0: Get ESC information (U64)
MASTER TO ESC:
Extended Frame ID
Priority Source
Destination
Address
Address
0x00
0x00
0x02
ESC TO MASTER (Answer)
Extended Frame ID
Priority Source
Destination
Address
Address
0x00
0x02
0x00
Example:
Message
Frame ID:
Transmission:
Master to ESC:
00 00 02 00
ESC to Master:
00 02 00 00
1: Set PWM (U16)
MASTER TO ESC:
Extended Frame ID
Priority Source
Destination
Address
Address
0x00
0x00
0x02
ESC TO MASTER(Answer)
Extended Frame ID
Priority Source
Destination
Address
Address
0x00
0x02
0x00
Example:
Message
Frame ID:
Transmission:
Master to ESC:
00 00 02 01
ESC to Master:
REV 1.1.1 (Last Modified May 25, 2023)
Object
Address
0x00
Object
Byte0
Byte1
Address
0x00
FW0
FW1
Data:
00 00 00 00 00 00 00 00
0C 00 01 00 46
Data
Object
Byte0
Byte1
Address
0x01
0~0x08
0~0x98
Object
Address
0x01
Data:
05 FC 00 00 00 00 00 00
Data
Byte2
Byte3
HW0
HW1
Data Decimal
Data Description:
Equivalent:
Master sends request
ESC replies with firmware 0x 0C 00 and
hardware 01 00
Data Decimal
Data Description:
Equivalent:
1532
Send 1532 μs to the ESC
The ESC sets the throttle to the
specified pulse width.
Byte4
Mode
15 | 29
R E V 1 . 1 . 1
