Summary of Contents for Phanteks ENTHOO PRO M
- Page 1 USER’S MANUAL...
- Page 3 Caution Please take a moment to carefully go through the installation guide. Phanteks will not take responsibility for any damages incurred due to incorrect installation and incorrect usage of this product. Thank you.
-
Page 4: Table Of Contents
TABLE OF CONTENTS SPECIFICATIONS ..........................................EXPLODED VIEW ..........................................ACCESSORIES & BRACKETS ......................................I/O PORTS ............................................. CONNECTIONS ........................................... PANEL REMOVAL ..........................................MOTHERBOARD INSTALLATION ....................................POWER SUPPLY INSTALLATION ..................................... FILTERS REMOVAL ..........................................10. FANS COMPATIBILITY ........................................11. RADIATOR BRACKET INSTALLATION ..................................12. HARD DRIVE INSTALLATION ......................................13. -
Page 5: Specifications
1. SPECIFICATIONS CASE SPECIFICATIONS PH-F140SP (included) Dimension 235 mm x 480 mm x 500 mm (W x H x D) Speed (rpm) 1200 ±250 rpm Max Airflow 9.25 in x 18.9 in x 19.7 in 82.1 CFM Form Factor Full Tower Mid Tower Static Pressure 1.33mm H2O... -
Page 6: Exploded View
2. EXPLODED VIEW 1. Chassis 2. Top Panel 3. SSD Bracket 4. ODD Bracket 5. Right Side Panel 6. Front Panel 7. HDD Tray 8. Hard Drive Cage 9. Front Mesh cover 10. Window Left Side Panel 11. Mid-plate Bracket 12. - Page 7 1.机箱 1. 筐体 1. Шасси 1. 섀시 2.顶部面板 2. 上部パネル 2 Верхняя панель 2. 상단 패널 3.SSD 支架 3. SSD ブラケット 3. Кронштейн для 3. SSD 브래킷 4.ODD 支架 4. ODD ブラケット твердотельных дисков 4. ODD 브래킷 5.右侧板 5. 右側パネル 4.
-
Page 8: Accessories & Brackets
3. ACCESSORIES & BRACKETS Reservoir/Pump... -
Page 9: I/O Ports
4. I/O PORTS 1. USB 3.0 1. USB 3.0 1. USB 3.0 2. Microphone 2. マイクロホン 2. 麦克风 3. Headphone 3. 耳机 3. ヘッドホン 4. Reset 4. 重启 4. 電源リセット 5. Power Button 5. 電源ボタン 5. 电源按钮 1. USB 3.0 1. -
Page 10: Connections
5. CONNECTIONS AUDIO PANEL USB 3.0 Power LED + Reset SW MIC2 L IntA P2_D+ AGND Power LED - IntA P2_D- IntA P1_D+ MIC2 R AVCC IntA P1_D- FRO-R MIC2_JD IntA P2_SSTX+ F_IO_SEN Power SW H.D.D LED IntA P2_SSTX- IntA P1_SSTX+ LINE2_JD FRO-L IntA P1_SSTX-... -
Page 11: Panel Removal
6. PANEL REMOVAL Unscrew the 4 thumb screws to remove the side panels. 首先拆除 4颗手动螺丝便可移掉左右侧板 4 つのつまみねじを抜き、横パネルを取り外します。 4개의 나비 나사를 풀어 측면 패널을 분리합니다 Для снятия боковых панелей отверните 4 винта с накатанной головкой. - Page 12 6. PANEL REMOVAL For the front panel, place your hands on the area shown and pull outward. 打开面板时，用手从指示位置向前拉出。 前面パネルの場合、図に示したエリアに両手を置き外側に引きます。 전면 패널을 분리하려면, 양손을 그림에 표시된 부분에 올려놓고 바깥쪽으 로 당깁니다. Чтобы снять переднюю панель, возьмитесь за нее руками в указанных местах...
-
Page 13: Motherboard Installation
7. MOTHERBOARD INSTALLATION Standoff screws are pre-installed for Micro ATX. Install the motherboard with the provided M3 screws. 出厂设置中预先安装的铜柱为规格 用M3螺丝安装主板 スタンドオフねじに標準装備されています。 同梱の M3 ねじでマザーボードを取り付けます。 스탠드 오프 나사가 에 미리 설치되어 있습니다. 제공한 M3 나사를 사용하여 메인보드를 설치합니다. Винтовые стойки заранее установлены для Закрепите... -
Page 14: Power Supply Installation
8. POWER SUPPLY INSTALLATION REAR VIEW Use the provided screws to secure the PSU in place. 使用提供的手动螺丝锁到位 提供された蝶ネジを使用して所定の位置に固定します。 제공한 나비 나사를 사용하여 제자리에 고정합니다. При условии, винты с накатанной головкой, чтобы зафиксировать ее на месте... -
Page 15: Filters Removal
9. FILTERS REMOVAL To clean the dust filters, run slow moving water through the filters. Dry filters before reinstalling. 慢慢的用水清洗滤尘器。等滤尘器凉干后再装入。 ダストフィルターを清掃するには、勢いのない水をフィルターに通し ます。 フィルターを乾かしてから再度取り付けます。 먼지 필터를 청소하려면 천천히 흐르는 물로 필터를 통과시킵니다. 다 시 설치하기 전에 필터를 말리십시오. Для очистки пылевых фильтров поместите их под небольшую струю... -
Page 16: Fans Compatibility
10. FAN COMPATIBILITY FAN COMPATIBILITY TABLE 140mm 120mm Radiator bracket required Front See page 17 Rear *To install 3x120mm on top or on front, please remove the ODD bracket first. For reference on removing the ODD bracket, see page 20. -
Page 17: Radiator Bracket Installation
11. RADIATOR BRACKET INSTALLATION Locate the 5 screws (silver colored screws) and remove. 找到5个螺钉（银色螺钉）并将其拆下 5本のネジを確認して (シルバー色のネジ) 取り外します。 나사 5개(은색 나사)를 찾아 제거하십시오. Найдите и удалите 5 винтов (серебристых). - Page 18 11. RADIATOR BRACKET INSTALLATION *For radiator and fans installation, please check compatibility table. 要拆除，松开中间板上的4个螺钉以及机箱底部的4个螺钉。 * ラジエーターやファンを取り付ける場合は、互換性表を確認して ください。 *라디에이터 및 팬 설치에 관해서는 호환성 표를 확인하십시오. * Перед установкой радиаторов и вентиляторов сверьтесь с таблицей совместимости. To remove unscrew the 5 silver screws and pull the bracket out. 若要拆除，拧下...
-
Page 19: Hard Drive Installation
12. HARD DRIVE INSTALLATION 3.5” INSTALLATION 2.5” INSTALLATION Place hard drive into tray and push in the arms to lock. 把硬盘放入托盘，并推入两边侧翼锁住。 Slide in the SSD and screw in from the side to lock in ハードドライブをトレイに置き、アームを押して固定します。하 place. 드 드라이브를 트레이에 넣고 암을 안쪽으로 눌러 고정합니다. 将SSD滑入支架后并在支架侧面锁入螺丝固定。... -
Page 20: Odd Bracket Removal
13. ODD BRACKET REMOVAL Front view To remove the ODD bracket, unscrrew the ODD bracket from the Side view mounting holes (see illustration) 若要拆卸 ODD 支架，請由安裝孔旋鬆 ODD 支架螺絲 (參閱圖例) ブラケットを取り外すには、ねじを回して取り付け穴から ODD ブ ラケットを外します (図を参照) ODD 브래킷을 제거하려면, 장착 구멍에서 ODD 브래킷의 나사를 푸 십시오(그림... - Page 21 13. HARD DRIVE CAGE HDD BRACKET REMOVAL To remove, unscrew the 4x screws on the midplate and the 4x screws on the bottom of the case. 要拆除，松开中间板上的4个螺钉以及机箱底部的4个螺钉。 取り外すには、中央プレートにある4本のネジと、ケースの下部にあ る4本のネジを外します。 탈거하려면 미드 플레이트에 있는 나사 4개와 케이스 하단의 나사 4개 를 푸십시오. Для...
-
Page 22: Drop-N-Lock Ssd Bracket
14. DROP-N-LOCK SSD BRACKET SSD INSTALLATION Slide in the SSD and screw in from the side to lock in place. 将SSD滑入支架后并在支架侧面锁入螺丝固定。 SSD を挿入し、側面からねじで留め、固定します SSD 밀어 제자리에 고정합니다 측면에서의 나사. Вставьте кронштейн SSD в паз и закрутите сбоку. DROP N LOCK Align corner of bracket to the guide and drop down to lock. -
Page 23: Watercooling Installation
15. WATERCOOLING INSTALLATION WATERCOOLING RADIATOR COMPATIBILITY 120mm, 140mm 240mm, 280mm 360mm *Removal of ODD Bracket required 140mm 120mm 120mm, 140mm 240mm, 280mm 360mm *Midplate bracket needs to be removed... - Page 24 15. WATERCOOLING INSTALLATION 120 MM FORM FACTOR RADIATORS *Caution: Supported Radiator size and thickness varies depending on your setup. Radiator Size Front Rear 提示：机箱所支持的水冷排的尺寸和厚度的变化取决于你的水路及风扇 Taille de radiateur Avant Arrière Dessus 设置。 Kühlkörpergröße Vorderseite Rückseite Oberseite 注意: サポートされるラジエーターのサイズと厚さはセットアップに Dimensioni del radiatore Parte frontale Parte posteriore Parte superiore...
-
Page 25: 5" Hdd Modular Installation (Optional)
16. 3.5” HDD MODULAR BRACKET INSTALLATION (OPTIONAL) Step 1. Remove the HDD cover by removing the m3 Screw Step 2: Align the HDD bracket to the slot and drop in. Step 3: Screw in from the back with thumb screws to lock the bracket in place. -
Page 26: Upgrade Accessories (Optional)
17. UPGRADE ACCESSORIES (OPTIONAL) SSD BRACKET HDD BRACKET HDD Bracket PH-SDBKT_01 PH-HDDKT_01 PH-SDBKT_01 PWM HUB PUMP BRACKET PH-PWHUB_01 PH-PUMBKT_01 Upgrade accessories can be purchase from www.phantekusa.com... -
Page 27: Support And Services
18. SERVICES AND SUPPORT If you have any questions or concerns, please visit Phanteks’ website for technical support. We consider customer support, satisfaction and feedback an essential element of our overall marketing effort. Please feel free to contact our support team. Thank you! Contact Us at: www.phanteks.com...
