
Page 160: Configuring Ntp Server
Network Video Recorder User Manual Figure 11. 6 PeanutHull Settings Interface • NO-IP: Enter the account information in the corresponding fields. Refer to the DynDNS settings. 5) Enter Server Address for NO-IP. 6) In the NVR Domain Name text field, enter the domain obtained from the NO-IP website (www.no-ip.com).
Page 161: Configuring Snmp
Network Video Recorder User Manual 1. Enter the Network Settings interface. Menu >Configuration> Network 2. Select the NTP tab to enter the NTP Settings interface, as shown in Figure 11. 8. Figure 11. 8 NTP Settings Interface 3. Check the Enable NTP checkbox to enable this feature. 4.
Page 162: Configuring More Settings
Network Video Recorder User Manual Figure 11. 10 SNMP Settings Interface When you choose the Yes option in step4, configure the following SNMP settings: • Trap Address: IP Address of SNMP host. • Trap Port: Port of SNMP host. Click the Apply button to save and exit the interface. Before setting the SNMP, please download the SNMP software and manage to receive the device information via SNMP port.
Page 163: Configuring Https Port
Network Video Recorder User Manual it according to different requirements.  Server Port and HTTP Port: Enter the Server Port and HTTP Port in the text fields. The default Server Port is 8000 and the HTTP Port is 80, and you can change them according to different requirements.
Page 164 Network Video Recorder User Manual Figure 11. 13 HTTPS Settings OPTION 1: Create the self-signed certificate 1) Click the Create button to create the following dialog box. Figure 11. 14 Create Self-signed Certificate 2) Enter the country, host name/IP, validity and other information. 3) Click OK to save the settings.
Page 165: Configuring Email
Network Video Recorder User Manual 11.2.7 Configuring Email Purpose: The system can be configured to send an Email notification to all designated users if an alarm event is detected, etc., an alarm or motion event is detected or the administrator password is changed. Before configuring the Email settings, the NVR must be connected to a local area network (LAN) that maintains an SMTP mail server.
Page 166: Configuring Nat
Network Video Recorder User Manual Enable SSL/TLS (optional): Click the checkbox to enable SSL/TLS if required by the SMTP server. Sender: The name of sender. Sender’s Address: The Email address of sender. Select Receivers: Select the receiver. Up to 3 receivers can be configured. Receiver: The name of user to be notified.
Page 167 Network Video Recorder User Manual Figure 11. 19 UPnP™ Settings Interface 3. Check checkbox to enable UPnP™. 4. Select the Mapping Type as Manual or Auto in the drop-down list. OPTION 1: Auto If you select Auto, the Port Mapping items are read-only, and the external ports are set by the router automatically.
Page 168 Network Video Recorder User Manual Figure 11. 21 External Port Settings Dialog Box Click Apply button to save the settings. You can click Refresh button to get the latest status of the port mapping. Figure 11. 22 UPnP™ Settings Finished-Manual Manual Mapping ...
Page 169: Configuring Virtual Host
Network Video Recorder User Manual Figure 11. 23 External Port Settings Dialog Box 5. Click OK to save the setting for the current port and return to the upper-level menu. 6. Click Apply button to save the settings. 7. Enter the virtual server setting page of router; fill in the blank of Internal Source Port with the internal port value, the blank of External Source Port with the external port value, and other required contents.
Page 170 Network Video Recorder User Manual Figure 11. 25 Advanced Settings Interface Check the checkbox of the Enable Virtual Host. Click the Save button to save the setting. 4. Enter the IP camera management interface of NVR. The Connect column appears on the right-most side of the camera list, as shown in the Figure 11.
Page 171: Checking Network Traffic
Network Video Recorder User Manual 11.3 Checking Network Traffic Purpose: You can check the network traffic to obtain real-time information of NVR such as linking status, MTU, sending/receiving rate, etc. Steps: Enter the Network Traffic interface. Menu > Maintenance > Net Detect Figure 11.
Page 172: Configuring Network Detection
Network Video Recorder User Manual 11.4 Configuring Network Detection Purpose: You can obtain network connecting status of NVR through the network detection function, including network delay, packet loss, etc. 11.4.1 Testing Network Delay and Packet Loss Steps: 1. Enter the Network Traffic interface. Menu >Maintenance>Net Detect 2.
Page 173: Checking The Network Status
Network Video Recorder User Manual Click Refresh button if the connected local backup device cannot be displayed. When it fails to detect the backup device, please check whether it is compatible with the NVR. You can format the backup device if the format is incorrect.
Page 174: Checking Network Statistics
Network Video Recorder User Manual Figure 11. 32 Network Status Checking If the network is normal the following message box pops out. Figure 11. 33 Network status checking result If the message box pops out with other information instead of this one, you can click Network button to show the quick setting interface of the network parameters.
Page 175 Network Video Recorder User Manual Figure 11. 34 Network Stat. Interface Check the bandwidth of IP Camera, bandwidth of Remote Live View, bandwidth of Remote Playback, bandwidth of Net Receive Idle and bandwidth of Net Send Idle. You can click Refresh to get the newest status.
Page 176: Chapter 12 Hdd Management
Network Video Recorder User Manual Chapter 12 HDD Management...
Page 177: Initializing Hdds
Network Video Recorder User Manual 12.1 Initializing HDDs Purpose: A newly installed hard disk drive (HDD) must be initialized before it can be used with your NVR. A message box pops up when the NVR starts up if there exits any uninitialized HDD. Figure 12.
Page 178 Network Video Recorder User Manual Figure 12. 5 HDD Status Changes to Normal Initializing the HDD will erase all data on it.
Page 179: Managing Network Hdd
Network Video Recorder User Manual 12.2 Managing Network HDD Purpose: You can add the allocated NAS or disk of IP SAN to NVR, and use it as network HDD. Steps: Enter the HDD Information interface. Menu > HDD>General Figure 12. 6 HDD Information Interface Click the Add button to enter the Add NetHDD interface, as shown in Figure 12.
Page 180 Network Video Recorder User Manual Figure 12. 8 Add NAS Disk • Add IP SAN: 1) Enter the NetHDD IP address in the text field. 2) Click the Search button to search the available IP SAN disks. 3) Select the IP SAN disk from the list shown below. 4) Click the OK button to add the selected IP SAN disk.
Page 181 Network Video Recorder User Manual Figure 12. 10 Initialize Added NetHDD...
Page 182: Managing Hdd Group
Network Video Recorder User Manual 12.3 Managing HDD Group 12.3.1 Setting HDD Groups Purpose: Multiple HDDs can be managed in groups. Video from specified channels can be recorded onto a particular HDD group through HDD settings. Steps: Enter the Storage Mode interface. Menu >...
Page 183: Setting Hdd Property
Network Video Recorder User Manual Figure 12. 13 Local HDD Settings Interface Select the Group number for the current HDD. The default group No. for each HDD is 1. Click the OK button to confirm the settings. Figure 12. 14 Confirm HDD Group Settings In the pop-up Attention box, click the Yes button to finish the settings.
Page 184 Network Video Recorder User Manual Figure 12. 15 Set HDD Property 3. Set the HDD property to R/W, Read-only or Redundancy. 4. Click the OK button to save the settings and exit the interface. 5. In the HDD Information menu, the HDD property will be displayed in the list. At least 2 hard disks must be installed on your NVR when you want to set a HDD to Redundancy, and there is one HDD with R/W property.
Page 185: Configuring Quota Mode
Network Video Recorder User Manual 12.4 Configuring Quota Mode Purpose: Each camera can be configured with allocated quota for the storage of recorded files. Steps: Enter the Storage Mode interface. Menu > HDD > Advanced Set the Mode to Quota, as shown in Figure 12. 16. The NVR must be rebooted to enable the changes to take effect.
Page 186: Checking Hdd Status
Network Video Recorder User Manual 12.5 Checking HDD Status Purpose: You may check the status of the installed HDDs on NVR so as to take immediate check and maintenance in case of HDD failure. Checking HDD Status in HDD Information Interface Steps: Enter the HDD Information interface.
Page 187: Hdd Detection
Network Video Recorder User Manual 12.6 HDD Detection Purpose: The device provides the HDD detection function such as the adopting of the S.M.A.R.T. and the Bad Sector Detection technique. The S.M.A.R.T. (Self-Monitoring, Analysis and Reporting Technology) is a monitoring system for HDD to detect and report on various indicators of reliability in the hopes of anticipating failures. S.M.A.R.T.
Page 188 Network Video Recorder User Manual Figure 12. 21 Bad Sector Detection And you can click Error info button to see the detailed damage information. And you can also pause/resume or cancel the detection.
Page 189: Configuring Hdd Error Alarms
Network Video Recorder User Manual 12.7 Configuring HDD Error Alarms Purpose: You can configure the HDD error alarms when the HDD status is Uninitialized or Abnormal. Steps: Enter the Exception interface. Menu > Configuration > Exceptions Select the Exception Type to HDD Error from the dropdown list. Click the checkbox(s) below to select the HDD error alarm type (s), as shown in Figure 12.
Page 190: Chapter 13 Camera Settings
Network Video Recorder User Manual Chapter 13 Camera Settings...
Page 191: Configuring Osd Settings
Network Video Recorder User Manual 13.1 Configuring OSD Settings Purpose: You can configure the OSD (On-screen Display) settings for the camera, including date /time, camera name, etc. Steps: Enter the OSD Configuration interface. Menu > Camera > OSD Select the camera to configure OSD settings. Edit the Camera Name in the text field.
Page 192: Configuring Privacy Mask
Network Video Recorder User Manual 13.2 Configuring Privacy Mask Purpose: You are allowed to configure the four-sided privacy mask zones that cannot be viewed by the operator. The privacy mask can prevent certain surveillance areas to be viewed or recorded. Steps: Enter the Privacy Mask Settings interface.
Page 193: Configuring Video Parameters
Network Video Recorder User Manual 13.3 Configuring Video Parameters Purpose: You can customize the image parameters including the brightness, contrast, saturation, image rotate and mirror for the live view and recording effect. Steps: Enter the Image Settings interface. Menu > Camera >Image Figure 13.
Page 194: Chapter 14 Nvr Management And Maintenance
Network Video Recorder User Manual Chapter 14 NVR Management Maintenance...
Page 195: Viewing System Information
Network Video Recorder User Manual 14.1 Viewing System Information Steps: Enter the System Information interface. Menu >Maintenance>System Info 2. You can click the Device Info, Camera, Record, Alarm, Network and HDD tabs to view the system information of the device. XXXXXXXXXXXXXX XXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXX XXXXXXXXXXXXXXX...
Page 196: Searching & Export Log Files
Network Video Recorder User Manual 14.2 Searching & Export Log Files Purpose: The operation, alarm, exception and information of the NVR can be stored in log files, which can be viewed and exported at any time. Steps: 1. Enter the Log Search interface. Menu >...
Page 197 Network Video Recorder User Manual Figure 14. 3 Log Search Results Up to 2000 log files can be displayed each time. 5. You can click the button of each log or double click it to view its detailed information, as shown in Figure 14.
Page 198 Network Video Recorder User Manual Figure 14. 5 Export Log Files 7. Select the backup device from the dropdown list of Device Name. 8. Select the format of the log files to be exported. Up to 9 formats are selectable. 9.
Page 199: Importing/Exporting Ip Camera Info
Network Video Recorder User Manual 14.3 Importing/Exporting IP Camera Info Purpose: The information of added IP camera can be generated into an excel file and exported to the local device for backup, including the IP address, manage port, password of admin, etc.. And the exported file can be edited on your PC, like adding or deleting the content, and copy the setting to other devices by importing the excel file to it.
Page 200: Importing/Exporting Configuration Files
Network Video Recorder User Manual 14.4 Importing/Exporting Configuration Files Purpose: The configuration files of the NVR can be exported to local device for backup; and the configuration files of one NVR can be imported to multiple NVR devices if they are to be configured with the same parameters. Steps: Enter the Import/Export Configuration File interface.
Page 201: Upgrading System
Network Video Recorder User Manual 14.5 Upgrading System Purpose: The firmware on your NVR can be upgraded by local backup device, or remote FTP server. 14.5.1 Upgrading by Local Backup Device Steps: Connect your NVR with a local backup device where the update firmware file is located. Enter the Upgrade interface.
Page 202 Network Video Recorder User Manual Menu >Maintenance>Upgrade 2. Click the FTP tab to enter the local upgrade interface, as shown in Figure 14. 8. Figure 14. 8 FTP Upgrade Interface 3. Enter the FTP Server Address in the text field. 4.
Page 203: Restoring Default Settings
Network Video Recorder User Manual 14.6 Restoring Default Settings Steps: 1. Enter the Default interface. Menu > Maintenance > Default Figure 14. 9 Restore Defaults 2. Select the restoring type from the following three options. Restore Defaults: Restore all parameters, except the network (including IP address, subnet mask, gateway, MTU, NIC working mode, default route, server port, etc.) and user account parameters, to the factory default settings.
Page 204: Chapter 15 Others
Network Video Recorder User Manual Chapter 15 Others...
Page 205: Configuring Rs-232 Serial Port
Network Video Recorder User Manual 15.1 Configuring RS-232 Serial Port The RS-232 is provided by the DS-8600NI-E8 and DS-7700NI-E4 series NVR only. Purpose: The RS-232 port can be used in two ways: • Parameters Configuration: Connect a PC to the NVR through the PC serial port. Device parameters can be configured by using software such as HyperTerminal.
Page 206: Configuring General Settings
Network Video Recorder User Manual 15.2 Configuring General Settings Purpose: You can configure the BNC output standard, VGA output resolution, mouse pointer speed through the Menu > Configuration > General interface. Steps: 1. Enter the General Settings interface. Menu >Configuration> General 2.
Page 207 Network Video Recorder User Manual • Resolution: For DS-8600NI series NVR, you can configure the VGA/HDMI resolution and VGA2/HDMI 2 resolution. And up to 4K (3840 × 2160) resolution is selectable for the VGA/HDMI output. For the DS-7600NI and DS-7700NI series NVR, you can configure the VGA resolution and HDMI resolution respectively.
Page 208: Configuring Dst Settings
Network Video Recorder User Manual 15.3 Configuring DST Settings Steps: Enter the General Settings interface. Menu >Configuration>General Choose DST Settings tab. Figure 15. 4 DST Settings Interface You can check the checkbox before the Auto DST Adjustment item. Or you can manually check the Enable DST checkbox, and then you choose the date of the DST period.
Page 209: Configuring More Settings For Device Parameters
Network Video Recorder User Manual 15.4 Configuring More Settings for Device Parameters Steps: Enter the General Settings interface. Menu >Configuration>General Click the More Settings tab to enter the More Settings interface, as shown in Figure 15. 5 Figure 15. 5 More Settings Interface Configure the following settings: •...
Page 210: Managing User Accounts
Network Video Recorder User Manual 15.5 Managing User Accounts Purpose: There is a default account in the NVR: Administrator. The Administrator user name is admin and the password is set when you start the device for the first time. The Administrator has the permission to add and delete user and configure user parameters.
Page 211 Network Video Recorder User Manual and User’s MAC Address. Password: Set the password for the user account. STRONG PASSWORD RECOMMENDED– We highly recommend you create a strong password of your own choosing (using a minimum of 8 characters, including upper case letters, lower case letters, numbers, and special characters) in order to increase the security of your product.
Page 212: Deleting A User
Network Video Recorder User Manual 6. Set the operating permission of Local Configuration, Remote Configuration and Camera Configuration for the user. Local Configuration • Local Log Search: Searching and viewing logs and system information of NVR. • Local Parameters Settings: Configuring parameters, restoring factory default parameters and importing/exporting configuration files.
Page 213: Editing A User
Network Video Recorder User Manual Figure 15. 10 User List Click the icon to delete the selected user account. 15.5.3 Editing a User For the added user accounts, you can edit the parameters. Steps: Enter the User Management interface. Menu >Configuration>User Select the user to be edited from the list, as shown in Figure 15.
Page 214 Network Video Recorder User Manual Figure 15. 12 Edit User (admin) Edit the corresponding parameters. • Operator and Guest You can edit the user information, including user name, password, permission level and MAC address. Check the checkbox of Change Password if you want to change the password, and input the new password in the text field of Password and Confirm.
Page 215 Network Video Recorder User Manual Figure 15. 13 Set Unlock Patter for Admin User of Export GUID to enter the reset password interface to export the GUID file for the Click the admin user account. When the admin password is changed, you can re-export the GUID file to the connected U-flash disk for the future password resetting.
Page 216: Chapter 16 Appendix
Network Video Recorder User Manual Chapter 16 Appendix...
Page 217: Specifications
Network Video Recorder User Manual 16.1 Specifications DS-7600NI-E1 Model DS-7604NI-E1 DS-7608NI-E1 DS-7616NI-E1 IP video input 4-ch 8-ch 16-ch Video/Audio input Two-way audio input 1-ch, RCA (2.0 Vp-p, 1kΩ) Incoming bandwidth 40 Mbps 80 Mbps 160 Mbps Network Outgoing bandwidth 80 Mbps Remote connection Recording resolution 6MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF...
Page 218: Ds-7600Ni-E2
Network Video Recorder User Manual DS-7600NI-E2 Model DS-7608NI-E2 DS-7616NI-E2 DS-7632NI-E2 IP video input 8-ch 16-ch 32-ch Video/Audio input Two-way audio 1-ch, RCA (2.0 Vp-p, 1kΩ) Incoming bandwidth 80 Mbps 160 Mbps 160 Mbps Network Outgoing bandwidth 80 Mbps Remote connection Recording resolution 6MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF Main stream: 50 fps (P)/60 fps (N)
Page 219: Ds-7700Ni-E4/P
Network Video Recorder User Manual DS-7700NI-E4/P Model DS-7708NI-E4/8P DS-7716NI-E4/16P DS-7732NI-E4/16P IP video input 8-ch 16-ch 32-ch Video/Audio input Two-way audio 1-ch, RCA (2.0 Vp-p, 1kΩ) Incoming bandwidth 80 Mbps 160 Mbps 160 Mbps Network Outgoing bandwidth 80 Mbps Remote connection Recording resolution 6MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF Main stream: 50 fps (P)/60 fps (N)
Page 220: Ds-7700Ni-E4
Network Video Recorder User Manual DS-7700NI-E4 Model DS-7708NI-E4 DS-7716NI-E4 DS-7732NI-E4 IP video input 8-ch 16-ch 32-ch Video/Audio input Two-way audio 1-ch, RCA (2.0 Vp-p, 1kΩ) Incoming bandwidth 80 Mbps 160 Mbps 160 Mbps Network Outgoing bandwidth 80 Mbps Remote connection Recording resolution 6MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF Main stream: 50 fps (P)/60 fps (N)
Page 221: Ds-8600Ni-E8
Network Video Recorder User Manual DS-8600NI-E8 Model DS-8608NI-E8 DS-8616NI-E8 DS-8632NI-E8 IP video input 8-ch 16-ch 32-ch Video/Audio input Two-way audio 1-ch, RCA (2.0 Vp-p, 1kΩ) Incoming bandwidth 80 Mbps 160 Mbps 160 Mbps Network Outgoing bandwidth 80 Mbps Remote connection Recording resolution 6MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF Main stream: 50 fps (P)/60 fps (N)
Page 222: Ds-7604Ni-E1/4N And Ds-7608Ni-E2/8N
Network Video Recorder User Manual DS-7604NI-E1/4N and DS-7608NI-E2/8N Model DS-7604NI-E1/4N DS-7608NI-E2/8N IP video input 4-ch 8-ch Video/Audio input Two-way audio input 1-ch, RCA (2.0 Vp-p, 1kΩ) Incoming bandwidth 40 Mbps 80 Mbps Network Outgoing bandwidth 80 Mbps Remote connection Recording resolution 6MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF Main stream: 50 fps (P)/60 fps (N) Frame rate...
Page 223: Ds-7600Ni-E2/N
Network Video Recorder User Manual DS-7600NI-E2/N Model DS-7616NI-E2/8N DS-7632NI-E2/8N DS-7616NI-E2/16N DS-7632NI-E2/16N IP video input 16-ch 32-ch 16-ch 32-ch Video/Audio Two-way audio input 1-ch, RCA (2.0 Vp-p, 1kΩ) input Incoming 160 Mbps bandwidth Outgoing Network 80 Mbps bandwidth Remote connection Recording 6MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF resolution Main stream: 50 fps (P)/60 fps (N)
Page 224: Ds-7604Ni-E1/4P And Ds-7608Ni-E2/8P
Network Video Recorder User Manual DS-7604NI-E1/4P and DS-7608NI-E2/8P Model DS-7604NI-E1/4P DS-7608NI-E2/8P IP video input 4-ch 8-ch Video/Audio input Two-way audio input 1-ch, RCA (2.0 Vp-p, 1kΩ) Incoming bandwidth 40 Mbps 80 Mbps Network Outgoing bandwidth 80 Mbps Remote connection Recording resolution 6MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF Main stream: 50 fps (P)/60 fps (N) Frame rate...
Page 225: Ds-7600Ni-E2/P
Network Video Recorder User Manual DS-7600NI-E2/P Model DS-7616NI-E2/8P DS-7632NI-E2/8P DS-7616NI-E2/16P DS-7632NI-E2/16P IP video input 16-ch 32-ch 16-ch 32-ch Video/Audio Two-way audio input 1-ch, RCA (2.0 Vp-p, 1kΩ) input Incoming 160 Mbps bandwidth Outgoing Network 80 Mbps bandwidth Remote connection Recording 6MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF resolution Main stream: 50 fps (P)/60 fps (N)
Page 226: Glossary
Network Video Recorder User Manual 16.2 Glossary • Dual Stream: Dual stream is a technology used to record high resolution video locally while transmitting a lower resolution stream over the network. The two streams are generated by the DVR, with the main stream having a maximum resolution of 4CIF and the sub-stream having a maximum resolution of CIF.
Page 227: Troubleshooting
Network Video Recorder User Manual 16.3 Troubleshooting No image displayed on the monitor after starting up normally.  Possible Reasons No VGA or HDMI connections. Connection cable is damaged. Input mode of the monitor is incorrect. Steps 1. Verify the device is connected with the monitor via HDMI or VGA cable.
Page 228 Network Video Recorder User Manual Possible Reasons Network failure, and the NVR and IP camera lost connections. The configured parameters are incorrect when adding the IP camera. Insufficient bandwidth. Steps 1. Verify the network is connected. 1) Connect the NVR and PC with the RS-232 cable. 2) Open the Super Terminal software, and execute the ping command.
Page 229 Network Video Recorder User Manual Check the brand, model of the switch connecting IP camera and NVR, and contact with the manufacturer of the switch to check if it has the function of flow control. If so, please turn it down. 5.
Page 230 Network Video Recorder User Manual The performances of hardware are not good enough, including CPU, memory, etc.. Steps: 1. Verify the network between NVR and IP camera is connected. 1) When image is stuck, connect the RS-232 ports on PC and the rear panel of NVR with the RS-232 cable.
Page 231 Network Video Recorder User Manual c) The encoding standard is not supported with NVR. Steps: 1. Verify the cable between the pickup and IP camera is connected well; impedance matches and compatible. Log in the IP camera directly, and turn the audio on, check if the sound is normal. If not, please contact the manufacturer of the IP camera.
Page 232 Network Video Recorder User Manual Steps: 1. Verify the system time setting is correct. Select “Menu > Configuration > General > General”, and verify the “Device Time” is correct. 2. Verify the search condition is correct. Select “Playback”, and verify the channel and time are correct. 3.
Page 233 Network Video Recorder User Manual...
Page 234: Summary Of Changes
Network Video Recorder User Manual 16.4 Summary of Changes Version 3.4.92 Added: Easy network access by Hik-Connect (Chapter 2.2 Using the Wizard for Basic Configuration, Chapter 11.2.1  Configuring Hik-Connect) Deleted: Delete two DDNS types: IP sever and HiDDNS (Chapter 2.2 Using the Wizard for Basic Configuration, ...
Page 235 Network Video Recorder User Manual Version 3.4.2 Added: Support the display of IP camera’s password on the IP camera management interface. (Chapter 2.6 Adding  and Connecting the IP Cameras; Chapter 15.5.3 Editing a User) Add the configuration and use of unlock pattern for fast login. (Chapter 2.3 Using the Unlock Pattern for ...
Page 236 Network Video Recorder User Manual Support VCA search function for behavior search, face search, people counting and heat map. (Chapter 10)  Support up to 9 formats for selection when you export the files to storage device. (Chapter 7)  The prompt will pop up when you input wrong user name or password in login interface.(Chapter 2.2) ...
Page 237 Network Video Recorder User Manual 16.5 List of Compatible IP Cameras 16.5.1 List of Hikvision IP Cameras For the list, our company holds right to interpret. Max. Type Model Version Sub-stream Audio Resolution DS-2CD7133F-E V5.2.0 build 140721 640*480 √ ×...
Page 238 Network Video Recorder User Manual Max. Type Model Version Sub-stream Audio Resolution DS-2CD4312FWD-I V5.3.0 build150327 1280*960 √ × DS-2CD4324F-I V5.3.0 build150327 1920*1080 √ × DS-2CD4332FHWD-IS V5.3.0 build150327 2048*1536 √ √ DS-2CD4332FHWD-I V5.3.0 build150327 2048*1536 √ × DS-2CD4332FWD-I V5.3.0 build150327 2048*1536 √...
Page 239 Network Video Recorder User Manual Max. Type Model Version Sub-stream Audio Resolution iDS-2CD9121 V3.7.1 build140417 1600*1200 √ × DS-2CD9131 V4.0.0 build150213 2048*1536 √ × iDS-2CD9131 V4.0.0 build150213 2048*1536 √ × DS-2CD9121A V3.8.2 build141121 1600*1200 √ × iDS-2CD9121A V3.8.2 build141121 1600*1200 √...
Page 240 Network Video Recorder User Manual Max. Type Model Version Sub-stream Audio Resolution DS-6516HFI- SATA V1.0.1 build130607 704*576 √ √ DS-6601HCI V1.2.1 build131202 352*288 √ √ DS-6602HCI V1.2.1 build131202 352*288 √ √ DS-6604HCI V1.2.1 build131202 352*288 √ √ DS-6601HFI(-SATA) V1.2.1 build131202 704*576 √...
Page 241 Network Video Recorder User Manual Max. Type Model Version Sub-stream Audio Resolution iDS-2DF5294-A/D/A3/D3/AF/A3F V5.2.8 build150124 2048*1536 √ √ DS-2DF7296-A/D/AF V5.2.8 build150124 2048*1536 √ √ iDS-2DF7296-A/D/AF V5.2.8 build150124 2048*1536 √ √ DS-2DF5296-A/D/A3/D3/AF/A3F V5.2.8 build150124 2048*1536 √ √ iDS-2DF5296-A/D/A3/D3/AF/A3F V5.2.8 build150124 2048*1536 √...
Page 242 Network Video Recorder User Manual Max. Type Model Version Sub-stream Audio Resolution DS-2DE7184-A/AE/D V5.2.10 build150128 1920*1080 √ √ DS-2DE5182-A/A3 V5.2.10 build150128 1920*1080 √ √ DS-2DE5184-A/AE/AE3/A3/D/D3 V5.2.10 build150128 1920*1080 √ √ DS-2DE5186-A/AE V5.2.10 build150128 1920*1080 √ √ DS-2DE7182-A V5.2.10 build150128 1920*1080 √...
Page 243 Network Video Recorder User Manual Max. Type Model Version Sub-stream Audio Resolution Module DS-2ZCN3006(B) V5.2.7 build141107 1280*960 √ √ DS-2ZMN2006 V5.2.7 build141107 1280*960 √ √ DS-2ZMN2006(B) V5.2.7 build141107 1280*960 √ √ DS-2ZMN3006 V5.2.7 build141107 1280*960 √ √ DS-2ZMN3006(B) V5.2.7 build141107 1280*960 √...
Page 244 Network Video Recorder User Manual 16.5.2 List of Third-party IP Cameras ONVIF compatibility refers to the camera can be supported both when it uses the ONVIF protocol and its private protocols. Only ONVIF is supported refers to the camera can only be supported when it uses the ONVIF protocol.
Page 245 Network Video Recorder User Manual IP Camera Max. Manufacturer or Model Version Sub-stream Audio Resolution Protocol compatibility) WFB-100Ap V3.1.0.9 1280×800 × √ VB-M400 Ver.+1.0.0 1280×960 × √ Canon VB-M6000D Ver.+1.0.0 1280×960 × × VB-M7000F Ver.+1.0.0 1280×960 × √ HUNT HLC_79AD V1.0.40 1600×1200 √...
Page 246 Network Video Recorder User Manual IP Camera Max. Manufacturer or Model Version Sub-stream Audio Resolution Protocol 1.8.2-20120327- IX30DN-ACFZHB3 √ × 2048×1536 2.9080-A1.7852 √(Only ONVIF SAMSUNG SNB-5080P √ V3.10_130416 1280×1024 is supported) (ONVIF compatibility) × × VCC-HD2300P 2.03-02(110318-00) 1920×1080 × √ SANYO VCC-HD2500P 2.02-02(110208-00)
Page 247 Network Video Recorder User Manual...

HIKVISION UD04701B User Manual

Chapter 1 Introduction

Chapter 2 Getting Started

Chapter 3 Live View

Chapter 4 PTZ Controls

Chapter 5 Recording Settings

Chapter 6 Playback

Chapter 7 Backup

Chapter 8 Alarm Settings

Chapter 9 VCA Alarm

Chapter 10 VCA Search

Chapter 11 Network Settings

Chapter 12 HDD Management

Chapter 13 Camera Settings

Chapter 14 NVR Management and Maintenance

Chapter 15 Others

Chapter 16 Appendix

Quick Links

Need help?

Questions and answers

Related Manuals for HIKVISION UD04701B

Summary of Contents for HIKVISION UD04701B
