Anzzi Bravo L-AZ030 Installation Manual

Perfection is our Tradition
1-844-44-ANZZI or visit www.ANZZI.com
Step 4 Parts list
1
4
5
6
7
8
9
11
10
12
13
14
15
T M
2
3
NO. PART NAME
1 Handle
2 Index
3 Screw
4 Trim cap
5 Cartridge lock nut
Cartridge
6
7 Body
Washer
8
9 Aerator core
10 Aerator collar
11 Screw
Copper tube
12
13 Copper tube
Base
14
O-ring
15
16 Clamp
17 Lock nut
18 Allen key
16
17
18
SINGLE HANDLE LAVATORY FAUCET
ASME A112.18.1/CSA B125.1
The tools might be applied to the following places:
L-AZ030
INSTALLATION MANUAL

RECOMMENDED TOOLS

Basin wrench Channel Locks Goggles
WARNING:
Please keep the
tool for future
use!
Adjustable Wrench Teflon tape Allen key
Attention:
for easy installation, you will need:
1.To read all the installation instruction completely before
beginning.
2.To read all the warning, attention and maitenance
information.
3.To purchase the proper supply lines.
