Cooper Lighting Lumark LQL1500 Specification Sheet

D E S C R I P T I O N
The Lumark QZ Wedge is a
compact, economical alternative
to traditional outdoor
floodlighting. The black or white
finishes provide lasting durability
with optics that deliver optimum
beam control. U.L. listed
and labeled for wet locations.
CSA certified.
9" [229mm]
O R D E R I N G I N F O R M AT I O N
S A M P L E N U M B E R : Q Z 3 L
Lamp Type Fixture
Q=Quartz Z=Wedge
NOTES: 1 Standard unit has 1/2" NPT threaded knuckle for mounting. 2" slipfitter is available as an accessory. 2 120 Volt operation only. 3 Specifications and dimensions
subject to change without notice.
D E S C R I P T I O N
The Lumark LQL1500 has a
heat- and impact-resistant clear
glass lens, mounted in a
gasketed, die-cast hinged
aluminum door with captive
screw fasteners for positive
latching. U.L. listed and labeled
for wet locations. CSA certified.
14 1/2" [362mm]
O R D E R I N G I N F O R M AT I O N
S A M P L E N U M B E R : L Q L 1 5 0 0 W L 2 4 0
Catalog Lamp
Number Wattage
LQL1500WL240 1500W
NOTES: 1 240V T3 lamp included. 2 Specifications and dimensions subject to change without notice. 3 Products also available in non-US voltages and frequencies for
international markets. 4 Consult your Cooper Lighting Representative for availability and ordering information.
S P E C I F I C AT I O N F E AT U R E S
• Die-cast aluminum
housing finished in black or
white paint for lasting
durability
• Adjustable stem mounting
arm fits 1/2" NPS outlet box
cover
6 1/4"
[159mm]
4"
[102mm]
Lamp Wattage Lamp
3=300W L=Lamp
5=500W Included
S P E C I F I C AT I O N F E AT U R E S
• Captive screw fasteners
provide positive
weatherproof seal
• Finished in dark bronze
paint
• Clear tempered glass lens is
heat- and impact-resistant
8 1/4"
[210mm]
8 3/4"
[222mm]
Lamp
Type
T3 Quartz
COOPER LIGHTING - LUMARK
• Anodized aluminum
reflector provides maximum
beam control and efficiency
• Porcelain lamp sockets for
300-500W quartz lamp
• Heat- and weather-
resistant gasketing seals out
external contaminants
• Hinged door frame has
toolless entry latch
• U.L. listed for wet
locations. CSA certified
• Approximate net weight:
3 lbs. (1 kgs.)
Options (add as suffix)
WHT=White
Accessories (order separately)
NKS-BZ=2" Slipfitter—Bronze
NKS-WHT=2" Slipfitter—White
• Quartz lamp provides white
light for excellent color
rendition
• Die-cast aluminum door
is sealed with full-
circumference gasketing to
die-cast aluminum housing
installation to J-box and can
be wall or eaves mounted
• Integral hinge design
permits hands-free
relamping and easy
door removal
• Adjustable stem mounting
arm fits 1/2" NPT outlet box
cover
• U.L. listed for wet
locations. CSA certified
• Approximate net weight:
4.5 lbs. (2.5 kgs.)
Voltage Color
240V Bronze
®
QZ
WEDGE
3 0 0 - 5 0 0 W
Q u a r t z
F L O O D L I G H T
LQL1500
QUARTZ FLOOD
1 5 0 0 W ( M a x . )
Q u a r t z
F L O O D L I G H T
[ 2 4 0 V L A M P I N C L U D E D ]
COOPER LIGHTING
553
