- Page 1 Network Video Recorder Quick Operation Guide UD.6L0202B1954A01...
-
Page 2: Table Of Contents
Quick Operation Guide of Network Video Recorder TABLE OF CONTENTS NVR Pre-Installation ............................5 NVR Installation .............................. 5 Hard Disk Installation ............................. 5 Front Panel ............................... 9 DS-7600NI-V and DS-7600NI-VP ......................9 DS-7600NI-SN/SE Series .......................... 9 DS-7100NI Series ............................ 10 Rear Panel .............................. - Page 3 (hereinafter referred to be “the Manual”) cannot be reproduced, changed, translated, or distributed, partially or wholly, by any means, without the prior written permission of Hikvision. Unless otherwise stipulated, Hikvision does not make any warranties, guarantees or representations, express or implied, regarding to the Manual.
-
Page 4: Regulatory Information
Quick Operation Guide of Network Video Recorder Regulatory Information FCC Information FCC compliance: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. -
Page 5: Safety Instruction
Quick Operation Guide of Network Video Recorder Safety Instruction These instructions are intended to ensure that user can use the product correctly to avoid danger or property loss. The precaution measure is divided into “Warnings” and “Cautions” Warnings: Serious injury or death may occur if any of the warnings are neglected. Cautions: Injury or equipment damage may occur if any of the cautions are neglected. -
Page 6: Nvr Pre-Installation
Quick Operation Guide of Network Video Recorder Thank you for purchasing our product. If there is any question or request, please do not hesitate to contact dealer. This manual is applicable to the models listed in the following table. Series Models DS-7104NI-SL, DS-7108NI-SL DS-7100NI-SL series... - Page 7 Quick Operation Guide of Network Video Recorder Steps (for DS-7600NI-V and DS-7600NI-VP): Fasten the hard disk mounting handle to the hard disk with screws. Insert the key and turn in clockwise direction to open the panel lock. Open the front panel. Insert the hard disk along the slot until it is placed into position.
- Page 8 Quick Operation Guide of Network Video Recorder Steps (for other models): 1. Remove the cover from the NVR by unfastening the screws on the rear and side panel. 2. Connect one end of the data cable to the motherboard of NVR and the other end to the HDD. 3.
- Page 9 Quick Operation Guide of Network Video Recorder 5. Re-install the cover of the NVR and fasten screws.
-
Page 10: Front Panel
Quick Operation Guide of Network Video Recorder Front Panel DS-7600NI-V and DS-7600NI-VP Name Description HDD1/HDD2 Blinks red when data is being read from or written to HDD. Panel Lock Lock/unlock the front panel. Running Status Indicator turns yellow when system is running. Indicator Universal Serial Bus (USB) ports for additional devices such as USB Interface... -
Page 11: Ds-7100Ni Series
Quick Operation Guide of Network Video Recorder DS-7100NI Series Icon Description Indicator turns red when DVR is powered up. Indicator lights in red when data is being read from or written to HDD. Indicator blinks blue when network connection is functioning properly. -
Page 12: Rear Panel
Quick Operation Guide of Network Video Recorder Rear Panel The rear panel vaires according to different models. DS-7600NI-SN, DS-7604NI-SN/N, DS-7608 & 7616NI-SN/N DS-7600NI-SN DS-7600NI-E1/4N and DS-7604NI-SN/N DS-7608 & 7616NI-SN/N Item Description Power Supply DC 12V power supply. Audio In RCA connector for audio input. HDMI Interface HDMI video output connector. -
Page 13: Ds-7600Ni-Se And Ds-7600Ni-Se/N
Quick Operation Guide of Network Video Recorder DS-7608 & 7616NI-SN/P Item Description Power Supply 48VDC or 100~240VAC power supply. Audio In RCA connector for audio input. HDMI Interface HDMI video output connector. LAN Network Interface 1 10 /100 /1000 Mbps self-adaptive Ethernet interface Audio Out RCA connector for audio output. -
Page 14: Ds-7600Ni-Se/P
Quick Operation Guide of Network Video Recorder Item Description Network Interfaces with Network interface for the cameras. switch function (for DS-7600NI-SE/N) DS-7600NI-SE/P DS-7604NI-SE/P DS-7608NI-SE/P and DS-7616NI-SE/P Item Description Connector for LAN (Local Area Network). LAN Network Interface Connects to RS-485 devices. RS-485 Interface 100~240VAC power supply Power Supply... -
Page 15: Ds-7100Ni-Sl, Ds-7100Ni-Sn And Ds-7100Ni-Sl/W
Quick Operation Guide of Network Video Recorder Item Description Switch for turning on/off the device. Power Switch Connector for LAN (Local Area Network). LAN Network Interface Audio In RCA connector for voice talk input Ground (needs to be connected when NVR starts up). Audio Out RCA connector for audio output HDMI video output connector. -
Page 16: Ds-7100Ni-Sn/N And Ds-7100Ni-Sn/P
Quick Operation Guide of Network Video Recorder DS-7100NI-SN/N and DS-7100NI-SN/P DS-7104NI-SN/N, DS-7104NI-SN/P DS-7108 & 7116NI-SN/N, DS-7108 & 7116NI-SN/P Item Description 12VDC power supply. Power Supply Audio In RCA connector for two-way audio input. HDMI video output connector. HDMI Interface Connector for LAN (Local Area Network). Network Interface Audio Out RCA connector for audio output. -
Page 17: Specifications
Quick Operation Guide of Network Video Recorder Specifications Specifications of DS-7600NI-SN Model DS-7604NI-SN DS-7608NI-SN DS-7616NI-SN 4-ch 8-ch 16-ch IP video input Video/Audio 1-ch, RCA (2.0 Vp-p, 1kΩ) input Two-way audio input Incoming bandwidth 25Mbps 50Mbps 100Mbps Network Outgoing bandwidth 40Mbps Remote connection 1-ch, resolution: HDMI/VGA output... -
Page 18: Specifications Of Ds-7600Ni-Sn/N
Quick Operation Guide of Network Video Recorder Specifications of DS-7600NI-SN/N Model DS-7604NI-SN/N DS-7608NI-SN/N DS-7616NI-SN/N Video/Audio IP video input 4-ch 8-ch 16-ch 1-ch, RCA (2.0 Vp-p, 1kΩ) input Two-way audio input 25Mbps 50Mbps 100Mbps Incoming bandwidth Network 40Mbps Outgoing bandwidth Remote connection 1-ch, resolution: Video/Audio HDMI/VGA output... -
Page 19: Specifications Of Ds-7600Ni-Se
Quick Operation Guide of Network Video Recorder Specifications of DS-7600NI-SE Model DS-7604NI-SE DS-7608NI-SE DS-7616NI-SE IP video input 4-ch 8-ch 16-ch Video/Audio input Two-way audio 1-ch, RCA (2.0 Vp-p, 1kΩ) input Incoming 20Mbps 40Mbps 80Mbps bandwidth Bandwidth Output 40Mbps bandwidth Decoding 5MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/ resolution 2CIF/CIF/QCIF... -
Page 20: Specifications Of Ds-7600Ni-Se/N
Quick Operation Guide of Network Video Recorder Specifications of DS-7600NI-SE/N Model DS-7604NI-SE/N DS-7608NI-SE/N DS-7616NI-SE/N IP video input 4-ch 8-ch 16-ch Video/Audio input Two-way audio 1-ch, RCA (2.0 Vp-p, 1kΩ) input Incoming 20Mbps 40Mbps 80Mbps bandwidth Bandwidth Output 40Mbps bandwidth Decoding 5MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF resolution 1-ch, resolution:... -
Page 21: Specifications Of Ds-7600Ni-Se/P
Quick Operation Guide of Network Video Recorder Specifications of DS-7600NI-SE/P Model DS-7604NI-SE/P DS-7608NI-SE/P DS-7616NI-SE/P IP video input 4-ch 8-ch 16-ch Video/Audio input 1-ch, RCA (2.0 Vp-p, 1kΩ) Two-way audio input Incoming bandwidth 20Mbps 40Mbps 80Mbps Network Output bandwidth 40Mbps Remote connection Recording resolution 5MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF 1-ch, resolution:... -
Page 22: Specifications Of Ds-7600Ni-V
Quick Operation Guide of Network Video Recorder Specifications of DS-7600NI-V Model DS-7604NI-V DS-7608NI-V DS-7616NI-V IP video input 4-ch 8-ch 16-ch Video/Audio input Two-way audio 1-ch, RCA (2.0 Vp-p, 1kΩ) input Incoming 20Mbps 40Mbps 80Mbps bandwidth Bandwidth Output bandwidth 40Mbps Decoding 5MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF resolution 1-ch, resolution:... -
Page 23: Specifications Of Ds-7600Ni-Vp
Quick Operation Guide of Network Video Recorder Specifications of DS-7600NI-VP Model DS-7604NI-VP DS-7608NI-VP DS-7616NI-VP IP video input 4-ch 8-ch 16-ch Video/Audio input Two-way audio 1-ch, RCA (2.0 Vp-p, 1kΩ) input Incoming 20Mbps 40Mbps 80Mbps bandwidth Network Output bandwidth 40Mbps Remote connection Recording 5MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF resolution... -
Page 24: Specifications Of Ds-7600Ni-Sn/P
Quick Operation Guide of Network Video Recorder Specifications of DS-7600NI-SN/P Model DS-7604NI-SN/P DS-7608NI-SN/P DS-7616NI-SN/P Video/Audio IP video input 4-ch 8-ch 16-ch 1-ch, RCA (2.0 Vp-p, 1kΩ) input Two-way audio input 50Mbps 100Mbps Incoming bandwidth 25Mbps Network Outgoing bandwidth 40Mbps Remote connection 1-ch, resolution: Video/Audio HDMI/VGA output... -
Page 25: Specifications Of Ds-7100Ni-Sl
Quick Operation Guide of Network Video Recorder Specifications of DS-7100NI-SL Model DS-7104NI-SL DS-7108NI-SL 4-ch 8-ch IP video input Video/Audio input 1-ch, RCA (2.0 Vp-p, 1kΩ) Two-way audio input Incoming bandwidth 25Mbps 50Mbps Network Outgoing bandwidth 40Mbps Remote connection 1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF Recording resolution 1-ch, resolution: HDMI/VGA output 1920 ×... -
Page 26: Specifications Of Ds-7100Ni-Sl/W
Quick Operation Guide of Network Video Recorder Specifications of DS-7100NI-SL/W Model DS-7104NI-SL/W 4-ch IP video input Video/Audio input 1-ch, RCA (2.0 Vp-p, 1kΩ) Two-way audio input Incoming bandwidth 25Mbps Network Outgoing bandwidth 40Mbps Remote connection 1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF Recording resolution 1-ch, resolution: HDMI/VGA output 1920 ×... -
Page 27: Specifications Of Ds-7100Ni-Sn
Quick Operation Guide of Network Video Recorder Specifications of DS-7100NI-SN Model DS-7104NI-SN DS-7108NI-SN DS-7116NI-SN 4-ch 8-ch 16-ch IP video input Video/Audio input 1-ch, RCA (2.0 Vp-p, 1kΩ) Two-way audio input Incoming bandwidth 25Mbps 50Mbps 100Mbps Network Outgoing bandwidth 40Mbps Remote connection 1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF Recording resolution 1-ch, resolution:... -
Page 28: Specifications Of Ds-7100Ni-Sn/N
Quick Operation Guide of Network Video Recorder Specifications of DS-7100NI-SN/N Model DS-7104NI-SN/N DS-7108NI-SN/N DS-7116NI-SN/N 4-ch 8-ch 16-ch IP video input Video/Audio input 1-ch, RCA (2.0 Vp-p, 1kΩ) Two-way audio input Incoming bandwidth 25Mbps 50Mbps 100Mbps Network Outgoing bandwidth 40Mbps Remote connection 1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF Recording resolution 1-ch, resolution:... -
Page 29: Specifications Of Ds-7100Ni-Sn/P
Quick Operation Guide of Network Video Recorder Specifications of DS-7100NI-SN/P Model DS-7104NI-SN/P DS-7108NI-SN/P DS-7116NI-SN/P 4-ch 8-ch 16-ch IP video input Video/Audio 1-ch, RCA (2.0 Vp-p, 1kΩ) input Two-way audio input 25Mbps 50Mbps 100Mbps Incoming bandwidth Network Outgoing bandwidth 40Mbps Remote connection Recording resolution 1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF 1-ch, resolution:... -
Page 30: Hdd Storage Calculation Chart
Quick Operation Guide of Network Video Recorder HDD Storage Calculation Chart The following chart shows an estimation of storage space used based on recording at one channel for an hour at a fixed bit rate. Bit Rate Storage Used 128K 160K 192K 224K... -
Page 31: Menu Operation
Quick Operation Guide of Network Video Recorder Menu Operation Menu Structure The menu structure of NVR is as follows: Menu Playback Maintenance Shutdown Export Manual Record Camera Configuration Normal Normal Record General Schedule Camera General System Info Logout Event Event Alarm Advanced Parameters... -
Page 32: Setting The Admin Password
Quick Operation Guide of Network Video Recorder Select the Shutdown button. Click the Yes button. Turn off the power switch on the rear panel when the attention pops up. Setting the Admin Password Purpose: For the first-time access, you need to activate the device by setting an admin password. No operation is allowed before activation. -
Page 33: Login And Logout
Quick Operation Guide of Network Video Recorder Login and Logout User Login Purpose: If NVR has logged out, you must login the device before operating the menu and other functions. Steps: Select the User Name in the dropdown list. Input Password. Click OK to log in. -
Page 34: Adding Ip Cameras
Quick Operation Guide of Network Video Recorder Click Logout. After you have logged out the system, menu operation on the screen is invalid. It is required to input a user name and password to unlock the system. Adding IP Cameras You should add and configure the online IP cameras to enable the live view and recording function. -
Page 35: Live View
Quick Operation Guide of Network Video Recorder Explanation of the icons Icon Explanation Icon Explanation Edit basic parameters of the camera Add the detected IP camera. The camera is disconnected; you can The camera is connected. click the icon to get the exception information of camera. -
Page 36: Recording
Quick Operation Guide of Network Video Recorder Alarm (video loss, tampering, motion detection or sensor alarm) Record (manual record, continuous record, motion detection or alarm triggered record) Alarm & Record Event/Exception (event and exception information, appears at the lower-left corner of the screen.) The Alarm, Motion &... - Page 37 Quick Operation Guide of Network Video Recorder Only record files recorded during the past five minutes on this channel will be played back. Option 2: Steps: 1. Enter the Playback menu. Mouse: right click a channel in live view mode and select Playback from the menu. Front Panel (not applicable for the DS-7100NI and DS-7600NI series): press PLAY button to play back record files of the channel under single-screen live view.
-
Page 38: Backup
Quick Operation Guide of Network Video Recorder Just check the channel or channels if you want to switch playback to another channel or execute simultaneous playback of multiple channels. The reverse playback is not supported by DS-7100NI-SN series NVR. Backup Recorded files can be backed up to various devices, such as USB flash drives, USB HDDs or a DVD writer. -
Page 39: Accessing By Web Browser
Quick Operation Guide of Network Video Recorder Choose the recording file in Export interface and click button to check it. Accessing by Web Browser Logging In You can get access to the device via web browser. You may use one of the following listed web browsers: Internet Explorer 6.0, Internet Explorer 7.0, Internet Explorer 8.0, Internet Explorer 9.0, Internet Explorer 10.0, Apple Safari, Mozilla Firefox, and Google Chrome. -
Page 40: Live View
Quick Operation Guide of Network Video Recorder Install the plug-in before viewing the live video and managing the camera. Please follow the installation prompts to install the plug-in. You may have to close the web browser to finish the installation of the plug-in. Live View The live view interface appears by default when you log in the device. -
Page 41: Recording
Quick Operation Guide of Network Video Recorder Name Description PTZ function can only be realized if the connected camera supports PTZ control. Video Parameters Brightness, contrast, saturation and hue of the image can be edited. Configuration The PTZ control is supported by DS-7600NI-SE series NVR only. Start Live View Steps: In the live view window, select a playing window by clicking the mouse. - Page 42 Quick Operation Guide of Network Video Recorder The Alarm, Motion & Alarm, Motion | Alarm recording types are not supported by the DS-7100NI-SL(/W) series NVR. Choose the day in a week to configure scheduled recording. Click Edit to edit record schedule. Configure All Day or Customize Record: ...
-
Page 43: Playback
Quick Operation Guide of Network Video Recorder Playback The playback interface may differ according to different models. Interface Introduction Name Description Channel List Displays the list of channels and the playing status of each channel. Playback Window Displays the image of channel. Play Control Bar Play control operations are supported. -
Page 44: Log
Quick Operation Guide of Network Video Recorder You can drag the progress bar with the mouse to locate the exact playback point. You can also input the time in the textbox and click button to locate the playback point. The color of the video on the progress bar stands for the different video types. The reverse playback is not supported by DS-7100NI-SN series NVR. - Page 45 Quick Operation Guide of Network Video Recorder...
