SUMAKE
Trigger Start-Shut Off Air Wrench (Alu.)
Vibration
MODEL
EN ISO 28927-2
No Load: 0.434 m/s 2
AWP48
No Load: 0.434 m/s 2
AWP50
No Load: 0.434 m/s 2
AWP55
No Load: 0.434 m/s 2
AWP60
No Load: 0.434 m/s 2
AWP65
No Load: 0.434 m/s 2
AWP68
Uncertainty K= 1.5 m/s²
SUMAKE INDUSTRIAL CO., LTD
4F,NO.351,Yangguang St.,Neihu District TAIPEI, TAIWAN, ZIP:114-91
.
PNEUMATIC TOOLS
Noise : EN ISO 15744
Sound pressure level
No Load: 81.84 dB(A)
No Load: 81.84 dB(A)
No Load: 81.84 dB(A)
No Load: 81.84 dB(A)
No Load: 81.84 dB(A)
No Load: 81.84 dB(A)
Uncertainty K= 3dB
Sound power level
1-
No Load: 92.84 dB(A)
No Load: 92.84 dB(A)
No Load: 92.84 dB(A)
2-
No Load: 92.84 dB(A)
No Load: 92.84 dB(A)
No Load: 92.84 dB(A)
AWP48(50)(55)(60)(65)(68)-S-1507A-MIF
Safety Instructions
Warning
Read this manual and
understand all safety
instructions before operation
the tool.
Wear an approved
ear-protector and gloves while
operating tool.
