SERVICE INFORMATION
Repair manual, exciter CR 3 from 2008
Last update September 2016
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the CR 3 and is the answer not in the manual?

Questions and answers

Related Manuals for Weber mt CR 3

Summary of Contents for Weber mt CR 3

  • Page 1 SERVICE INFORMATION Repair manual, exciter CR 3 from 2008 Last update September 2016...
  • Page 2 SERVICE INFORMATION Repair manual, exciter CR 3 from 2008 Introduction Carefully read the repair manual all the way through before starting work. Carefully follow all instructions and always execute the described activities in the specified sequence. The safety requirements prescribed for repair tasks must be complied with to prevent personal injury and / or material damage.
  • Page 3 SERVICE INFORMATION Repair manual, exciter CR 3 from 2008 Dismantling Unscrew the fastening screws of the exciter housing cover. Do not reuse screws and Nordlock lock rings! Remove the O-ring. Do not reuse the O-ring. Remove the fastening screws of the cylinder cover.
  • Page 4 SERVICE INFORMATION Repair manual, exciter CR 3 from 2008 Screw the hex screw M8 x 40mm into the cylinder cover. Force off the cylinder cover and expose the operating piston. Remove the paper seal. Paper seal must be replaced! Unscrew the fastening screws of the cover.
  • Page 5 SERVICE INFORMATION Repair manual, exciter CR 3 from 2008 Screw hex screws M8 x 40 mm into the cover. Force off the cover and remove the paper seal. Paper seal must be replaced! Remove the fastening screw of the V-belt pulley.
  • Page 6 SERVICE INFORMATION Repair manual, exciter CR 3 from 2008 Screw hex screws M8 x 40 into the V-belt pulley and force off the V-belt pulley. Unscrew the fastening screws of the cover. Screw hex screws M8 x 40 mm into the cover.
  • Page 7 SERVICE INFORMATION Repair manual, exciter CR 3 from 2008 Unscrew the fastening screws of the cover. Screw hex screws M8 x 40 mm into the cover. Force off the cover and remove the paper seal. Paper seal must be replaced! Loosen the lock ring on the adjusting eccentric shaft and take it out.
  • Page 8 SERVICE INFORMATION Repair manual, exciter CR 3 from 2008 Take the washer and spring out of the adjusting eccentric shaft. The washer could be pushed out by the spring after loosening the lock ring. Unscrew the headless set screw for the fastening of the straight pin.
  • Page 9 SERVICE INFORMATION Repair manual, exciter CR 3 from 2008 Remove the lock ring of the piston. Carefully knock the piston down from the adjusting bolt with a soft face hammer. Remove the lock ring. Knock the adjusting bolt out of the bearings with...
  • Page 10 SERVICE INFORMATION Repair manual, exciter CR 3 from 2008 Straight pin Adjusting bolt Deep-groove ball bearing 4 + 5 Lock rings 6 + 7 Piston and piston seal Lock screw Place the mounting sleeve on the adjusting eccentric shaft to knock the opposite bearing out of the exciter housing.
  • Page 11 SERVICE INFORMATION Repair manual, exciter CR 3 from 2008 Place the mounting sleeve on the fixed eccentric shaft to knock the opposite bearing out of the exciter housing. Cylindrical roller bearing falls onto the floor plate when knocked out. Take the fixed eccentric shaft out of the exciter housing.
  • Page 12 SERVICE INFORMATION Repair manual, exciter CR 3 from 2008 Place the fixed eccentric shaft in a vice and remove the bearing ring with a bearing puller. Remove the second bearing ring of the fixed eccentric shaft with the bearing puller.
  • Page 13 SERVICE INFORMATION Repair manual, exciter CR 3 from 2008 Use a soft face hammer to knock the adjusting eccentric shaft out of the adjusting bush. Remove the lock ring. Knock the ball bearing out of the adjusting bush with a single punch.
  • Page 14 SERVICE INFORMATION Repair manual, exciter CR 3 from 2008 Assembly Insert the ball bearing in the adjusting bush and use the mounting sleeve and soft face hammer to knock it into the adjusting bush. Mount the lock ring of the ball bearing.
  • Page 15 SERVICE INFORMATION Repair manual, exciter CR 3 from 2008 Mount the lock ring of adjusting eccentric shaft. Mount the adjusting eccentric shaft to the stop. Mount the inner bearing ring. Mount the bearing ring on the fixed eccentric shaft with the mounting sleeve and soft face hammer.
  • Page 16 SERVICE INFORMATION Repair manual, exciter CR 3 from 2008 Knock the cylindrical roller bearing into the exciter housing with the mounting sleeve. Insert the fixed eccentric shaft. When mounting the fixed eccentric shaft ensure that the orientation is correct. The fixed eccentric...
  • Page 17 SERVICE INFORMATION Repair manual, exciter CR 3 from 2008 Place the V-belt pulley on the fixed eccentric shaft. The fastening screw must have a through-bore. It is used to vent the exciter. Fasten the V-belt pulley with the vent screw.
  • Page 18 SERVICE INFORMATION Repair manual, exciter CR 3 from 2008 Insert the adjusting eccentric shaft. When inserting the adjusting eccentric shaft ensure that the gears are mounted in such a manner that the markings are aligned. On the other side, use the mounting sleeve to knock the second cylindrical roller bearing of the adjusting eccentric shaft into the exciter housing.
  • Page 19 SERVICE INFORMATION Repair manual, exciter CR 3 from 2008 Secure the bearing with the lock ring. Mount the piston seal of the piston. The open side of the piston seal must, as shown, point up during assembly. Knock the adjusting bolt into the piston with a soft face hammer.
  • Page 20 SERVICE INFORMATION Repair manual, exciter CR 3 from 2008 Introduce the adjusting bolt into the adjusting eccentric shaft. Insert the straight pin into the adjusting bush. When mounting the straight pin ensure that the milled surface points away from the gear.
  • Page 21 SERVICE INFORMATION Repair manual, exciter CR 3 from 2008 Introduce the spring into the adjusting eccentric shaft. Secure the spring with washer and lock ring. Mount the cover with paper seal. Paper seal 020013269 Mount the cover with paper seal.
  • Page 22 SERVICE INFORMATION Repair manual, exciter CR 3 from 2008 Mount the cylinder cover with paper seal. Paper seal 020013269 Mount the vent screw with copper washer. Copper washer 025008012 DIN7603-10x16x1 Vent screw 025030016 DIN910-M10x1 Insert the O-ring. O-ring 020013302 Only use new housing screws and new Nordlock lock rings for assembly.
  • Page 23 SERVICE INFORMATION Repair manual, exciter CR 3 from 2008 Fasten the exciter housing cover with ten screws. Important: After assembling the exciter, fill the exciter housing with the specified oil and oil quantities: Oil types: Fully synthetic gear oil API-GL-5 / GL4, e.
