The Defibtech RMU-2000 ACC (continued)
1. User Control Panel. The User Control
Panel contains the user interface for the
RMU-2000 ACC system.
2. Compression Module. The Compression
Module contains all the therapeutic
components of the RMU-2000 ACC
system, including the piston drive
mechanism, the control electronics, the
User Control Panel, and the Battery Pack
interface.
3. Serial Number. The serial number can be
found on the Compression Module.
4. External Power Input. The External
Power Input jack is used to connect an
external power adapter to operate the unit
(with a Battery Pack installed) or to charge
the Battery Pack.
5. USB Port. The USB Port is located on
the bottom of the Compression Module. It
allows the Module to be directly connected
to a personal computer and for RMU-2000
ACC data retrieval and event reporting
when used in conjunction with utility
software available at www.defibtech.com.
It is not intended to be used during rescue
operation.
Note: A Bluetooth ON/OFF button on
®
the User Control Panel (item 1) allows for
wireless connection between the Module
and the PC.
6. Patient Wrist Straps. The Patient Wrist
Straps are used to attach a patient's arms to
the RMU-2000 ACC for ease of transporting
the patient and the RMU-2000 ACC. To
maximize the available time to perform a
rescue, Defibtech recommends that the
Patient Wrist Straps be affixed to the Frame
(item 7) prior to a rescue.
7. Frame. The Frame attaches to the
Backboard and holds the Compression
Module. It is used to maintain the
Compression Module's position over the
patient.
8. Stabilization Strap. The Stabilization
Strap is used to stabilize the RMU-2000
ACC while compressions are being
applied by the unit to the patient. To
maximize the available time to perform a
rescue, Defibtech recommends that the
Stabilization Strap's Frame Straps be affixed
to the Frame prior to a rescue.
9. Backboard. The Backboard is the base for
the RMU-2000 ACC system. It is placed
under the patient and provides an interface
that the Frame attaches to.
10. Backboard Latches. One on each side
of the Frame, the Backboard Latch is the
mechanism that secures the Frame to the
Backboard.
11. Backboard Release Levers. One on each
side of the Frame, the Backboard Release
Levers are used to release the Frame from
the Backboard.
12. Handles. One on each side of the Frame,
the Handles provide a secure way to grasp
the Frame during RMU-2000 ACC assembly
and patient transport.
13. Battery Pack. The Battery Pack provides
a replaceable primary power source for the
Compression Module.
14. Battery Pack Release Buttons. The
Battery Pack Release Buttons (one on each
side of the battery compartment on the
Compression Module) eject the Battery
Pack from the Compression Module.
15. Compression Piston. The Compression
Piston is driven by a motor housed inside
the Compression Module and, with the
Suction Cup attached to the end of the
Piston, provides the compressions to the
patient's chest.
16. Suction Cup. The Suction Cup is a user-
replaceable, single-use component that
provides the interface between the piston
and the patient's chest.
