Goodrive350 series VFD Auto Station programmable expansion card
Auto Station
interface variable
name
C_MoP8
C_MoP9
C_MoP10
C_VF_SET
C_UP_FRQ
C_SetDo
C_SetAO1
C_SetAO2
C_SetAO3
VFD
D element function
code
D7621 P27.19
D7622 P27.20
D7623 P27.21
D7624 /
D7625 /
D7626 /
D7627 /
D7628 /
D7629 /
Interface description
and writable.
MoP8 value monitored by the VFD. It is readable
and writable.
MoP9 value monitored by the VFD. It is readable
and writable.
MoP10 value monitored by the VFD. It is
readable and writable.
0–1000 (corresponding to 0–100.0%). It is
readable and writable.
To enable the PLC card to set the VFD VF
voltage, set P04.00=5 (user-defined V/F) and
P04.27=12.
Frequency upper limit. Reserved.
C_SetDo is an unsigned 16-bit number, which is
readable and writable.
Each bit represents a unique digital output
terminal of the VFD:
Bit0: Y1
Bit1: HDO (for digital output)
Bit2: Y2 (VFD I/O expansion card output
terminal Y2)
Bit3: RO1
Bit4: RO2
Bit5: RO3 (VFD I/O expansion card output
terminal RO3)
Bit6: RO4 (VFD I/O expansion card output
terminal RO4)
Bit7–Bit15: Reserved
0.00–10.00V/0.00–20.00mA. It is readable and
writable.
VFD analog output terminal AO1, corresponding
to -1000–1000/0–1000
0.00–10.00V/0.00–20.00mA. It is readable and
writable.
VFD I/O expansion card analog output terminal
AO2, corresponding to -1000–1000/0–1000
Reserved.
