INSTALLING DRIVES

2. 5" S S D IN S TA LL AT I O N
Three SSDs can be installed on the 3x dedicated SSD bracket and two on each of the 4x SSD
covers for a total of 11 SSD drives.
SSD Cover
One SSD can be installed on the front of the cover with 4x
SSD screws:
4x
Another SSD can be placed without tools on the rear side of
the cover. Press the SSD down on the bottom 2 pins and then
place the SSD in the top 2 pins.
16
2
1
SSD Bracket
Install the SSD with 4x SSD
screws and place it back on
the 4x grommets.
ENTHOO PRO II SE
RE QU IRE S:
2
1
4x
3
