Goodrive350 series VFD Auto Station programmable expansion card

Appendix 2 Function codes for the PLC card (Group P27)

Function
Function name
code
P27.00 PLC card enable
P27.01
P27.02
P27.03
P27.04
P27.05
P27.06
P27.07
P27.08
P27.09
P27.10 I_WrP10
PLC card current
P27.11
0–1
Indicates whether to enable the PLC
card function, which is reserved.
0–65535
I_WrP1 Value that the VFD writes to WrP1 on
the PLC card.
0–65535
I_WrP2 Value that the VFD writes to WrP2 on
the PLC card.
0–65535
I_WrP3 Value that the VFD writes to WrP3 on
the PLC card.
0–65535
I_WrP4 Value that the VFD writes to WrP4 on
the PLC card.
0–65535
I_WrP5 Value that the VFD writes to WrP5 on
the PLC card.
0–65535
I_WrP6 Value that the VFD writes to WrP6 on
the PLC card.
0–65535
I_WrP7 Value that the VFD writes to WrP7 on
the PLC card.
0–65535
I_WrP8 Value that the VFD writes to WrP8 on
the PLC card.
0–65535
I_WrP9 Value that the VFD writes to WrP9 on
the PLC card.
0–65535
Value that the VFD writes to WrP10 on
the PLC card.
0–1
It displays the current status of the PLC
status
card. It is read only.
Description
-52-
Appendix 2
Default Modify
◎
0
○
0
○
0
○
0
○
0
○
0
○
0
○
0
○
0
○
0
○
0
●
0
