Goodrive350 series VFD Auto Station programmable expansion card Auto Station programming interfaces
Auto Station
interface
variable name
C_T_UP_ELEC
C_T_UP_GEN
C_ACC1
C_DEC1
C_PID_GV_S
C_PID_FB_S
VFD
D element function
code
D7607 /
D7608 /
D7609 /
D7610 /
D7612 /
D7613 /
Interface description
To enable the PLC card to set reverse frequency
upper limit, set P03.32=1, P00.00 to a value
rather than 2, and P03.15=11.
0–3000 (corresponding to 0–300.0%). It is
readable and writable.
To enable the PLC card to set electromotion
torque upper limit, set P03.32=1, P00.00 to a
value rather than 2, and P03.18=10.
0–3000 (corresponding to 0–300.0%). It is
readable and writable.
To enable the PLC card to set braking torque
upper limit, set P03.32=1, P00.00 to a value
rather than 2, and P03.19=10.
0–36000 (corresponding to 0–3600.0s). It is
readable and writable.
When VFD ACC time 1 is set to a value rather
than 0 through the PLC card, ACC time 1
specified by the value is forcibly used (P00.11 is
invalid). When VFD ACC time 1 is set to 0
through the PLC card, ACC time 1 (P00.11) set
through the VFD keypad is used.
0–36000 (corresponding to 0–3600.0s). It is
readable and writable.
When VFD DEC time 1 is set to a value rather
than 0 through the PLC card, DEC time 1
specified by the value is forcibly used (P00.12 is
invalid). When VFD DEC time 1 is set to 0
through the PLC card, DEC time 1 (P00.12) set
through the VFD keypad is used.
-1000–1000 (corresponding to -100.0–100.0%).
It is readable and writable.
To enable the PLC card to set the VFD PID
reference value, set P00.00 to a value rather
than 2, P00.06=7 and P09.00=11.
-1000–1000 (corresponding to -100.0–100.0%).
It is readable and writable.
