Quick Start Summary
The following checklist includes the minimum required
settings to start using the receiver.
• Install either a battery sled, camera slot adapter or
other power source via bottom plate adapter.
• Connect power to the receiver.
• Set the COMPAT (compatibility) mode for the trans-
mitters to be used.
• Find clear operating frequencies for one or both
receivers using SmartTune or manual scanning.
• Set transmitters on the matching frequencies (see
transmitter manual).
• Adjust transmitter input gain to match voice level
and mic position (see transmitter manual).
• Adjust level as needed for the camera or mixer
input level desired.
