D I M E N S I O N S
7"
[179mm]
FLAT (Compact Fluorescent &
Incandescent Units)
O R D E R I N G I N F O R M AT I O N
S A M P L E N U M B E R : T R E 1 8 - C - 3 4 2 C T - D T - B K
Product Lamp Qty/Type
Compact Fluorescent
T=Terrapin
1, 2, or 3/26CT
1, 2, or 3/32CT
Shape
1, 2, or 3/42CT
R=Round
1, 2, or 3/57CT
1, 2, or 3/70CT
Style
Incandescent
B=Border Paint
1 or 2/75IN
E=Eyelid
1 or 2/100IN
O=Open Face
1/150IN
1/200IN
Size
18=18"
Lens
C=Clear prismatic
O=Opal
For additional options, consult your Cooper Lighting Representative. Specifications and dimensions subject to change without
Notes:
notice. Products also available in non-US voltages and 50Hz for international markets.
1 Ceiling mount three (3) 26CT & three (3) 32CT require CSTG, Shallow Casting; TRB18-C-332CT-DT-BK-CSTG.
Incandescent version to be mounted on non-combustible material only.
come standard with Shallow Casting, (CSTG).
TORX ® is a registered trademark of Camcar Division of Textron Inc.
18 3/8"
[467mm]
8 3/4"
[223mm]
SHALLOW CASTING
(Units with CSTG, F1 Option, EM &
SC Option and SCB18 Accessory)
Voltage
Compact Fluorescent:
DT=Universal
1
120-277V Ballast
1
3 347V=347V Ballast
3,4
Incandescent:
3,4
120V=120V
2
Color
BK=Black
2
WH=White
To View Style Options,
please go to page #1413.
3 Three (3) 42CT, three (3) 57CT, & three (3) 70CT, EM & SC
4 Wall Mount Only. 5 Supplied with Shallow Casting (CSTG).
D E S C R I P T I O N
The Fail-Safe Terrapin Series
provides exceptional aesthetics
with remarkable strength. The
wide variety of products allow
an interior and exterior
architectural theme throughout
an entire facility. Cast, extra-
heavy aluminum walls of the
housings offer rugged
durability and afford efficient
heat dissipation. AccUView UV-
Guard coating protects the
inside and outside of all UV
stabilized polycarbonate lenses.
The combination of narrow
prismatic blondels on the
interior and a prescription
texture on the exterior of the
lens provides exceptional lamp
obscuration. Lifetime Warranty
against breakage.
Options Accessories
(Order Separately)
EM 3 =Emergency Battery
VRSD=TORX ®
Pack (Fluorescent
Only) screwdriver
F1 5 =Single Fuse 120, 277,
VRSB=TORX
or 347V (with HID
screwdriver bit
specify single
SCB18=Surface
voltage only)
conduit box, 18"
L=With lamp
SC 3 =Surface conduit
taps w/plugs
(standard with HID
units)
CSTG=Shallow Casting
I N S I D E / O U T S I D E P O L Y C A R B O N A T E
L E N S C O A T I N G
2 Ceiling mount 200W
FAIL-SAFE ®
ROUND SERIES
18" Harmony ™ VR
2 6 W - 7 0 W
C o m p a c t F l u o r e s c e n t
7 5 W - 2 0 0 W
I n c a n d e s c e n t
• Lens is one piece injection
molded polycarbonate, .125"
thick. In clear prismatic or
opal, the lens is scientifically
designed to obscure lamp
image while maintaining
efficiency. All lenses are
provided with AccUView UV
guard on interior and exterior
surfaces.
• Precision die-cast aluminum
housing. Extra-heavy
thickness, minimum .125"
thick, promotes durability and
efficient heat dissipation.
Marine-grade low-copper
alloy aluminum resists
corrosion.
• Eyelid face consists of high-
impact, injection molded,
.125" minimum thickness,
polycarbonate overlay
attached to lens with two
recessed stainless steel
TORX fasteners. Provides
true 360° backlit halo effect
• Incandescent sockets are
Porcelain medium base
sockets with nickel-plated
brass screw shell. Compact
Fluorescent sockets are
polycarbonate.
• Compact Fluorescent ballasts
are electronic, universal
voltage 120-277V, with
minimum starting
temperatures of -17°C (0°F)
for 57, 70W.
COOPER LIGHTING
1411
