Cooper Lighting Acorn ANE50SR2554 Specification Sheet

50-250W
MH/HPS/MERCURY
8"
21 1/2" [546mm]
9"
27 3/4" [705mm]
11 1/4"
[286mm]
4 1/2"
[114mm]
O R D E R I N G I N F O R M AT I O N
S A M P L E N U M B E R : A N E 5 0 S R 2 5 5 4
PRODUCT LAMP
FAMILY WATTAGE 3
ANE=Acorn 50=50W 1
70=70W
10=100W
15=150W
17=175W
25=250W 2
O P T I O N S + A C C E S S O R I E S [ M u s t b e o r d e r e d i n a l p h a n u m e r i c o r d e r ]
OPTIONS (add as suffix)
1=Single Fuse, Internally Mounted WH=White
(120 or 277V) BZ=Bronze
2=Double Fuse, Internally 9=9" Globe
Mounted (208, 240, or 480V) A=Acrylic Globe
4=NEMA Twistlock Photocontrol B=Acrylic Globe 9"
Receptacle F=Finial
5=Internal Button Photocontrol 5 AP=Grey
O P T I O N A L C O L O R S [ S t a n d a r d c o l o r i s b l a c k , o t h e r f i n i s h c o l o r s a v a i l a b l e . C o n s u l t y o u r C o o p e r L i g h t i n g r e p r e s e n t a t i v e ]
BZ
WH
White Bronze
P H O T O M E T R I C S [ C o m p l e t e I E S f i l e s a v a i l a b l e a t w w w. c o o p e r l i g h t i n g . c o m ]
A B
5 4 3 2 1 0 1 2 3
A N E 1 5 S 3 3 . I E S
150-Watt HPS
16,000-Lumen Lamp
Type III
NOTE: 1 Available in 120V only. 2 250W available for 120V only. 3 Refer to technical section for lamp/ballast/voltage compatibility. 4 Available 50-150W, 120/240 or single voltage only. 5 Specify single voltage. 6 Standard 8" globe.
7 Available in Reactor HPF and NPF. For Hi Reactance or CWA availability consult your Streetworks Representative.
C o o p e r L i g h t i n g
T I LT- B A C K P O W E R M O D U L E
8"
14 1/4" [362mm]
9"
16 1/2" [419mm]
LAMP TYPE 3 BALLAST TYPE
S=High R=Reac./NPF
Pressure
H=Reac./HPF
Sodium N=Hi. Reac./NPF
V=Mercury P=Hi. Reac./HPF
M=Metal
W=CWA
Halide K=10KV CWA
H=Hartford Green
DP=Dark Platinum
6 M=Milk White Globe
N=NEMA Ballast Bracket
S=Screw Secure Power Module
U=UL/CSA Listed
AP DP
Grey Dark Platinum
5
4
3
2
1
C D
0
1
2
3
4
5
4 5 5 4 3 2 1 0
A N E 1 5 S 5 5 . I E S
150-Watt HPS
16,000-Lumen Lamp
Type V
3 VOLTAGE 3
1 2=120V
0=208V
4=240V
7=277V
8=480V
4 F=120/240 wired 120V
G=120/240 wired 240V
W=Multi-Tap wired 120V
N=Multi-Tap wired 277V
V=Multi-Tap wired 240V
ACCESSORIES (order separately)
AA1000=House Side Shield (9" globe)
AA1001=House Side Shield (8" globe)
7
H
Hartford Green
5
F O O T C A N D L E TA B L E
Select mounting height and read across for footcandle
4
values of each isofootcandle line. Distance in units of
3
mounting height.
Mounting
2
Height
1
A B C D
ANE15S33.IES
0
12'
1
14'
16'
2
3
ANE15S55.IES
12'
4
14'
5
16'
1 2 3 4 5
S T R E E T W O R K S O u t d o o r L i g h t i n g S o l u t i o n s
ANE ACORN
D E C O R AT I V E L U M I N A I R E
REFRACTOR
OPTIONS +
TYPE
ACCESSORIES
33=Type III
(See Below)
55=Type V
Footcandle Values for
Isofootcandle Lines
A B C D
1.36 0.68 0.34 0.13
1.00 0.50 0.25 0.10
0.76 0.38 0.19 0.07
1.36 0.68 0.34 0.13
1.00 0.50 0.25 0.10
0.76 0.38 0.19 0.07
D E C O R AT I V E
STREETWORKS ™
G L O B E
8" textured polycarbonate globe is
standard. Optional globes include a
9" polycarbonate, 8" and 9" milk
white, and 8" and 9" acrylic.
(Optional internal Type III refractor
available.)
S O C K E T
Mogul-base socket for 50W through
150W HPS and 175W and 250W
Metal Halide; 50W through 150W
MH is medium base socket. All
sockets are 4KV pulse rated.
B A L L A S T
Easily accessible, tilt-back power
module. Standard plug-in starter
when applicable.
P H O T O C O N T R O L
Photocontrol receptacle available.
H O U S I N G
Cast aluminum housing. Standard
with two position terminal block.
Standard color is black. Other finish
colors available. Consult your
Streetworks Representative. 1" ANSI
wattage/source label.
M O U N T I N G
Post-top mount fits 3" tenons.
Secures with three (3) square
headed 1 1/4" polymer coated
mounting bolts.
F I N I S H
Standard polyester powder coat
finish in black. For more color
options see optional color or
consult your Streetworks
represenatitive for
more information.
E P A :
Effective Projective Area: 1.7
S H I P P I N G D ATA
Approximate Net Weight:
30 lbs. (14 kgs.)
