Cooper Lighting ARC15SWW33112 Specification Sheet

D E C O R AT I V E
ARC GENERATION SERIES
A R C H I T E C T U R A L D E C O R AT I V E L U M I N A I R E
STREETWORKS ™
G L O B E O R D E R I N G I N F O R M AT I O N
Refractive globe is a 9" high efficiency
S A M P L E N U M B E R
UV resistant acrylic or optional
polycarbonate design and utilizes a
combination of refractive and PRODUCT
reflective prisms for optional Type III
FAMILY
or V distributions. Globes maintain
ARC=Architectural
consistency in form and photometric
performance between both
distributions. Polycarbonate not
recommended for MH applications.
H O U S I N G
Heavy duty-cast aluminum housing
and door. Wide handhole provide
toolless entry for access to plug-in
starters and optional NEMA twistlock
PCR. 1" ANSI wattage/source label.
Fixture is 3G vibration rated.
E L E C T R I C A L
Available up to 400W MH and 250W
HPS. Ballast assembly is mounted on
a removable tray with quick
disconnects for ease of installation
and maintenance. Plug in starter
standard when applicable. Terminal
O P T I O N S + A C C E S S O R I E S
block is hard mounted to the casting
and easily accessible through the
OPTIONS (add as suffix)
door's wide entryway. UL listing and
optional induction fluorescent lamp 1=Single Fuse (120 or 277V)
available.
2=Double Fuse (208, 240 or 480V)
4=Internal NEMA photocontrol Receptacle
C A G E A S S E M B L I E S
P=Polycarbonate Refractor
All uprights are manufactured of cast
WH=White
aluminum. Banding is extruded
BZ=Bronze
aluminum. All cage assemblies are
mounted to the exterior of the housing
AP=Grey
via four (4) stainless steel fasteners. A
DP=Dark Platinum
variety of finishes are available.
H=Hartford Green
A=Twistlock Refractor
T O P S + F I N I A L S
R=Internal Downlight Reflector
All hard mount tops are made of spun
U=UL/CSA Listed
aluminum and all glow tops are
manufactured of acrylic. Finials are B=Decorative Brass Banding
manufactured of cast aluminum.
M O U N T I N G
O P T I O N A L C O L O R S
Post top mount fits 3" OD tenons.
Four (4) stainless steel fasteners
standard.
F I N I S H
WH
Standard polyester powder coat
White
finish in black. For more color options
see optional color or consult your
O P T I O N A L M E TA L L I C C O L O R S
Streetworks represenatitive for more
information.
E P A :
Sun Gold
Effective Projective Area: 2.1
S H I P P I N G D ATA
NOTE: 1 Induction only. 120/240V only. 2 400W available only in Metal Halide. Not Available in 480V. 3 Refer to technical section for lamp/ballast/voltage compatibility. 4 Medium-base socket standard for 150 watt and below Metal
Approximate Net Weight:
Malide. 5 Available 120V only. 6 Available 50-150W, 120/240 or single voltage only. 7 Cage Type 1, 2, 3 will be finished same color as base.8 Polycarbonate parts used with metal halide or mercury vapor lamps will eventually
50 lbs. (23 kgs.) yellow. 9 When brass banding is chosen, finial finished in gold.
18 S T R E E T W O R K S O u t d o o r L i g h t i n g S o l u t i o n s
: A R C 1 5 S W W 3 3 1 1 2
LAMP TYPE 3
LAMP BALLAST TYPE
M=Metal R=Reac./NPF
WATTAGE 3
Halide 4 H=Reac./HPF
50=50W
S=High N=Hi. Reac./NPF
70=70W
Pressure P=Hi. Reac./HPF
85=85W 1
Sodium W=CWA
10=100W
Q=Induction K=10KV CWA
15=150W
I=Induction
17=175W
25=250W
40=400W 2
[ M u s t b e o r d e r e d i n a l p h a n u m e r i c o r d e r ]
ACCESSORIES (order separately)
AA2000=House Side Shield—Mogul-base Socket
AA2001=House Side Shield—Medium-base Socket
8
9
[ S t a n d a r d c o l o r i s b l a c k , o t h e r f i n i s h c o l o r s a v a i l a b l e . C o n s u l t y o u r C o o p e r L i g h t i n g r e p r e s e n t a t i v e ]
BZ AP
Bronze Grey
[ C l a s s i c a l , M o d e r n , a n d A r c h i t e c t u r a l C a g e Ty p e O n l y ]
Antique Gold Colonial Bronze
TM
REFRACTOR
3 VOLTAGE 3 CAGE TYPE
5 2=120V 1=CLASSICAL
TYPE
0=208V A=Classical/Sun Gold
33=Type III
4=240V 55=Type V B=Classical/Antique
7=277V Gold
8=480V C=Classical/Colonial
6 9=347V Bronze
W=Multi-Tap 2=MODERN
wired 120V D=Modern/Sun Gold
N=Multi-Tap E=Modern/Antique Gold
wired 277V F=Modern/Colonial
Bronze
3=ARCHITECTURAL
G=Architectural/Sun
Gold
H=Architectural/Antique
Gold
J=Architectural/Colonial
Bronze
X=None
DP
Dark Platinum
18 3/4" [476mm]
TOP TYPE
7 FINIAL TYPE
1=Acorn 1=Victorian
2=Modern
2=Modern
3=Architectural
3=Victorian
4=Classical 4=Nostalgic
6=Nostalgic X=None
(Top Access)
7=Architectural
(Top Access)
H
Hartford Green
7
50-400W
MH/HPS/QL
24"
[610mm]
OPTIONS +
ACCESSORIES
(See Below)
C o o p e r L i g h t i n g
