• Analog Devices AD1854 96 kHz digital-to-analog converter
(DAC)
Line-out 3.5 mm stereo jack
• SDRAM memory
32 MB (4M byte x 64) DIMM
• Flash memory (544K x 8)
512K main flash memory
32K secondary flash memory
• Interface connectors
14-pin emulator connector for JTAG interface
Link port 0 and link port 1 for each processor
Expansion interface connectors (not populated)
• General-purpose IO
4 push button flags (two for each processor)
2 push button interrupts (one for each processor)
4 LED flag outputs (two for each processor)
• Analog Devices ADP3338, ADP3339, ADM660, and ADP3170
for voltage regulation
The EZ-KIT Lite board has two external memories: flash memory and
SDRAM. The flash memory can be used to store user-specific boot code.
By configuring the boot mode switch (
memory, the board can run as a stand-alone unit. For more information,
see "Memory Map" on page
The EZ-KIT Lite board also contains an audio interface, facilitating cre-
ation of audio signal processing applications.
ADSP-TS101S EZ-KIT Lite Evaluation System Manual
) and programming the flash
SW7
1-7.
