APPLICATION
The ACN Series traditional
character with updated styling
and superior photometric
performance offers roadway
illumination and uniformity
to set a new standard for
decorative post top luminaires.
It's traditional styling ties in
well with historic districts,
downtown streetscapes,
walkways, and parking lots.
DIMENSIONS
18 4/5" [478mm]
TOPS/FINIAL OPTIONS
A C O R N ( G L O W T O P )

ORDERING INFORMATION

ACN
Product Family Lamp Lamp Type
ACN=Architectural Wattage M=Metal
50=50W Halide
70=70W S=High
10=100W Pressure
15=150W Sodium
17=175W
25=250W
NOTE: 1 When brass banding is choosen, finial finished in gold. Specifications and Dimensions subject to change without notice.
PHOTOMETRIC
6 5 4 3 2 1 0 1 2 3 4 5
R E P O R T # 7 6 8 0 5 5
15' Mounting Height
150-Watt HPS, Type III Acrylic Refractor
16,000-Lumen Clear ED-23.5 Lamp
COEFFICIENTS OF UTILIZATION
0.5
0.4
0.3
0.2
0.1
25 1/3"
0.0
[643mm]
0
LUMENS OUTPUT & EFFICIENCY
REPORT #768055
Downward Street Side
Downward House Side
Downward Total
Upward Street Side
Upward House Side
Upward Total
Total Flux
M O D E R N V I C T O R I A N ( G L O W T O P )
Ballast Type Voltage Refractor
R=Reac./NPF 2=120V Type
H=Reac./HPF 0=208V 33=Type III
N=Hi. Reac./NPF 4=240V 55=Type V
P=Hi. Reac./HPF 7=277V
W=CWA 8=480V
K=10KV CWA 9=347V
W=Multi-Tap
Wired 120V
N=Multi-Tap
Wired 277V
Customer First Center 1121 Highway 74 South Peachtree City, GA 30269 770.486.4800 FAX 770.486.4801
6
5
4
3
2
1
0
1
2
3
4
5
6
6
6 5 4 3 2 1 0 1 2 3
R E P O R T # 7 6 8 0 6 6
15' Mounting Height
150-Watt HPS, Type V Acrylic Refractor
16,000-Lumen Clear ED-23.5 Lamp
Street Side
House Side
1 2 3 4 5
Street Width/Mounting Height
PERCENT
LUMENS
OF LAMP
6721.65 42.0
3681.3 23.0
10402.95 65.0
2710.24 16.9
2260.82 14.1
4971.06 31.1
15374.01 96.1
C L A S S I C A L
Cage Type Top Type
1=Classical 1=Acorn
2=Modern 2=Modern
3=Architectural 3=Victorian
X=None 4=Classical
ACORN—ACN-2 Post Top Luminaire
6
F O O T C A N D L E TA B L E
Select mounting height and read across for
5
footcandle values of each isofootcandle line.
4
Distance in units of mounting height.
3
2 Mounting Footcandle Values for
Height Isofootcandle Lines
1
0
1
REPORT #768055
2
10' 4.50 2.25
3
15' 2.00 1.00
4
20' 1.12 0.56
REPORT #768066
5
10' 2.25 1.12
6
4 5 6
15' 1.00 0.50
20' 0.56 0.28
0.5
0.4
0.3
0.2
0.1
0.0
0 1 2
Street Width/Mounting Height
LUMENS
REPORT #768066
Downward Street Side 5089.05
Downward House Side 5089.04
Downward Total 10178.09
Upward Street Side 2494.74
Upward House Side 2494.73
Upward Total 4989.47
Total Flux 15167.56
V I C T O R I A N M O D E R N
Finial Type Options (add as suffix)
1=Victorian 1=Single Fuse (120, 277V)
2=Modern 2=Double Fused (208, 240 or 480V)
3=Architectural 4=Internal NEMA Photocontrol Receptacle
X=None 6=White
8=Bronze
B=Decorative Brass Banding
H=Hartford Green
SY=Silver
P=Polycarbonate Refractor
R=Downlight Reflector
Accessories (order separately)
AA1000=House Side Shield
www.cooperlighting.com
1.12 0.45 0.22
0.50 0.20 0.10
0.28 0.11 0.05
0.45 0.22 0.11
0.20 0.10 0.05
0.11 0.05 0.02
Street Side
House Side
3 4 5
PERCENT
OF LAMP
31.8
31.8
63.6
15.6
15.6
31.2
94.8
A R C H I T E C T U R A L
1
ADW010227
