Page 1: Quick Start Guide
Quick Operation Guide of WIFI Network Video Recorder Quick Start Guide UD.6L0202B1986A01... -
Page 2: Table Of Contents
Quick Operation Guide of WIFI Network Video Recorder TABLE OF CONTENTS NVR Pre-Installation ......................8 NVR Installation ......................8 HDD Installation ......................9 Main Features ....................... 11 Typical Application ....................... 12 Front Panel and Rear Panel ..................13 Menu Operation ......................15 Menu Structure ......................15 Startup and Shutdown .................... - Page 3 Any and all information, including, among others, wordings, pictures, graphs are the properties of Hangzhou Hikvision Digital Technology Co., Ltd. or its subsidiaries (hereinafter referred to be “Hikvision”). This user manual (hereinafter referred to be “the Manual”) cannot be reproduced, changed, translated, or distributed, partially or wholly, by any means, without the prior written permission of Hikvision.
- Page 4 RELEVANT LAWS IN YOUR JURISDICTION BEFORE USING THIS PRODUCT IN ORDER TO ENSURE THAT YOUR USE CONFORMS THE APPLICABLE LAW. HIKVISION SHALL NOT BE LIABLE IN THE EVENT THAT THIS PRODUCT IS USED WITH ILLEGITIMATE PURPOSES. IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE...
- Page 5 Quick Operation Guide of WIFI Network Video Recorder Regulatory information FCC information FCC compliance: Please take attention that changes or modification not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Note: This product has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
- Page 6 Quick Operation Guide of WIFI Network Video Recorder This equipment should be installed and operated with a minimum distance 20cm between the radiator and your body. FCC conditions This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: 1.
- Page 7 Quick Operation Guide of WIFI Network Video Recorder product documentation for specific battery information. The battery is marked with this symbol, which may include lettering to indicate cadmium (Cd), lead (Pb), or mercury (Hg). For proper recycling, return the battery to your supplier or to a designated collection point.
- Page 8 Quick Operation Guide of WIFI Network Video Recorder gain should be so chosen that the equivalent isotropically radiated power (e.i.r.p.) is not more than that necessary for successful communication. Conformé ment à la ré glementation d'Industrie Canada, le pré sent é metteur radio peut fonctionner avec une antenne d'un type et d'un gain maximal (ou infé...
-
Page 9: Nvr Pre-Installation
Quick Operation Guide of WIFI Network Video Recorder This manual is applicable to the model DS-7108NI-E1/V/W. NVR Pre-Installation The NVR is highly advanced surveillance equipment that should be installed with care. Please take into consideration the following precautionary steps before installation of the NVR. -
Page 10: Hdd Installation
Quick Operation Guide of WIFI Network Video Recorder HDD Installation A HDD is required for the purpose of storage videos, logs, etc. Insert a screwdriver into the slot below the power supply interface to uninstall the cover in bottom. Slot... - Page 11 Quick Operation Guide of WIFI Network Video Recorder Insert the 2.5-inch HDD into the HDD slot as the direction shown below. Install the cover and lay the device properly.
-
Page 12: Main Features
Quick Operation Guide of WIFI Network Video Recorder Main Features Support establishing wired and wireless network instead of a wireless router. Support SADP automatically searching and adding active IP cameras. A build-in noiseless fan supports automatically adjusting speed. -
Page 13: Typical Application
Quick Operation Guide of WIFI Network Video Recorder Typical Application Base Station 3G/4G Phone & laptop Phone & laptop Computer WIFI Network Camera WIFI Network Camera HDMI Displayer Network Camera HDMI Cable UTP Cable... -
Page 14: Front Panel And Rear Panel
Quick Operation Guide of WIFI Network Video Recorder Front Panel and Rear Panel Front Panel Rear Panel... - Page 15 Quick Operation Guide of WIFI Network Video Recorder Name Function Description LAN Interface 3 RJ-45 10 /100Mbps network interfaces for LAN (1 ~ 3) (Local Area Networks). 1 RJ-45 10 /100 Mbps network interface for WAN WAN Interface (Wide Area Networks). Universal Serial Bus (USB) ports for additional devices USB Interface such as USB mouse and USB writer.
-
Page 16: Menu Operation
Quick Operation Guide of WIFI Network Video Recorder Menu Operation You can operate the NVR locally via displayer and mouse connected to NVR. Menu Structure Menu Shutdown Playback Export Manual Record Camera Maintenance Con figuration Search System Behavior Normal Normal Record General Schedule... -
Page 17: Startup And Shutdown
Quick Operation Guide of WIFI Network Video Recorder Startup and Shutdown Proper startup and shutdown procedures are crucial to expanding the life of the NVR. To start your NVR: Step: Check the power supply is plugged into an electrical outlet. It is HIGHLY recommended that an Uninterruptible Power Supply (UPS) be used in conjunction with the device. -
Page 18: Setting The Admin Password
Quick Operation Guide of WIFI Network Video Recorder Click to select the Shutdown button. Click the Yes button. Unplug the power supply on the rear panel when the attention pops up. Setting the Admin Password Purpose: For the first-time access, you need to activate the device by setting an admin password. No operation is allowed before activation. - Page 19 Quick Operation Guide of WIFI Network Video Recorder STRONG PASSWORD RECOMMENDED– We highly recommend you create a strong password of your own choosing (using a minimum of 8 characters, including upper case letters, lower case letters, numbers, and special characters) in order to increase the security of your product.
-
Page 20: Using Wizard For Basic Configurations
Quick Operation Guide of WIFI Network Video Recorder Using Wizard for Basic Configurations After admin password is set, the setup wizard pops up automatically. It can walk you through some basic settings of the NVR. Steps: If you don’t want to use the setup wizard at that moment, click the Exit button. You... - Page 21 Quick Operation Guide of WIFI Network Video Recorder can also choose to use the Setup Wizard next time by leaving the “Start wizard when the device starts?” checkbox checked. Click the Next button to enter the Date and Time Settings interface. After the time settings, click Next button which takes you to the WAN Setup Wizard window.
- Page 22 Quick Operation Guide of WIFI Network Video Recorder Click Next button to enter WIFI settings interface. Edit SSID and select Security Type. Input Network Security Key if Security Type does not set as Disable. Click Next button which takes you to the General Network Configuration window. Click Next button after you configured the general network parameters.
- Page 23 Quick Operation Guide of WIFI Network Video Recorder according to your needs. Click Next button to enter the Advanced Network Parameter interface. You can enable UPnP, enable DDNS and set other ports according to your need.
- Page 24 Quick Operation Guide of WIFI Network Video Recorder 10. After configuration finishes, click Next button to enter HDD Management interface. 11. To initialize the HDD, click the Init button. Initialization removes all the data saved...
- Page 25 Quick Operation Guide of WIFI Network Video Recorder in the HDD. 12. Click Next button. You enter the Adding IP Camera interface. 13. Click Next button to enter the IP Camera Management interface. 14. Click Search to search the online IP Camera and the Security status shows whether it is active or inactive.
-
Page 26: Login And Logout
Quick Operation Guide of WIFI Network Video Recorder 16. Click OK to complete the startup Setup Wizard. Login and Logout User Login Purpose: If NVR has logged out, you must login the device before operating the menu and other functions. Steps: Select the User Name in the dropdown list. -
Page 27: User Logout
Quick Operation Guide of WIFI Network Video Recorder Input Password. Click OK to log in. The device gets locked for 60 seconds if the admin user performs 7 failed password attempts (5 attempts for the guest/operator). User Logout Purpose: After logging out, the monitor turns to the live view mode and if you want to do some... -
Page 28: Adding Ip Cameras
Quick Operation Guide of WIFI Network Video Recorder operation, you need to enter user name and password tog in again. Steps: Enter the Shutdown menu. Menu > Shutdown Click Logout. After you have logged out the system, menu operation on the screen is invalid. It is required to input a user name and password to unlock the system. - Page 29 Quick Operation Guide of WIFI Network Video Recorder been activated. Please refer to the User Manual for activating the inactive IP camera. You can select one of the following three options to add the IP camera. Steps: Right-click the mouse when you in the live view mode to show the right-click menu. Click Add IP Camera to enter the IP Camera Management interface.
- Page 30 Quick Operation Guide of WIFI Network Video Recorder Click the button to add the camera. The online cameras with same network segment will be displayed in the camera list. The added cameras are marked in white while these have not been added are marked in yellow.
- Page 31 Quick Operation Guide of WIFI Network Video Recorder Explanation of the icons Icon Explanation Edit basic parameters of the camera Add the detected IP camera. The camera is connected. The camera is disconnected; you can click the icon to get the exception information of camera.
- Page 32 Quick Operation Guide of WIFI Network Video Recorder 2) You can edit the IP address, protocol, management port, and other information of the IP camera to be added. 3) Click Add to add the camera. 4) (For the encoders with multiple channels only) check the checkbox of Channel No.
-
Page 33: Live View
Quick Operation Guide of WIFI Network Video Recorder Live View After exit the wizard, you will enter live view interface. You can view the image of added cameras there. In the live view mode, there are icons at the upper-right corner of the screen for each channel, showing the status of the record and alarm in the channel, so that you can find problems as soon as possible. -
Page 34: Playback
Quick Operation Guide of WIFI Network Video Recorder Event/Exception (event and exception information, appears at the lower-left corner of the screen.) Playback Play back the record files of a specific channel in the live view menu. Channel switch is supported. ... - Page 35 Quick Operation Guide of WIFI Network Video Recorder Option 2: Steps: Enter the Playback menu. Right-click a channel in live view mode and select Playback from the menu. Record files of the selected channel will be played back.
- Page 36 Quick Operation Guide of WIFI Network Video Recorder Playback management. Check the channel or channels if you want to execute simultaneous playback of multiple channels. The toolbar in the bottom part of Playback interface can be used to control playing process.
- Page 37 Quick Operation Guide of WIFI Network Video Recorder...
-
Page 38: Accessing By Web Browser
Quick Operation Guide of WIFI Network Video Recorder Accessing by Web Browser You can access to the device via web browser. Before you start: Establish the connection between the NVR and Internet via the WAN interface. Establish the network connection between your computer and the NVR via wired or wireless network. - Page 39 Quick Operation Guide of WIFI Network Video Recorder 1) Set the password for the admin user account. 2) Click OK to login to the device. STRONG PASSWORD RECOMMENDED– We highly recommend you create a strong password of your own choosing (using a minimum of 8 characters, including upper case letters, lower case letters, numbers, and special characters) in order to increase the security of your product.
- Page 40 Quick Operation Guide of WIFI Network Video Recorder 1) Input the User Name and Password, and click the Login button to pop up wizard. Click OK to enable the wizard. It will lead you to configure basic configurations, including setting password, configuring WAN and WIFI parameters, initializing HDD, adding IP cameras and setting record schedule.
- Page 41 Quick Operation Guide of WIFI Network Video Recorder Click Next to enter Edit Password interface. Input Admin Password, New Admin Password and Confirm. Click Save to save the new password and click Next to enter WAN settings interface.
- Page 42 Quick Operation Guide of WIFI Network Video Recorder Set the Access Type as PPPoE, input User Name, Password and Confirm. Click Save to dial up and click Next to enter WIFI settings interface. Input the new SSID (the name of WIFI) and Key. Click Save to create WIFI and click Next to enter HDD Initialization interface.
- Page 43 IP cameras and the NVR via wired or wireless network. For details, you can refer to the before you start section in Accessing by Web Browser Hikvision WIFI IP camera which has default user name and password and is within 2m distance from the NVR will be added automatically.
-
Page 44: Live View
Quick Operation Guide of WIFI Network Video Recorder 13. Check the checkboxes of cameras to add and click OK to add them. 14. Click Next to enter Record Schedule settings interface. 15. Select the added cameras and click All-day Recording to enable recording for them. 16. - Page 45 Quick Operation Guide of WIFI Network Video Recorder Name Description Displays the list of channels and the playing and recording status of each channel. Channel List The live view stream can be switched by clicking the icon before the channel name: stands for main...
- Page 46 Quick Operation Guide of WIFI Network Video Recorder Name Description stream and for sub-stream. Live View Displays the image of channel, and multi-window Window division is supported. Pan, tilt, zoom operations are supported, as well as preset editing and calling. PTZ Control PTZ function can only be realized if the connected camera supports PTZ control.
-
Page 47: Playback
Quick Operation Guide of WIFI Network Video Recorder Icon Description Switch live view stream as main stream or sub-stream. Start/stop two-way audio Start/stop all live view Capture pictures in the live view mode Start/stop all recording Enable/disable digital zoom Previous/next page Open/close audio Adjust volume Full screen... - Page 48 Quick Operation Guide of WIFI Network Video Recorder Name Description Displays the list of channels and the playing status Channel List of each channel. Playback Window Displays the playback image. Play Control Bar Play control operations are supported.
- Page 49 Quick Operation Guide of WIFI Network Video Recorder Name Description Displays the time bar and the records marked with Time Line different colors. Playback Status Displays the playback status. Calendar You can select the date to play. Start Playback Steps: Click Playback on the menu bar to enter playback interface.
- Page 50 Quick Operation Guide of WIFI Network Video Recorder Button Description Button Description Play by single frame Stop all playback Capture Video clip Enable/disable digital Open/Close audio zoom Adjust volume Download Full screen You can drag the progress bar with the mouse to locate the exact playback point. You can also input the time in the textbox and click button to locate the playback point.
- Page 51 Quick Operation Guide of WIFI Network Video Recorder...
