- Page 1 HDMI 2.0 KVM HDBT Extender Kit, 100m User Manual 500449 © MuxLab Inc. 2023 94-001010-A/SE-001010-A...
-
Page 2: Table Of Contents
HDMI 2.0 KVM HDBT Extender Kit, 100m Table of Contents 1. Safety Precautions..............................3 2. Introduction................................4 3. Features..................................4 4. Package Contents..............................4 5. Specifications................................5 6. Operation Controls and Functions........................6 6.1. Transmitter Panel..............................6 6.2. Receiver Panel..............................7 7. IR Pin Definition.................................8 8. Application Diagram..............................9 © MuxLab Inc. 2023 94-001010-A/SE-001010-A... -
Page 3: Safety Precautions
All contents in this manual are copyrighted, and cannot be cloned, copied, or translated without the express permission of MuxLab Inc. Product specifications and information in this document are for reference only, and the content may be updated from time to time without prior notice. -
Page 4: Introduction
328ft (100m) at 4K/60Hz (4:4:4) resolution via one (1) Cat 6a/7 unshielded twisted pair cable in a point-to-point configuration. The MuxLab HDMI 2.0 KVM HDBT Extender Kit, 100m includes one (1) transmitter and one (1) receiver. The Extender supports EDID management, bi-directional PoC function and can switch between HDBT Standard Mode (as factory default) and HDBT Long Reach Mode. -
Page 5: Specifications
-4 - 140°F / -20 - 60°C Storage Temperature Relative Humidity 20~90% RH (non-condensing) Generic Specification Compliance Regulatory: FCC, CE, RoHS 2 years Warranty 500449 HDMI 2.0 KVM HDBT Extender Kit 100m (UPC:627699004494) Order Information © MuxLab Inc. 2023 94-001010-A/SE-001010-A... -
Page 6: Operation Controls And Functions
HDBaseT output port, connected to the HDBaseT IN port of Receiver with a HDBaseT OUT CAT6A/7 cable. It is used for various signals pass-through. Illuminating: HDMI signal with HDCP. Data Signal Indicator Flashing: HDMI signal without HDCP. (Yellow) Dark: No HDMI signal. © MuxLab Inc. 2023 94-001010-A/SE-001010-A... -
Page 7: Receiver Panel
HDBaseT input port, connected to the HDBaseT OUT port of Transmitter with a HDBaseT IN CAT 6A/7 cable. It is used for various signals pass-through. Illuminating: HDMI signal with HDCP. Data Signal Indicator Flashing: HDMI signal without HDCP. (Yellow) Dark: No HDMI signal. © MuxLab Inc. 2023 94-001010-A/SE-001010-A... -
Page 8: Ir Pin Definition
Note: When the angle between the IR receiver and the remote control is ± 45°, the transmission distance is 0-5 meters; when the angle between the IR receiver and the remote control is ± 90°, the transmission distance is 0-8 meters. © MuxLab Inc. 2023 94-001010-A/SE-001010-A... -
Page 9: Application Diagram
HDMI 2.0 KVM HDBT Extender Kit, 100m 8. Application Diagram 2321 Cohen | St-Laurent , H4R 2N7 | Québec, Canada Tel: 514-905-0588 | Fax: HDMI 2.0 KVM HDBT Extender Kit, 100m 514-905-0589 | Toll free: 1-877-689-5228 info@muxlab.com | 500449 salesteam@muxlab.com | www.muxlab.com Follow us:...
