IMPORTANT!
Read all instructions in this manual before operating pump.
As a result of Crane Pumps & Systems, Inc., constant product improvement program,
product changes may occur. As such Crane Pumps & Systems reserves the right to
change product without prior written notification.
A Crane Co. Company
420 Third Street
Piqua, Ohio 45356
Phone: (937) 778-8947
Fax: (937) 773-7157
www.cranepumps.com
INSTALLATION MANUAL
Fixed Discharge Upgrade Core
Series: OGP2022CM
2 HP, 3450 RPM, 60 Hz.
Fits into F.E. Myers;
SRA-125 or SRA-125CV
Lift Out Package
This product may be covered by one or more of
the following patents and other patent(s) pending:
US Patent 7,357,341 & 7,578,657
83 West Drive, Bramton
Ontario, Canada L6T 2J6
Phone: (905) 457-6223
Fax: (905) 457-2650
®
Form No. 141496-Rev. D
Advertisement
Table of Contents
Related Manuals for Crane BARNES PS OGP2022CM Series
Summary of Contents for Crane BARNES PS OGP2022CM Series
- Page 1 Read all instructions in this manual before operating pump. As a result of Crane Pumps & Systems, Inc., constant product improvement program, product changes may occur. As such Crane Pumps & Systems reserves the right to change product without prior written notification. A Crane Co. Company...
-
Page 2: Table Of Contents
START-UP REPORT .........................15 - 16 Other brand and product names are trademarks or registered trademarks of their respective holders. ® Barnes is a registered trademark of Crane Pumps & Systems, Inc © Crane Pumps & Systems, Inc. 2003, 2/2006, 9/06... -
Page 3: Safety First
Other brand and product names are trademarks or registered trademarks of their respective holders. ® Barnes is a registered trademark of Crane Pumps & Systems Inc. 1/2005, 8/05, 12/05, 1/06, 9/06 Alteration Rights Reserved... -
Page 4: User Guide
USER GUIDE The grinder pump Congratulations on generates sufficient your purchase of a Barnes UltraGRIND™ grinder pressure to pump this slurry from your home to pump system. With proper care and by following the wastewater plant. a few simple guidelines your grinder pump will give you many years of dependable service. -
Page 5: Specifications
PUMP SPECIFICATIONS: DISCHARGE ....... 1¼” Horizontal, Bolt-on Flange CORD ........CSA/UL Approved 12/5, Type SOW LIQUID TEMPERATURE ..104°F (40°C) Continuous SPEED ........ 3450 RPM, 60Hz MOTOR HOUSING ..... Cast Iron ASTM A-48, Class 30 UPPER BEARING: VOLUTE ......Cast Iron ASTM A-48, Class 30 Design ..... -
Page 6: Installation
Barnes representative or • Consult local officials for any applicable codes and Crane Pumps & Systems, Inc., Service Department in regulations. Piqua, Ohio, telephone (937) 778-8947 or in Brampton, • Make sure you have the necessary equipment and Ontario, Canada (905) 457-6223. -
Page 7: Electrical Connections
ELECTRICAL CONNECTIONS: Pump Cables - The cord assembly mounted to the pump must NOT be modified in any way except for shortening to a specific application. Any splice between the pump and the control panel must be made in accordance with the National Electric Code or the Canadian Electric Code and all applicable state, province and local electric codes. - Page 8 FIGURE 5 STEPS & TIPS: • Install power cord and jumper plug to pump. Install level control cord to ESPS switch. Make sure alignment mark on cord aligns with alignment mark on terminal block. • See ESPS manual for level control wiring. •...
- Page 9 FIGURE 6 STEPS & TIPS: • Attach the chain using the provided shackles to the side of the motor housing and the eye bolt on top of the pump. • Attach shackle and rope to the chain to ensure the pump has a 10-degree forward tilt.
-
Page 10: Exploded View (Fig. 10)
FIGURE 7... -
Page 11: Parts List
PARTS LIST ITEM PART NO. DESCRIPTION 119525 PUMP, OGP2022C 118794 CHECK VALVE HOUSING 118252 CHECK VALVE FLAPPER 122891 FLAPPER BASE 26322 WASHER,LOCK,5/16" 2-23030-50 SHCS,5/16-18 X 1.25" 1-156-1 SCREW,HXH,5/16-17 X 1.00" 625-01558 O-RING 141179 DICHARGE ELBOW 121675E ESPS-100,FLAT-BOTTOM 131835 ESPS Base 113288 ESPS Cord 123082... - Page 12 Notes...
-
Page 13: Warranty
Crane Pumps & Systems, Inc. Distributor. RETURNED GOODS RETURN OF MERCHANDISE REQUIRES A “RETURNED GOODS AUTHORIZATION”. CONTACT YOUR LOCAL CRANE PUMPS & SYSTEMS, INC. DISTRIBUTOR. Products Returned Must Be Cleaned, Sanitized, Or Decontaminated As Necessary Prior To Shipment, To Insure That Employees Will Not Be Exposed To Health Hazards In Handling Said Material.
