Cooper Lighting Lexington LXT70SR2554 Specification Sheet

D E C O R AT I V E
LXT TRADITIONAL TOP LEXINGTON
D E C O R AT I V E L U M I N A I R E
STREETWORKS ™
H O U S I N G O R D E R I N G I N F O R M AT I O N
Die-cast aluminum base housing.
S A M P L E N U M B E R
Standard color is black. Other finish
colors available. Consult your
PRODUCT
Streetworks Representative. 1" ANSI
FAMILY
wattage/source label.
LXT=Traditional
Top
T O P
Lexington
Hinged die-cast aluminum top with
cupola cover.
R E F R A C T O R
Injection molded acrylic refractor
panels.
S O C K E T P O S I T I O N
Vertical socket position is O P T I O N S
mogul-base porcelain socket
(Type V). 50-150W MH is
OPTIONS (add as suffix)
medium-base socket standard.
1=Single Fused, Internally Mounted (120 or 277V)
Horizontal socket position is
2=Double Fused, Internally Mounted (208, 240 or 480V)
mogul-base porcelain socket
4=Photocontrol Receptacle
(Type III, field adjustable).
WH=White
50-150W MH is medium-base
BZ=Bronze
socket standard.
AP=Grey
S C R E W S
Captive retaining screw.
O P T I O N A L C O L O R S
S TA R T E R
Plug-in starter.
T E R M I N A L B L O C K
WH
Terminal block standard.
White
M O U N T I N G
Self-aligning pole-top fitter fits
2 3/8" and 3" O.D. tenons. Square
headed 1 1/4" polymer coated
mounting bolts.
E P A :
Effective Projective Area: 1.7
S H I P P I N G D ATA
Approximate Net Weight:
NOTE: 1 Refer to technical section for lamp/ballast/voltage compatibility. 2 50-150W Metal Halide is medium-base socket standard. 3 Requires use of coated lamp to achieve Type III distribution. 4 Available in Reactor HPF and NPF.
For Hi Reactance or CWA availability consult your Streetworks representative.
25 lbs. (11 kgs.)
60 S T R E E T W O R K S O u t d o o r L i g h t i n g S o l u t i o n s
: L X T 7 0 S R 2 5 5 4
LAMP LAMP TYPE
S=High
WATTAGE 1
Pressure
70=70W
Sodium
10=100W
V=Mercury
15=150W
M=Metal
17=175W
Halide
[ M u s t b e o r d e r e d i n a l p h a n u m e r i c o r d e r ]
[ S t a n d a r d c o l o r i s b l a c k , o t h e r f i n i s h c o l o r s a v a i l a b l e . C o n s u l t y o u r C o o p e r L i g h t i n g r e p r e s e n t a t i v e ]
BZ AP
Bronze Grey
15" [381mm]
1 BALLAST TYPE 1
H=Reac./HPF
N=Hi. Reac./NPF
P=Hi. Reac./HPF
R=Reac./NPF
W=CWA
2
S=Snap Latches for Toolless Lamp Replacement
B=House Side Shield
P=Polycarbonate Lens Panels
T=3/4" Pendant Mount Provision
U=UL/CSA Listed
N=NEMA Ballast Bracket 4
O P T I O N A L P E N D A N T M O U N T
25"
[635mm]
DISTRIBUTION
VOLTAGE 1
22=Type II
2=120V
33=Type III 3
0=208V
44=Type IV
4=240V
55=Type V
7=277V
8=480V
9=347V
P=240 w/PCR wired 120V
W=Multi-Tap Wired 120V
N=Multi-Tap Wired 277V
V=Multi-Tap Wired 240V
70-175W
MH/HPS/MERCURY
21"
[533mm]
OPTIONS
(See Below)
C o o p e r L i g h t i n g
