Goodrive350 series VFD Auto Station programmable expansion card
Auto Station
interface variable
name
C_MFrq
C_SpT
C_FRQ_SET
C_TOR_SET
VFD
D element function
code
D7601 /
D7602 /
D7603 /
D7604 /
Interface description
4: Jog reversely
5: Decelerate to stop
6: Coast to stop
7: Reset the fault
8: Quick and emergency stop
9: Reserved
10: Reserved
0–16. It is readable and writable.
The options are as follows:
0: Disable
1: Multi-step speed 0
2: Multi-step speed 1
3: Multi-step speed 2
4: Multi-step speed 3
5: Multi-step speed 4
6: Multi-step speed 5
7: Multi-step speed 6
8: Multi-step speed 7
9: Multi-step speed 8
10: Multi-step speed 9
11: Multi-step speed 10
12: Multi-step speed 11
13: Multi-step speed 12
14: Multi-step speed 13
15: Multi-step speed 14
16: Multi-step speed 15
0–4. It is readable and writable.
The options are as follows:
0: ACC/DEC time 1
1: ACC/DEC time 2
2: ACC/DEC time 3
3: ACC/DEC time 4
0–63000 (corresponding to 0–630.00Hz). It is
readable and writable.
To enable the PLC card to set the VFD
frequency, set P00.06/P00.07=14.
-3000–3000 (corresponding to
-300.0%–300.0%). It is readable and writable.
-46-
