Goodrive350 series VFD Auto Station programmable expansion card Auto Station programming interfaces
interface variables I_WrSend_PZD1–I_WrSend_PZD12) on the PLC card.
③ You can use the Auto Station to perform secondary programming on D7424–D7435
(corresponding Auto Station interface variables I_WrSend_PZD1–I_WrSend_PZD12) on the
PLC card. After the processing, the data is sent to D7636–D7647 (corresponding to Auto
Station interface variables C_WrRece_PZD1–C_WrRece_PZD12). Then the PLC card sends
this group of D elements to the DP/CANopen/PN card parsing program on the DSP for
parsing.
As shown in the figure, the host computer receives data by using the reading channels.
① The DSP sends data to the PLC card by using D7436–D7447 (corresponding to Auto
Station interface variables I_RdSend_PZD1–I_RdSend_PZD12).
② You can use the Auto Station to perform secondary programming on D7436–D7447
(corresponding to Auto Station interface variables I_RdSend_PZD1–I_RdSend_PZD12). After
the processing, the data is sent to D7648–D7659 (corresponding to Auto Station interface
variables C_RdRece_PZD1–C_RdRece_PZD12). Then the PLC card sends this group of D
elements to the DSP channels for communication with the DP/CANopen/PN card.
③ After receiving the data, the DP/CANopen/PN card sends the data to the host computer.
The following table describes the channel interfaces.
Auto Station
interface variable
name
I_WrSend_PZD1
I_WrSend_PZD2
I_WrSend_PZD3
I_WrSend_PZD4
I_WrSend_PZD5
I_WrSend_PZD6
I_WrSend_PZD7
I_WrSend_PZD8
I_WrSend_PZD9
I_WrSend_PZD10
I_WrSend_PZD11
I_WrSend_PZD12
C_WrRece_PZD1
C_WrRece_PZD2
C_WrRece_PZD3
Table 4.17 PZD writing channel interfaces
VFD
D element function
code
D7424 /
D7425 /
D7426 /
D7427 /
D7428 /
D7429 /
D7430 /
D7431 /
D7432 /
D7433 /
D7434 /
D7435 /
D7636 /
D7637 /
D7638 /
Interface description
Control word (CW), which is the first PZD sent
from the DP/CANopen/PN card
PZD2 sent from the DP/CANopen/PN card
PZD3 sent from the DP/CANopen/PN card
PZD4 sent from the DP/CANopen/PN card
PZD5 sent from the DP/CANopen/PN card
PZD6 sent from the DP/CANopen/PN card
PZD7 sent from the DP/CANopen/PN card
PZD8 sent from the DP/CANopen/PN card
PZD9 sent from the DP/CANopen/PN card
PZD10 sent from the DP/CANopen/PN card
PZD11 sent from the DP/CANopen/PN card
PZD12 sent from the DP/CANopen/PN card
CW sent to the VFD
PZD2 sent to the VFD
PZD3 sent to the VFD
