D E C O R AT I V E
ARC
AVENUE
D E C O R AT I V E L U M I N A I R E
STREETWORKS
T O P S + F I N I A L S
O R D E R I N G I N F O R M AT I O N
All hard mount tops are made of spun
S A M P L E N U M B E R
aluminum. Top provided with toolless
access for ease of maintenance.
Finials are manufactured of cast
PRODUCT
aluminum.
FAMILY
ARC=Architectural
G L O B E
Globe is available in 9" high efficiency
UV resistant acrylic or optional
polycarbonate refractive design.
Internal and external prisms work in
conjunction to provide excellent
vertical and horizontal illumination.
C A G E A S S E M B L I E S
Two (2) uprights are manufactured of
cast aluminum. Banding is spun
O P T I O N S + A C C E S S O R I E S
aluminum. All cage assemblies are
mounted to the exterior of the housing
via four (4) stainless steel fasteners.
OPTIONS (add as suffix)
A variety of finishes are available.
1=Single Fuse (120 or 277V)
2=Double Fuse (208, 240 or 480V)
E L E C T R I C A L
4=Internal NEMA photocontrol Receptacle
Available up to 400W MH and 250W
P=Polycarbonate Refractor
HPS. Ballast assembly is mounted on
a removable tray with quick discon-
WH=White
nects for ease of installation and
BZ=Bronze
maintenance. Plug in starter standard
AP=Grey
when applicable. Terminal block is
DP=Dark Platinum
hard mounted to the casting and
H=Hartford Green
easily accessible through the door's
R=Internal Downlight Reflector
wide entryway. UL listing and optional
U=UL/CSA Listed
induction fluorescent lamp available.
H O U S I N G
Heavy duty-cast aluminum housing
O P T I O N A L C O L O R S
and door. Wide handhole provide
toolless entry for access to plug-in
starters and optional NEMA twistlock
PCR. 1" ANSI wattage/source label.
Fixture is 3G vibration rated.
WH
White
M O U N T I N G
Post top mount fits 3" OD tenons.
Four (4) stainless steel fasteners
standard.
F I N I S H
Standard polyester powder coat
finish in black. For more color options
see optional color or consult your
Streetworks represenatitive for more
information.
E P A :
Effective Projective Area:
2.1
S H I P P I N G D ATA
NOTE: 1 85W QL Induction only. 120V or 240V only. 2 400W available only in Metal Halide. Not available in 480V. 3 Refer to technical section for lamp/ballast/voltage compatibility. 4 Medium-base lamp standard for 150W and
Approximate Net Weight:
below Metal Halide. 5 Available 120V only. 6 Available 50-150W, 120/240 or single voltage only. 7 Avenue Cage must be used with Avenue Top. Avenue Top is available without cage. 8 Cage Type 6 will be finished same
50 lbs. (23 kgs.)
color as base. 9 Polycarbonate parts used with Metal Halide lamps will eventually yellow.
42
S T R E E T W O R K S O u t d o o r L i g h t i n g S o l u t i o n s
: A R C 2 5 M W W 5 5 5 2
LAMP TYPE
3
BALLAST TYPE
LAMP
M=Metal
R=Reac./NPF
WATTAGE
3
Halide
4
H=Reac./HPF
50=50W
S=High
N=Hi. Reac./NPF
70=70W
Pressure
P=Hi. Reac./HPF
85=85W
1
Sodium
W=CWA
10=100W
Q=Induction
K=10KV CWA
15=150W
I=Induction
17=175W
25=250W
40=400W
2
[ M u s t b e o r d e r e d i n a l p h a n u m e r i c o r d e r ]
ACCESSORIES (order separately)
AA2000=House Side Shield—Mogul-base Socket
AA2001=House Side Shield—Medium-base Socket
9
[ S t a n d a r d c o l o r i s b l a c k , o t h e r f i n i s h c o l o r s a v a i l a b l e . C o n s u l t y o u r C o o p e r L i g h t i n g r e p r e s e n t a t i v e ]
BZ
AP
Bronze
Grey
TM
REFRACTOR
3
VOLTAGE
3
CAGE TYPE
5
2=120V
TYPE
6=Avenue
0=208V
X=None
33=Type III
4=240V
55=Type V
7=277V
8=480V
6
9=347V
W=Multi-Tap
wired 120V
N=Multi-Tap
wired 277V
DP
Dark Platinum
25 3/8" [645mm]
7, 8
TOP TYPE
7
FINIAL TYPE
5=Avenue
2=Modern
(Top Access)
3=Architectural
H
Hartford Green
C o o p e r L i g h t i n g
50-400W
MH/HPS/QL
37 3/8"
[949mm]
OPTIONS +
ACCESSORIES
(See Below)
