Pulsar RSFUPS116 Quick Start Manual


DC 54V uninterruptible power supply of 16 IP cameras

16 PoE ports 10/100 Mb/s, (1÷16 ports) (data and
power supply)

2 ports 10/100/1000 Mb/s (G1/TP, G2/TP2 ports)

2 ports 10/100/1000 Mb/s SFP (G1/SFP, G2/SFP ports)

battery charging and maintenance control

excessive discharging (UVP) protection

battery charge current: 0,5A
(batteries 4x7Ah / 4x17Ah)

Approximate backup time: 5h 15min
CONTENTS
1. Technical description.
1.1 General description
1.2 Block diagram
1.3 Description of components and connectors
1.4 Specifications
2. Installation.
2.1 Requirements
2.2 Installation procedure
3. Indication of the device operation
4. Operation and use.
4.1 Overload or short circuit of the PSU output (SCP on)
4.2 Disconnection of discharged battery
4.3. Maintenance
RSFUPS116
RSFUPS116 16-ports switch with buffer power supply
for 16 IP cameras, RACK
Edition: 3 from 02.07.2018
Supercedes the edition: 2 from 15.11.2017
Features
:
Example of use.
1
v1.1
mounted
 battery output protection against short circuit
and reverse connection
 30W for each PoE port, supports devices
complaint with the IEEE802.3af/at (PoE+)
standard
 Supports auto-learning and auto-aging of MAC
addresses (16K size)
 LED indication
 Metal enclosure RACK 19" 2U
- color: black RAL 9005
 warranty – 2 year from the production date
EN
