D E C O R AT I V E
LXD
DAYFORM LEXINGTON
D E C O R AT I V E L U M I N A I R E
STREETWORKS
H O U S I N G
O R D E R I N G I N F O R M AT I O N
Die-cast aluminum base housing.
S A M P L E N U M B E R
Standard color is black. Other finish
colors available. Consult your
PRODUCT
Streetworks Representative.
FAMILY
1" ANSI wattage/source label.
LXD=Dayform
Lexington
T O P
Hinged die-cast aluminum top with
cupola cover.
R E F L E C T O R
Anodized aluminum reflector with
field adjustable socket.
R E F R A C T O R
O P T I O N S
Clear acrylic refractor panels.
C H I M N E Y
OPTIONS (add as suffix)
Decoractive glass chimney and
1=Single Fused, Internally Mounted (120 or 277V)
brass holder.
4=Photocontrol Receptacle
WH=White
S C R E W S
BZ=Bronze
Captive retaining screw.
AP=Grey
S TA R T E R
Plug-in starter.
T E R M I N A L B L O C K
O P T I O N A L C O L O R S
Terminal block standard.
M O U N T I N G
Self-aligning pole-top fitter fits
2 3/8" and 3" O.D. tenons. Square
WH
headed 1 1/4" polymer coated
White
mounting bolts.
E P A :
Effective Projective Area:
1.7
S H I P P I N G D ATA
Approximate Net Weight:
25 lbs. (11 kgs.)
NOTE: 1 Refer to technical section for lamp/ballast/voltage compatibility. 2 Medium-base porcelain socket standard. 3 HPS only.
62
S T R E E T W O R K S O u t d o o r L i g h t i n g S o l u t i o n s
: L X D 7 0 S R 2 3 3 4
LAMP
LAMP TYPE
S=High
WATTAGE
1
Pressure
70=70W
Sodium
10=100W
M=Metal
15=150W
Halide
17=175W
[ M u s t b e o r d e r e d i n a l p h a n u m e r i c o r d e r ]
[ S t a n d a r d c o l o r i s b l a c k , o t h e r f i n i s h c o l o r s a v a i l a b l e . C o n s u l t y o u r C o o p e r L i g h t i n g r e p r e s e n t a t i v e ]
BZ
AP
Bronze
Grey
O P T I O N A L P E N D A N T M O U N T
1
BALLAST TYPE
1
H=Reac./HPF
3
N=Hi. Reac./NPF
R=Reac./NPF
2
P=Polycarbonate Lens Panels
S=Snap Latches for Toolless Lamp Replacement
T=3/4" Pendant Mount Provision
U=UL/CSA Listed
21"
[533mm]
15" [381mm]
DISTRIBUTION
VOLTAGE
1
22=Type II
2=120V
33=Type III
70-175W
MH/HPS
25"
[635mm]
OPTIONS
(See Below)
