The Frame (continued)

To remove the Frame, push in on the two backboard release levers and lift the Frame off of the

Backboard. The latches may be released together or one at a time.

3.5 Installing the Suction Cup onto the Frame

Attach the Suction Cup to the Frame by aligning the circular connector ring on the top of the

Suction Cup to the hole on the underside of the Frame's apex and pressing up until the Suction

Cup snaps into place, as shown below.

Note: Defibtech recommends that the Suction Cup be installed to onto the Frame prior to a

rescue and that the Frame be stored in the Carrying Case with the Suction Cup already attached

to the Frame.

Note: Prior to installation, check to make sure that the Suction Cup is clean and is undamaged.

If the Suction Cup is damaged, discard it and install an undamaged one.

Note: The Suction Cup is intended as a single-use item. After being used on a patient, dispose

of the used Suction Cup and replace it with a new one.

RAC-A2510EN-DC rev B
