Summary of Contents for Phanteks Enthoo Primo
- Page 1 USER’S MANUAL DESIGNED IN THE NETHERLANDS...
- Page 3 Caution Please take a moment to carefully go through the installation guide. Phanteks will not take responsibility for any damages incurred due to incorrect installation and incorrect usage of this product. Thank you.
-
Page 4: Table Of Contents
TABLE OF CONTENTS SPECIFICATIONS ....................................... EXPLODED VIEW ...................................... ACCESSORIES ......................................4. BRACKETS ........................................I/O PORTS ........................................CONNECTIONS ......................................PANEL REMOVAL ...................................... MOTHERBOARD INSTALLATION ................................. POWER SUPPLY INSTALLATION ................................10. FILTERS REMOVAL ....................................11. FANS COMPATIBILITY ..................................... 12. PWM HUB ........................................13. -
Page 5: Specifications
1. SPECIFICATIONS CASE SPECIFICATIONS LIQUID COOLING 120 mm radiator 140 mm radiator Dimension 250 mm x 650 mm x 600 mm (W x H x D) Front Up to 240 Form Factor Full tower Up to 480 Up to 420 Material(s) Aluminum faceplates, Steel chassis Side (w/out HDD cages) -
Page 6: Exploded View
2. EXPLODED VIEW... - Page 7 14. Bottom Radiator Bracket 15. 底部滤尘网 15. Bottom Dust Filters 16. 免工具光驱 16. Tool-less ODD 17. Phanteks 铭板 17. Phanteks Logo plate 18. 前网罩盖 18. Front Mesh Cover 19. 硬盘笼 19. Hard Drive Cage 20. 硬盘底座 20. Hard Drive Stand 21.
-
Page 8: Accessories
3. ACCESSORIES ITEM DESCRIPTION ITEM DESCRIPTION Motherboard/ Screw M3 x 5mm Screw 5 x 10KT Fan installation ODD/SSD Stand Off Screws Motherboard Screw M4 x 8mm Reservoir Bracket Screw 6-32 x 6mm CM6 #11 Thumb Screws PSU, Brackets, CM6 #5 Pump Bracket 6-32 x 6mm HDD cages... -
Page 9: Brackets
4. BRACKETS SSD Bracket Bottom Radiator Bracket SSD 支架 底部水冷排支架 Reservoir Bracket Pump Bracket 水箱支架 水泵支架 Side Radiator Bracket 侧水冷排支架... -
Page 10: I/O Ports
5. I/O PORTS AND FRONT PANEL TOP VIEW FRONT VIEW 1. Microphone 2. Headphone 3. USB 2.0 4. USB 3.0 5. Power Reset 6. LED ON/OFF Switch 7. HDD LED 8. Power Button 1. 麦克风 2.耳机 6 ** 3. USB 2.0 4. -
Page 11: Connections
6. CONNECTIONS * 4 unoccupied connectors for Phanteks LED fans upgrades (3-6) LED ON/OFF SWITCH ** Molex output connector for LED Strips (9). 4x2pin 接头连接PHANTEKS led 风扇灯开关（系统升级用） 大4pin连接LED 灯带---（用户升级用） *Slot 1, 2, and 8 are occupied. Per Fan LED Line (1-6) >100mA... - Page 12 6. CONNECTIONS MOLEX CONNECTOR USB 3.0 IntA P2_D+ IntA P2_D- IntA P1_D+ IntA P1_D- IntA P2_SSTX+ IntA P2_SSTX- IntA P1_SSTX+ IntA P1_SSTX- IntA P2_SSRX+ IntA P1_SSRX+ IntA P2_SSRX- IntA P1_SSRX- Vbus Vbus AUDIO No Pin MIC2 L AGND MIC2 R AVCC FRO-R MIC2_JD...
-
Page 13: Panel Removal
7. PANEL REMOVAL REAR Unscrew the 4 thumb screws to remove the side panels. 首先拆除 4颗手动螺丝便可移掉左右侧板... - Page 14 7. PANEL REMOVAL ** To prevent damage to the panels, please follow the steps in order. Step 1: Pull outward to remove the front panel. Step 2: Pull up to remove the top panel. 为防面板破损，请按以下的步骤操作 步骤1，拆前面板时，向外拉 步骤2，向上拉以便拆下顶板 ** Use caution when removing front panel, Power LED wires are attached to front panel. 面板LED灯线与机箱连接，当拆除前面板时，请注意先断开接线...
-
Page 15: Motherboard Installation
8. MOTHERBOARD INSTALLATION FRONT BACK SIDE MOTHERBOARD TRAY (4x) Step 1 Step 1: Remove the reservoir bracket by unscrewing the four screws before you install the motherboard. 步骤1，在装主板之前，先卸掉水箱架的4个螺丝并移除... - Page 16 8. MOTHERBOARD INSTALLATION Step 2 Step 3 Step 2: Standoff screws are pre-installed for ATX. Extra standoff required for E-ATX Step 3: Install the motherboard with the provided M3 screws. 步骤3，用M3螺丝安装主板 步骤2，主板支撑铜柱预安装有ATX, E-ATX需要用户自行增加...
-
Page 17: Power Supply Installation
9. POWER SUPPLY INSTALLATION REAR VIEW Use the provided screws to secure the PSU in place. (4x) 请使用厂家提供的螺丝安装电源... - Page 18 9. PSU INSTALLATION (OPTIONAL) * Unscrew the panel to reveal the psu ** We recommend this install as your optional PSU location. mounting location Airflow will be restricted if PSU is installed. 以上为我们推荐的电源安装方式，这样会提 电源位为右侧隐藏式设计—安 高系统的散热效率 装电源时请先拆除右侧板 PSU RUBBER STAND (4x) Rear Align the PSU with the mounting holes and use the screws to secure the PSU to the chassis.
-
Page 19: Filters Removal
10. FILTERS REMOVAL Push down 往下按 BACK VIEW DUST FILTER BACK VIEW To clean the dust filters, run slow moving water through the filters. Dry filters before reinstalling. 慢慢的用水清洗滤尘器。等滤尘器凉干后再装入。 Push in to remove Push in to remove 推进后再移出 推进后再移出... -
Page 20: Fans Compatibility
11. FAN COMPATIBILITY FAN COMPATIBILITY TABLE 140mm 120mm (1x included) Bottom (1x included) Front (2x LED fan included) Rear (Top) (1x included) Rear (Bottom) Side HDD Cages... -
Page 21: Pwm Hub
12. PWM HUB Fan3 Fan2 Fan1 MOLEX CONNECTOR Fan4 Fan5 Fan6 4 Pin PWM hub will enable PWM function to 3-pin fans. Fan 1 can only be connected to one fan and cannot be split. Fan 2 - Fan 6 can be split to multiple fans. -
Page 22: Ssd/Odd Installation
13. SSD/ODD INSTALLATION ODD INSTALLATION SSD INSTALLATION Push in the two sides to release the ODD cover. Slide in the bottom SSD and place the second on top then screw in to lock. 从两侧扣手居中推拆除光驱档板 先用滑入的方式安装底部SSD，然后再装顶部的第二个SSD，然 后锁上螺丝固定。 DROP N LOCK Align and slide in. Align corner of bracket to the guide and drop down to lock. -
Page 23: Hard Drive Installation
14. HARD DRIVE INSTALLATION 3.5” INSTALLATION Place hard drive into tray and push in the arms to lock. 把硬盘放入托盘，并推入两边侧翼锁住。 2.5” INSTALLATION Align the SSD onto the mounting holes and screw in. Align the tray to the HDD cage and slide in. 把SSD与安装孔对齐，并锁入螺丝。... - Page 24 14. HARD DRIVE INSTALLATION REMOVING HDD CAGES REPOSITIONING OF HDD CAGES 1. Unscrew the rails under ODD 2. Pull tab out to release 3. Remove thumbscrew on the HDD cage stand 4. Reposition to alternate placement 1.拆下光驱下面导轨的螺丝 2.从拉手拉出 3.拆下硬盘盒下方支架的螺丝 4.可替换位置摆放 Unscrew the thumbscrews to remove the cages.
-
Page 25: Watercooling Installation
15. WATERCOOLING INSTALLATION WATERCOOLING RADIATOR COMPATIBILITY 120mm, 140mm 240mm, 280mm 360mm, 420mm 120mm 240mm 480mm 140mm 120mm *Side Radiator Bracket required 120mm, 140mm 240mm, 280mm SIDE VIEW 360mm 480mm 120mm 240mm *360mm,420mm, and 480mm Radiator will not fit on bracket. - Page 26 15. WATERCOOLING INSTALLATION 120 MM FORM FACTOR RADIATORS Front Rear Bottom Side w/o (HDD cages) Radiator Size Front Rear Side(w/o HDD Cages) Bottom 底部 顶部 散热排尺寸 前面 侧面（不含硬盘盒） 后面 120mm 240mm ...
- Page 27 15. WATERCOOLING INSTALLATION 140 MM FORM FACTOR RADIATORS Front Rear Bottom Side w/o (HDD cages) Radiator Size 散热排尺寸 前面 底部 顶部 侧面（不含硬盘盒） 后面 140mm 280mm 420mm **(70mm thickness max) *** 145mm width max *Caution: Supported Radiator size and thickness varies depending on your setup. ** 70mm thickness max 最大寬度145mm 机箱所支持的散热器的尺寸和厚度的变化取决于你的设置。...
- Page 28 15. WATERCOOLING INSTALLATION RADIATOR BRACKETS * 145 mm max *Bottom Radiator Bracket Side Radiator Bracket 底部水冷排支架 最大寬度145mm 侧水冷排支架...
- Page 29 15. WATERCOOLING INSTALLATION PUMP BRACKET 6#-32 rubber dampers position 1 position 2 / position 3 with HDD stand 4.5mm *in millimeters Pump bracket with universal mounting allows for multiple pumps to be installed. Pump bracket can be put on the HDD stand or without. 通用的水泵支架可支持各类多样化的水泵...
- Page 30 15. WATERCOOLING INSTALLATION RESERVOIR BRACKET 35.75 71.50 35.75 *in millimeters 71.50 Reservoir rear mounting Unscrew the cover to install the reservoir 后置水箱位 卸掉拆除水箱架表面的塑胶盖才可安装水箱 REAR VIEW...
-
Page 31: Service And Support
16. SERVICES AND SUPPORT If you have any questions or concerns, please visit Phanteks’ website for technical support. We consider customer support, satisfaction and feedback an essential element of our overall marketing effort. Please feel free to contact our support team. Thank you! Contact Us at: www.phanteks.com... - Page 32 Unleash unlimited possibilities DESIGNED IN THE NETHERLANDS...
