INVT Goodrive350 Series Operation Manual page 56

Goodrive350 series VFD Auto Station programmable expansion card
Function
Function name
code
P27.12 C_MoP1
P27.13 C_MoP2
P27.14 C_MoP3
P27.15 C_MoP4
P27.16 C_MoP5
P27.17 C_MoP6
P27.18 C_MoP7
P27.19 C_MoP8
P27.20 C_MoP9
P27.21 C_MoP10
PLC card digital
P27.22 input terminal
PLC card digital
P27.23 output terminal
P27.24 PLC card AI1
P27.25 PLC card AO1
P27.26 Length of data
0: Stopped
1: Running
0–65535
MoP1 value monitored by the VFD.
0–65535
MoP2 value monitored by the VFD.
0–65535
MoP3 value monitored by the VFD.
0–65535
MoP4 value monitored by the VFD.
0–65535
MoP5 value monitored by the VFD.
0–65535
MoP6 value monitored by the VFD.
0–65535
MoP7 value monitored by the VFD.
0–65535
MoP8 value monitored by the VFD.
0–65535
MoP9 value monitored by the VFD.
0–65535
MoP10 value monitored by the VFD.
0x00–0x3F
PLC card digital input terminal status.
Bit5–Bit0 represent PS6–PS1
status
respectively.
0x0–0x3
PLC card digital output terminal status.
Bit0 represents PRO1, and Bit1
status
represents PRO2.
0–10.00V/0.00–20.00mA
The Value of PLC card input terminal
AI1.
0–10.00V/0.00–20.00mA
The Value of PLC card output terminal
AI1.
0x00–0x28
Description
-53-
Appendix 2
Default Modify
●
0
●
0
●
0
●
0
●
0
●
0
●
0
●
0
●
0
●
0
●
0x00
●
0x00
●
0
●
0
○
0x03
