Network PT Dome Camera
Quick Start Guide
UD04331B
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UD04331B and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for HIKVISION UD04331B

Summary of Contents for HIKVISION UD04331B

  • Page 1 Network PT Dome Camera Quick Start Guide UD04331B...
  • Page 2 Any and all information, including, among others, wordings, pictures, graphs are the properties of Hangzhou Hikvision Digital Technology Co., Ltd. or its subsidiaries (hereinafter referred to be “Hikvision”). This user manual (hereinafter referred to be “the Manual”) cannot be reproduced, changed, translated, or distributed, partially or wholly, by any means, without the prior written permission of Hikvision.
  • Page 3 LOSS OF BUSINESS PROFITS, BUSINESS INTERRUPTION, OR LOSS OF DATA OR DOCUMENTATION, IN CONNECTION WITH THE USE OF THIS PRODUCT, EVEN IF HIKVISION HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. REGARDING TO THE PRODUCT WITH INTERNET ACCESS, THE USE OF PRODUCT SHALL BE WHOLLY AT YOUR OWN RISKS.
  • Page 4 Network PT Dome Camera·Quick Start Guide IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE APPLICABLE LAW, THE LATER PREVAILS. Regulatory Information FCC Information FCC compliance: This equipment has been tested and found to comply with the limits for a digital device, pursuant to part 15 of the FCC Rules.
  • Page 5 Network PT Dome Camera·Quick Start Guide 2012/19/EU (WEEE directive): Products marked with this symbol cannot be disposed of as unsorted municipal waste in the European Union. For proper recycling, return this product to your local supplier upon the purchase of equivalent new equipment, or dispose of it at designated collection points.
  • Page 6 Network PT Dome Camera·Quick Start Guide Warnings Follow these Cautions Follow these safeguards to prevent precautions to prevent serious injury or death. potential injury or material damage. Warnings ● Proper configuration of all passwords and other security settings is the responsibility of the installer and/or end-user. ●...
  • Page 7 Network PT Dome Camera·Quick Start Guide ● If smoke, odor or noise rise from the device, turn off the power at once and unplug the power cable, and then please contact the service center. Cautions ● Make sure the power supply voltage is correct before using the camera.
  • Page 8 Network PT Dome Camera·Quick Start Guide ● While in delivery, the camera shall be packed in its original packing, or packing of the same texture. ● Regular part replacement: a few parts (e.g. electrolytic capacitor) of the equipment shall be replaced regularly according to their average enduring time.

  • Page 9: Table Of Contents

    Network PT Dome Camera·Quick Start Guide Table of Contents 1 Appearance Description ............... 10 1.1 Overview ............... 10 1.2 Installing the Micro SD Card .......... 11 1.3 WPS Connection............13 2 Installation ..................14 2.1 Ceiling Mounting ............15 2.2 Ceiling Mounting with a Junction Box ......19 2.3 Wall Mounting ..............

  • Page 10: Appearance Description

    Network PT Dome Camera·Quick Start Guide 1 Appearance Description Please refer to the chapter below to have a close eye on the camera appearance and components. 1.1 Overview Figure 1-1 Overview (1) DC12V IN SD RST/WPS Figure 1-2 Overview (2)

  • Page 11: Installing The Micro Sd Card

    Network PT Dome Camera·Quick Start Guide Table 1-1 Description Description Power Supply Interface (12 VDC) Audio In/Out Alarm In/Out 10M / 100M self-adaptive Ethernet interface & PoE Micro SD/ SDHC/SDXC card slot WPS (Wi-Fi Protected Setup) / Reset Button The figures shown in this manual are for reference only. The appearance and interfaces of the camera are subject to the actual model.
  • Page 12 Network PT Dome Camera·Quick Start Guide RST/WPS Micro SD Figure 1-3 Install the SD Card Press RESET about 10s when the camera is powering on or rebooting to restore the default settings, including the user name, password, IP address, port No., and so on. Move the cover back and press to secure the cover.

  • Page 13: Wps Connection

    Network PT Dome Camera·Quick Start Guide 1.3 WPS Connection A wireless router with the WPS function is required to if you want to enable the WPS function of the camera. Follow the steps below to establish a WPS connection. 1. Press the WPS button on the router. 2.

  • Page 14: Installation

    Network PT Dome Camera·Quick Start Guide 2 Installation Before you start: ● Make sure the device in the package is in good condition and all the assembly parts are included. ● The standard power supply is 12V DC or 24V AC, please make sure your power supply matches with your camera.

  • Page 15: Ceiling Mounting

    Network PT Dome Camera·Quick Start Guide 2.1 Ceiling Mounting Steps: 1. Stick the supplied drill template on the ceiling. 2. Drill the cable hole and screw holes according to the drill template. 3. Hammer the expansion plugs to the screw holes. FRONT Drill Template Hole A: for cables routed through the ceiling...
  • Page 16 Network PT Dome Camera·Quick Start Guide Front Joint Figure 2-2 Adapter Plate Figure 2-3 Install the Adapter Plate...
  • Page 17 Network PT Dome Camera·Quick Start Guide 6. Route the cables through the cable hole and connect the corresponding cables including power cable, network cable, alarm cables, and audio cables. 7. Align the notches on the camera with those on the adapter plate, and rotate the camera clockwise to secure the camera with the adapter plate.
  • Page 18 Network PT Dome Camera·Quick Start Guide Figure 2-5 PTZ Control Interface 0° ~ 75° -90° ~ +90° Figure 2-6 Adjust Surveillance Angel...

  • Page 19: Ceiling Mounting With A Junction Box

    Network PT Dome Camera·Quick Start Guide 2.2 Ceiling Mounting with a Junction Box You have to buy a junction box separately if you want to install the camera with a junction box. Steps: 1. Stick the drill temperate to the ceiling. 2.
  • Page 20 Network PT Dome Camera·Quick Start Guide Figure 2-8 Hammer the Screws 6. Align two joints of the junction box to the two inserted screws, and rotate the junction box counterclockwise to fix the junction box. 7. Use the other two screws to secure the junction box. Figure 2-9 Install the Junction Box...

  • Page 21: Wall Mounting

    Network PT Dome Camera·Quick Start Guide 8. Connect the power cable, network cable, alarm cable and audio cable. 9. Align the notches on the camera with the joints on the junction box, and rotate the camera clockwise to secure the camera. Side Outlet OPEN LOCK...
  • Page 22 Network PT Dome Camera·Quick Start Guide 2. Rotate the adapter plate counterclockwise on the bottom of the camera to remove the adapter plate. 3. Fix the adapter plate to the wall mount with the supplied screws. Align the No.2 screw holes on the adapter plate with the No.2 screw holes on the wall mount, and align the cable holes as well when installing the adapter plate.
  • Page 23 Network PT Dome Camera·Quick Start Guide OPEN LOCK Figure 2-12 Install the Camera 6. Align the bracket base to the wall, and hammer the expansion plugs to the wall. 7. Fix the bracket base with the supplied expansion screws.
  • Page 24 Network PT Dome Camera·Quick Start Guide Bracket Base Figure 2-13 Fix the Bracket Base to the Wall 8. Route the cables. 9. Fix the camera to the bracket base with the supplied screws in the wall mount package. Figure 2-14 Fix the Camera 10.

  • Page 25: Routing The Cable Through Side Outlet

    Network PT Dome Camera·Quick Start Guide 2.4 Routing the Cable through Side Outlet You may select to route the cables through the side outlet, please follow the steps below. 1. Pull up the cap of the wiring duct to remove the cap. Figure 2-15 Remove the Cap 2.

  • Page 26: Setting The Network Camera Over The Lan

    Network PT Dome Camera·Quick Start Guide 3 Setting the Network Camera over the Note: You shall acknowledge that the use of the product with Internet access might be under network security risks. For avoidance of any network attacks and information leakage, please strengthen your own protection.

  • Page 27: Activating The Camera

    Network PT Dome Camera·Quick Start Guide Activating the Camera You are required to activate the camera first by setting a strong password for it before you can use the camera. Activation via Web Browser, Activation via SADP, and Activation via Client Software are all supported.

  • Page 28: Activation Via Sadp Software

    Network PT Dome Camera·Quick Start Guide Figure 3-3 Activation Interface(Web) 3. Create a password and input the password into the password field. STRONG PASSWORD RECOMMENDED– We highly recommend you create a strong password of your own choosing (using a minimum of 8 characters, including upper case letters, lower case letters, numbers, and special characters) in order to increase the security of your product.
  • Page 29 Network PT Dome Camera·Quick Start Guide Get the SADP software from the supplied disk or the official website, and install the SADP according to the prompts. Follow the steps to activate the camera. Steps: 1. Run the SADP software to search the online devices. 2.

  • Page 30: Modifying The Ip Address

    Network PT Dome Camera·Quick Start Guide STRONG PASSWORD RECOMMENDED– We highly recommend you create a strong password of your own choosing (using a minimum of 8 characters, including upper case letters, lower case letters, numbers, and special characters) in order to increase the security of your product.
  • Page 31 Network PT Dome Camera·Quick Start Guide Steps: 1. Run the SADP software. 2. Select an active device. 3. Change the device IP address to the same subnet with your computer by either modifying the IP address manually or checking the checkbox of Enable DHCP. Figure 3-5 Modify the IP Address...
  • Page 32 Network PT Dome Camera·Quick Start Guide Note: You can enable the Hik-Connect service for the device during activation. Refer to Chapter 5.1 for detailed information. 4. Input the admin password and click Modify to activate your IP address modification. The batch IP address modification is supported by the SADP. Refer to the user manual of SADP for details.

  • Page 33: Accessing Via Web Browser

    Network PT Dome Camera·Quick Start Guide 4 Accessing via Web Browser System Requirement: Operating System: Microsoft Windows XP SP1 and above version CPU: 2.0 GHz or higher RAM: 1G or higher Display: 1024×768 resolution or higher Web Browser: Internet Explorer 8.0 and above version, Apple Safari 5.0.2 and above version, Mozilla Firefox 5.0 and above version and Google Chrome 18 and above version Steps:...
  • Page 34 Network PT Dome Camera·Quick Start Guide 4. Click Login. Figure 4-1 Login Interface 5. Install the plug-in before viewing the live video and managing the camera. Follow the installation prompts to install the plug-in. Note: You may have to close the web browser to finish the installation of the plug-in.

  • Page 35: Operating Via Hik-Connect App

    Network PT Dome Camera·Quick Start Guide 5 Operating via Hik-Connect App Purpose: Hik-Connect is an application for mobile devices. With the App, you can view live image of the camera, receive alarm notification and so Note: Hik-Connect service is not supported by certain camera models. Enable Hik-Connect Service on Camera Purpose: Hik-Connect service should be enabled on your camera before using...

  • Page 36: Enable Hik-Connect Service Via Web Browser

    Network PT Dome Camera·Quick Start Guide Figure 5-1 Verification Code Setting (SADP) Note: The verification code is required when you add the camera to Hik-Connect app. 3. Click and read "Terms of Service" and "Privacy Policy". 4. Confirm the settings. 5.1.2 Enable Hik-Connect Service via Web Browser Before you start:...
  • Page 37 Network PT Dome Camera·Quick Start Guide Steps: 1. Access the camera via web browser. Refer to Chapter 4. 2. Enter platform access configuration interface: Configuration > Network > Advanced Settings > Platform Access Figure 5-2 Platform Access Configuration (Web) 3. Select Platform Access Mode as Hik-Connect. 4.

  • Page 38: Hik-Connect Setup

    Network PT Dome Camera·Quick Start Guide Hik-Connect Setup Steps: 1. Download and install the Hik-Connect app by searching “Hik-Connect” in App Store or Google Play 2. Launch the app and register for a Hik-Connect user account. 3. Log in Hik-Connect app after registration. Adding Camera to Hik-Connect Before you start: You need to enable the Hik-Connect service on camera before...
  • Page 39 Network PT Dome Camera·Quick Start Guide You can find the QR code on the camera or on the cover of the Quick Start Guide of the camera in the package. Figure 5-4 Scan QR Code Note: If the QR code is missing or too blur to be recognized, you can also add the camera by tapping the icon and inputting the camera's serial number.

  • Page 40: Initializing The Memory Card

    Network PT Dome Camera·Quick Start Guide Initializing the Memory Card Steps: Check the memory card status by tapping on the Storage Status in the Device Settings interface. If the memory card status displays as Uninitialized, tap to initialize it. The status will then change to Normal. You can then start recording any event triggered video in the camera such as motion detection.
