Cooper Lighting Manchester ANG17MWW33431 Specification Sheet

D E C O R AT I V E
ANG MANCHESTER
D E C O R AT I V E G L A S S L U M I N A I R E
STREETWORKS ™
F I N I A L O R D E R I N G I N F O R M AT I O N
Cast finial optional. Finial painted
S A M P L E N U M B E R
to match cast housing.
PRODUCT
G L O B E
FAMILY
Borosilicate two-piece prismatic
ANG=Manchester
glass refractor, available in either
a Type III or Type V distribution.
C A G E O R B A N D
Optional decorative cage or band
is available. Cage uprights are
manufactured of cast aluminum.
Bands are extruded aluminum.
Finish colors match housing color
choice. Optional gold anodized
O P T I O N S + A C C E S S O R I E S
band available. Other finish colors
available. Consult your Streetworks
Representative.
OPTIONS (add as suffix)
1=Single Fuse (120 or 277V)
H O U S I N G
2=Double Fuse (208, 240, or 480V)
Heavy-duty cast aluminum housing.
4=Internal NEMA photocontrol Receptacle
Optional NEMA PCR is accessible
BZ=Bronze
through door assembly. Provided
AP=Grey
with 1" ANSI wattage source label.
DP=Dark Platinum
H=Hartford Green
B A L L A S T
U=UL/CSA Listed
Ballast provided with a power tray
assembly for ease of maintenance.
Mogul-base is standard for 70W
O P T I O N A L C O L O R S
through 150W HPS and 175W MH.
70W through 150W MH use
medium-base. Standard plug-in
starter when applicable. U.L. Listing
is available.
BZ
Bronze
M O U N T I N G
Post top mount fits 3" O.D. tenons
and secures in place with four (4)
allen-head set screws.
F I N I S H
Standard polyester powder coat
finish in black. For more color
options see optional color or
consult your Streetworks
represenatitive for more
information.
E P A :
Effective Projective Area: 1.6
S H I P P I N G D ATA
Approximate Net Weight:
60 lbs. (27 kgs.) NOTE: 1 Refer to technical section for lamp/ballast/voltage compatibility. 2 Medium-base socket standard for 150W and below MH. 3 Available in 120V only. 4 When gold anodized band is chosen, finial finished in gold.
68 S T R E E T W O R K S O u t d o o r L i g h t i n g S o l u t i o n s
: A N G 1 7 M W W 3 3 4 3 1
LAMP LAMP TYPE 1 BALLAST TYPE
M=Metal
WATTAGE 1
R=Reac./NPF
Halide 2
70=70W
H=Reac./HPF
S=High
10=100W
N=Hi. Reac./NPF
Pressure
15=150W
P=Hi. Reac./HPF
Sodium
17=175W
W=CWA
[ M u s t b e o r d e r e d i n a l p h a n u m e r i c o r d e r ]
ACCESSORIES (order separately)
AA3000=House Side Shield—Mogul-base Socket
AA3001=House Side Shield—Medium-base Socket
[ S t a n d a r d c o l o r i s b l a c k , o t h e r f i n i s h c o l o r s a v a i l a b l e . C o n s u l t y o u r C o o p e r L i g h t i n g r e p r e s e n t a t i v e ]
DP
AP
Dark Platinum
Grey
1 VOLTAGE 1 REFRACTOR CAGE/BAND TYPE
2=120V 1=Classical
TYPE
3
0=208V A=Classical/Sun Gold
33=Type III
4=240V B=Classical/Antique
55=Type V
7=277V Gold
8=480V C=Classical/Colonial
9=347V Bronze
W=Multi-Tap Wired 120V 4=Gold Anodized Band
N=Multi-Tap Wired 277V 5=Painted Band
X=None
H
Hartford Green
70-175W
MH/HPS
[801mm]
15 5/8" [397mm]
TOP TYPE OPTIONS +
FINIAL TYPE 4
3=Victorian
1=Victorian
ACCESSORIES
2=Modern
(See Below)
3=Architectural
4=Nostalgic
5=Old World
X=None
4
C o o p e r L i g h t i n g
31 1/2"
