- Page 1 Questo manuale d’istruzione è fornito da trovaprezzi.it. Scopri tutte le offerte per Phanteks Enthoo Elite cerca il tuo prodotto tra le migliori offerte di Case e Alimentatori ENTHOO ELITE U S E R M A N U A L ENTHOO ELITE...
- Page 2 ENTHOO ELITE...
- Page 3 Thank you f o r c h o o s i n g ENTHOO ELITE...
-
Page 4: Table Of Contents
Installing vertical GPU Exploded view Installing 5.25” ODD bay Accessories Installing power splitter/combo bracket Choose your setup Installing dual system Configure your Enthoo Elite Pro tips Get started Installing motherboard Dust filters Installing power supply More RGB Installing fans Expand & upgrades... -
Page 5: Introduction
Built from premium materials that are engineered with utmost care and attention to detail. A design based on continuous product improvement and innovation throughout the Enthoo Series. Discover the ultimate building experience. Phanteks believes that meaningful designs are created through the fusion of form and function. The Phanteks team... -
Page 6: Specifications
Front Up to 480 Up to 560 Up to 480 Up to 420 Bottom Up to 480 Up to 420 Midplate Up to 480 Up to 420 Side Up to 360 Up to 280 Rear *see page 40 ENTHOO ELITE... -
Page 7: Exploded View
EXPLODED VIEW 1. Chassis 2. Front Panel 3. Top Panel 4. Mesh Panel 5. Right Side Panel 6. Right Side Cover 7. Left Side Panel 8. Mid Plates 9. Top Radiator Bracket 10. Bottom Radiator Bracket ENTHOO ELITE... -
Page 8: Accessories
- Universal mounting holes - Rubber dampening SIDE RADIATOR BRACKET SIDE PANEL DUSTFILTER - 1 included in accessory box - 1 included in accessory box - Up to 280/360 radiators - Magnetic - Universal reservoir mounts - Washable ENTHOO ELITE... - Page 9 10x Zip Tie 150 mm 6-32x6 mm 6-32x6 mm 6-32x5 mm 6-32x9 mm 6-32x10 mm 3x Spare Velcro ties Thumb screw Thumb screw Case screw / HDD grommit Thumb screw Pump bracket screw 1x ITX GPU bracket Phanteks Logo Badge ENTHOO ELITE...
-
Page 10: Configure Your Enthoo Elite
S I L E N T CO N F I G U R AT I O N P E R F O R M A N C E CO N F I G U R AT I O N ENTHOO ELITE... - Page 11 C O O L I N G S T O R A G E D U A L S Y S T E M ENTHOO ELITE...
-
Page 12: Get Started
Take out the EVA-foam from the top cover of the PREPARATIONS packaging to use as base for your hardware placement. The Enthoo Elite case is designed to support installation in standing position. Make sure the case is standing stable while building. - Page 13 O P E N I N G T O P P A N E L FIRST TIME USE R E M O V E : O P E N I N G F R O N T PA N E L R E M O V E : ENTHOO ELITE...
- Page 14 O P E N I N G S I D E C O V E R R E M O V E : After removing the side cover, equip the magnetic dust filter (found in the accessory box) to protect from dust entering your case. ENTHOO ELITE...
- Page 15 1) Slide and position this panel to create more clearance for easier cable management and installation of your hardware. 2) Use this panel to cover your cables after installation. 3) Slide this panel to position mounted components, e.g. water reservoir. ENTHOO ELITE...
-
Page 16: Installing Motherboard
S S I E E B install extra standoffs X L AT X install extra standoffs Some motherboard types require installation / repositioning of the standoffs. Please consult your motherboard manual for the correct standoff positioning. ENTHOO ELITE... -
Page 17: Installing Power Supply
P R I M A R Y P O W E R S U P P L Y RUBBER R E M O V E : Make use of the included 8-Pin extension cable if the 8-Pin cable from your power supply is too short. RUBBER ENTHOO ELITE... -
Page 18: Installing Fans
1 4 0 1 2 0 1 4 0 1 2 0 B O T T O M M I D P L A T E 1 4 0 1 4 0 1 2 0 1 2 0 ENTHOO ELITE... -
Page 19: Connecting Pwm Hub
C O N N E C T T H E 1 2 V S A T A C A B L E T O T H E P O W E R S U P P L Y Please connect the 12V SATA cable if your motherboard 4-pin PWM fan header is providing insufficient power to the PWM hub. ENTHOO ELITE... -
Page 20: Installing Drives
INSTALLING DRIVES 2 . 5 ” S S D I N S T A L L A T I O N Remove the aluminum plates in this order. ENTHOO ELITE... - Page 21 3 . 5 ” H D D I N S T A L L A T I O N R E M O V E : R E M O V E : R E M O V E : ENTHOO ELITE...
-
Page 22: Installing Watercooling
1 2 0 2 4 0 3 6 0 4 8 0 1 4 0 FORM FACTOR 1 4 0 2 8 0 4 2 0 ENTHOO ELITE... - Page 23 R E Q U I R E : B O T T O M Please use the radiator screws that come with your radiator. When using the Phanteks radiator screws make sure the threading matches with your radiator’s. 120 form factor...
- Page 24 4 2 0 5 6 0 For installation of radiators longer than R E M O V E : 440 mm, it’s required to remove the aluminum mid-cover. Remove the stock fan, sitting on top, prior to removing the mid-cover. ENTHOO ELITE...
- Page 25 2 4 0 3 6 0 4 8 0 1 4 0 FORM FACTOR 1 4 0 2 8 0 4 2 0 For installation of a 480 / 420 radiators a small section needs to be left unscrewed. ENTHOO ELITE...
- Page 26 S I D E R A D I A T O R B R A C K E T 1 2 0 FORM FACTOR 1 4 0 FORM FACTOR 1 4 0 1 2 0 2 4 0 2 8 0 3 6 0 Remove the right side panel cover for optimal airflow. See page 12. ENTHOO ELITE...
- Page 27 R E S E R V O I R I N S T A L L A T I O N S I D E R E A R PUMP/RES COMBO EKWB D5 DDC 42-45 mm RESERVOIR Centered 26 mm spacing 71.5 mm spacing Remove the aluminum plates in this order. ENTHOO ELITE...
- Page 28 Phanteks’ pump bracket can also R E M O V E : be 1) mounted on a 120 mm fan mount location or 2) onto a 120 mm fan. This can be very useful for positioning pump/reservoir combo solutions.
-
Page 29: Connecting Front I/O
H D M I 2 .0 USB 3.0 U S B 3 . T Y P E - C It’s possible to connect the “system 2” USB 3.0 connector to “system 1” to configure 4x USB 3.0 for one single system. ENTHOO ELITE... -
Page 30: Rgb Lighting
3. Scroll (Up / Down): See Mode list. cables (in accessory bag) to reroute the RGB connector for extra reach. For example when connecting Phanteks RGB M O D E L I S T watercooling products. You could also connect an RGB LED strip and route it for external use. -
Page 31: Sync Case Lighting With Rgb Motherboard
RGB LED lights. Connect the RGB LED Adapter to the case RGB connector. Case RGB connector Selected motherboard brands will allow color callibration of your Use the included RGB Extension connected LED strips. cables (in accessory bag). ENTHOO ELITE... -
Page 32: Installing Vertical Gpu
GPU bracket. 1 PCI slot won’t go into the bracket. It’s possible that using the vertical GPU bracket will unable the use of the DVI port. T I G H T E N : ENTHOO ELITE... - Page 33 U S I N G T H E 2 N D S L O T O N T H E V E R T I C A L G P U B R A C K E T 2nd Phanteks Riser Cable...
-
Page 34: Installing 5.25" Odd Bay
6,5 mm (2.5 in). Make sure your 5.25” device front panel won’t be higher than 6,5 B a y 2 mm (2.5 in) so there will be no conflicts when closing the Tempered Glass side panel. ENTHOO ELITE... -
Page 35: Installing Power Splitter/Combo
P H - P W C O B _ 2 P 1 M R E A R S I D E D R O P - N - L O C K There are 2x installation positions next to each other for the power splitter / combo bracket. ENTHOO ELITE... -
Page 36: Installing Dual System
I N S TA L L I T X GPU BRACKET I N S T A L L I T X B R A C K E T We recommend to install your ITX motherboard on to the ITX bracket prior to installing the bracket. ENTHOO ELITE... -
Page 37: Dust Filters
T O P P A N E L F I L T E R let it dry up before putting back to use. W I N D O W P A N E L F I L T E R ENTHOO ELITE... - Page 38 P S U F I L T E R S I D E P A N E L F I L T E R ENTHOO ELITE...
-
Page 39: More Rgb
MORE RGB The RGB controller in the Enthoo Elite supports up to 5 meters of LED strips. This allows you to expand your LED lighting throughout the entire case as well as outside the case. WE PROVIDE THE FOLLOWING RGB LED PRODUCTS:... -
Page 40: Expand & Upgrades
EXPAND AND UPGRADE The Enthoo Elite has been designd for maximum compatibility for any type of system. With these upgrades you can maximize your storage capability’s and expand your power options. 3.5” MODULAR HDD BRACKET PH-HDDKT_02 POWER SPLITTER HUB PH-PWSPR_1P2M - Power a Dual System with one power supply - For 3.5”... -
Page 41: Contact Us
CONTACT US As a Phanteks customer, you are priority number one. We have a dedicated team of employees across the globe working hard ever y day to make sure we deliver the superior experience you deser ve. We are here for you. If you have a question or a concern about our products, we have numerous ways you can reach us. -
Page 42: Warranty
WARRANTY PHANTEKS warrants its products to be free from defects in material and workmanship during the warranty period; when given normal, proper and intended usage. If a product proves to be defective in material or workmanship during the warranty period, PHANTEKS will, at its sole option, repair or replace the product with same product or similar product. - Page 43 ENTHOO ELITE...
