European Home Joist 42 Installation Manual

Designer surround. exclusively designed to fit these h series fireplaces

Advertisement

Quick Links

J o i s t
Designer Surround
Installation Guide
Exclusively designed to fit these
European Home H Series Fireplaces:
H-42-1
H-60-1
H-72-1
H-42-ST
H-60-ST
H-72-ST
November 2017
Designer Surround for H Series
EuropeanHome.com
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the Joist 42 and is the answer not in the manual?

Questions and answers

Summary of Contents for European Home Joist 42

  • Page 1 J o i s t Designer Surround Installation Guide Exclusively designed to fit these European Home H Series Fireplaces: H-42-1 H-60-1 H-72-1 H-42-ST H-60-ST H-72-ST November 2017 Designer Surround for H Series EuropeanHome.com...
  • Page 2: Table Of Contents

    TABLE OF CONTENTS Important Information Specifications and Dimensions Pre-Installation Planning Installation Maintenance Warranty Designer Surround for H Series EuropeanHome.com...
  • Page 3: Important Information

    IMPORTANT INFORMATION PRODUCT INSTALLATION RECORD Installer: Please complete this form. Customer: Please retain this information. Purchased From Date of Purchase Installed By Date of Installation Surround Serial Number Thank you for your purchase of a Designer Surround for H Series! Your Designer Surround for H Series is a proprietary combination of modern non-combustible materials designed to please the eye and delight the senses.
  • Page 4 JOIST SURROUND PANELS Joist Tile Panels 18” 24” 6” 48” 6” 72” 6” 84” 6” 96” Joist Metal Panels 48” Metal 72” Metal 84” Metal 96” Metal 24” Tile 42” Joist 60” Joist 72” Joist Each surround contains Metal and Tile Panels according to the chart, above. All surround panels are 7/16”...
  • Page 5: Specifications And Dimensions

    SPECIFICATIONS and DIMENSIONS SPECIFICATIONS and DIMENSIONS 95” Metal 42” H Series Fireplace Tile Tile 38” Metal Metal Joist 42 112” Metal 38” 60” H Series Fireplace Tile Metal Metal Metal Metal Joist 60 117” Metal 72” H Series Fireplace Tile Tile 38”...
  • Page 6: Pre-Installation Planning

    PRE-INSTALLATION PLANNING BEFORE YOU BEGIN These surrounds are intended to be installed in the same manner as a french cleat system. Please read these instructions thoroughly before proceeding. There is information which is important for safe and effective installation. Please inspect the shipment for completeness and any damage. Contact your retailer if any damage is found. Do not install the surround with any damaged or substituted parts.
  • Page 7: Installation

    The intersection of these two lines is the starting point for the installation. 20” right of fireplace opening 12” down from fireplace Starting Point Layout Lines for the Joist 42 (not to scale) 16” right of fireplace opening 12” down from fireplace Starting Point...
  • Page 8 The metal panels and tile panels should be applied to the wall in the order shown below. 4 (Metal) 3 (Tile) 42” H Series Fireplace Tile 1 (Metal) 2 (Metal) Joist 42 6 (Metal) 60” H Series Fireplace 5 (Tile) 1 (Metal) 4 (Metal) 2 (Metal)
  • Page 9 INSTALLATION: WALL LAYOUT + Z-CLIPS NOTE ABOUT Z-CLIPS Z-clips installed on the wall should have the interlocking side facing up. The slotted side of the clips face the wall. The length of the clips is to account for contact with the existing wall stud behind the wall sheet- ing.
  • Page 10 Red lines Represent guidelines for Z-clip; draw these in as guides for mounting. 6” 2 5/16” 2 5/16” 24” 24” 2 3/16” 6” 2 3/16” 6” Layout Lines for the Joist 42 (not to scale) 6” 2 5/16” 2 5/16” 24” 24” 2 3/16” 6” 2 3/16”...
  • Page 11 INSTALLATION The areas in gray, below, show where the Z-clips is to be applied to the wall. 6” 2 5/16” 2 5/16” 24” 24” 2 3/16” 6” 2 3/16” 6” Align Z-Clips to the Red Lines (42”- not to scale) 6”...
  • Page 12: Maintenance

    MAINTENANCE SURROUND MAINTENANCE Weekly Cleaning Both the metal and tile panels should be wiped with a lint free cloth to remove any dust then wiped with a damp cloth. Yearly Cleaning Both the metal and tile panels should be wiped with a lint free cloth to remove any dust then wiped with a damp cloth.
  • Page 13: Warranty

    YEAR from the date of original retail purchase. If a defect exists, European Home will, at its option, either (1) provide needed components using new or refurbished replacement parts or (2) exchange the product with one which is new or which has been manu- factured from new or serviceable used parts and is at least functionally equivalent to the original product.
  • Page 14 EUROPEAN HOME a division of Europa Ja, Inc. 30 Log Bridge Road Building 300 - Suite 303 Middleton, MA 01949 www.europeanhome.com IGHVFJS 1.0 Designer Surround for H Series EuropeanHome.com...

This manual is also suitable for:

Joist 60Joist 72
