Cooper Lighting Traditionaire UTR50SR2554 Specifications

50-250W
MH/HPS/MERCURY
30 3/4"
[781mm]
17" [432mm]
16 1/2" [419mm]
Optional Decorative
Ladder Rest
O R D E R I N G I N F O R M AT I O N
S A M P L E N U M B E R : U T R 5 0 S R 2 5 5 4
PRODUCT LAMP WATTAGE
50=50W
FAMILY
70=70W
UTR=Traditionaire
10=100W
15=150W 1
17=175W
20=200W
25=250W
O P T I O N S + A C C E S S O R I E S [ M u s t b e o r d e r e d i n a l p h a n u m e r i c o r d e r ]
OPTIONS (add as suffix)
4=Photocontrol Receptacle
WH=White
BZ=Bronze
AP=Grey
B=House Side Shield
E=Factory Installed Cupola Cover with Cast Aluminum Eagle
H=Plug-in Starter Receptacle
O P T I O N A L C O L O R S [ S t a n d a r d c o l o r i s b l a c k , o t h e r f i n i s h c o l o r s a v a i l a b l e . C o n s u l t y o u r C o o p e r L i g h t i n g r e p r e s e n t a t i v e ]
WH
BZ
White
Bronze
P H O T O M E T R I C S [ C o m p l e t e I E S f i l e s a v a i l a b l e a t w w w. c o o p e r l i g h t i n g . c o m ]
A B
5 4 3 2 1 0 1 2 3
U T R 2 5 S 2 2 . I E S
250-Watt HPS
30,000-Lumen Lamp
Type II
NOTE: 1 150W units are for S55 Lamps. 2 Refer to technical section for lamp/ballast/voltage compatibility. 3 Medium-base porcelain socket standard for 50-150W MH. 4 Requires coated lamp to achieve Type III distribution.
C o o p e r L i g h t i n g
O P T I O N A L P E N D A N T M O U N T
4" [102mm]
6" [152mm]
17" [432mm]
3 3/4" [95mm]
2 LAMP TYPE 2
BALLAST TYPE
S=High Pressure Sodium
H=Reac./HPF
V=Mercury N=Hi. Reac./NPF
M=Metal Halide 3
P=Hi. Reac./HPF
R=Reac./NPF
W=CWA
C=CWI
J=Factory Installed Ladder Rest
P=Polycarbonate Lens Panels
S=Snap Latches for Toolless
Lamp Replacement
T=3/4" Pendant Mount Provision
U=UL/CSA Listed
W=20' #10 Leads Installed
AP
Grey
5
4
3
2
1
C D
0
1
2
3
4
5
5 4 3 2 1 0
4 5
U T R 2 5 S 5 5 . I E S
250-Watt HPS
30,000-Lumen Lamp
Type V
UTR
VOLTAGE 2
2
2=120V
0=208V
4=240V
7=277V
8=480V
9=347V
W=Multi-Tap wired 120V
N=Multi-Tap wired 277V
V=Multi-Tap wired 240V
ACCESSORIES (order separately)
TA1BK=Decorative Ladder Rest for Field Installation
OA1219=TufGuard Vandal Shield
5
F O O T C A N D L E TA B L E
Select mounting height and read across for
4
footcandle values of each isofootcandle line.
3
Distance in units of mounting height.
Mounting
2
Height
1
UTR25S22.IES
0
A B C D
15'
1
20'
25'
2
3
UTR25S55.IES
15'
4
20'
5
25'
1 2 3 4 5
S T R E E T W O R K S O u t d o o r L i g h t i n g S o l u t i o n s
TRADITIONAIRE
P O S T- T O P A R E A L U M I N A I R E
DISTRIBUTION OPTIONS +
22=Type II
ACCESSORIES
33=Type III 4
(See Below)
55=Type V
Footcandle Values for
Isofootcandle Lines
A B C D
2.77 1.39 0.69 0.28
1.56 0.78 0.39 0.16
1.00 0.50 0.25 0.10
1.77 0.89 0.44 0.18
1.00 0.50 0.25 0.10
0.64 0.32 0.16 0.06
D E C O R AT I V E
®
STREETWORKS ™
H O U S I N G + C O V E R
Hinged (stainless steel hinge pins)
die-cast aluminum housing and
cover with cupola. Standard color
is black polyester powder coat.
Other finish colors available.
Consult your Streetworks
Representative. 1" ANSI
wattage/source label.
R E F R A C T O R
Injection molded acrylic refractor
panels.
S O C K E T
Mogul-base porcelain socket.
(50-150W MH is medium-base
socket standard).
B A L L A S T
Ballast assembly with encapsulated
starter (where used). Tunnel type
compression terminal lugs.
M O U N T I N G
Self-aligning pole-top fitter fits 3"
O.D. pole tops or vertical tenons.
Square headed 1 1/4" polymer
coated mounting bolts with a lock
nut.
F I N I S H
Standard polyester powder coat
finish in black. For more color
options see optional color or
consult your Streetworks
represenatitive for more
information.
E P A :
Effective Projective Area: 2.3
S H I P P I N G D ATA
Approximate Net Weight:
37 lbs. (17 kgs.)
