ITEM: L-AZ 904**
2 TONE LAVATORY FAUCET
INSTALLATION & OPERATION MANUAL
V1.0
10/30/2022
LEAD FREE
NSF/ANSI/CAN 61
DON'T WAIT!
REGISTER NOW!
Register your product within 90 days to ensure your product is
recognized as an
purchase and is
for warranty
coverage.
in the
registry card (Pg. 2) or register
at www.swcorp.com/register.
Advertisement
Table of Contents
Related Manuals for Anzzi L-AZ 904 Series
Summary of Contents for Anzzi L-AZ 904 Series
- Page 1 ITEM: L-AZ 904** 2 TONE LAVATORY FAUCET INSTALLATION & OPERATION MANUAL V1.0 10/30/2022 LEAD FREE NSF/ANSI/CAN 61 DON’T WAIT! REGISTER NOW! Register your product within 90 days to ensure your product is recognized as an purchase and is for warranty coverage.
- Page 3 PRODUCT SIZE CHART 8.15" [207mm] 6.34" [161mm] 1.3-1.38" 2.05" [33-35mm] [52mm] TOOLS 3/8 COMPRESSION Screwdriver Wrench PG.1...
- Page 4 COMPONENTS [01] [02] Part. Description [03] [01] Handle [04] [02] Screw [05] [03] Button [04] [06] [05] O-ring [06] Retainer Cartridge [07] [07] Body [08] [09] Aerator [10] O-ring [11] [12] Rubber Gasket [08] Metal Gasket [13] [14] Mounting Kit [09] [10] [11]...
- Page 5 INSTALLATION STEP 1: Remove Rubber Gasket [12], Metal Gasket [13] and Mounting Kit [14] from Faucet. Faucet Install Faucet with O-ring [11] at the bottom into the faucet hole on sink. Adjust the Faucet. Slide Rubber Gasket [12], Metal Gasket [13] up onto Faucet under sink and secure with Mounting Kit [14].
- Page 6 INSTALLATION Handle Faucet [09] [10] STEP 3: Turn on hot and cold water supplies and check all connections for leaks where indicated by arrows. Retighten if necessary, but Do Not Overtighten. Using the Key [10], remove Aerator [09] from Faucet. Turn the Handle to full on position and flush water lines for one minute.
- Page 7 INSTALLATION Washer Body Plastic washer Gasket Lock nut Outlet pipe STEP 5: STEP 6: Slide Washer, Plastic washer and Lock nut Install the Outlet pipe with Gasket up onto the up onto the Body from under the sink and secure Body from under the sink and tighten it securely.
