- Page 2 (deleting) of data. It has nothing to do with EZ Dupe if there is any mistake in correcting (deleting) the data by user. In addition, EZ Dupe is not responsible for the risks and data losses incurred as a result of duplication.
- Page 3 Before Use 1. Please read this manual carefully before operation to avoid any misconduct. 2. Make sure that the storage device you want to use is of good quality and can be used normally. 3. The capacity of target storage device must be greater than or equal to the capacity of source storage device to avoid incomplete data backup.
-
Page 4: Table Of Contents
INTRODUCTION ......................5 Features ................................5 Duplicator Introduction ..........................6 Control Panel Overview ..........................7 Specifications ..............................7 II. NOTICE ......................... 8 III. OPERATION OVERVIEW ..................... 8 IV. DAISY CHAIN OPERATION..................9 V. MENU OVERVIEW ...................... 10 Copy .................................. 10 Compare ................................10 Copy + Compare .............................. 10 Capacity Check .............................. - Page 5 5.12 Media Information ........................... 15 Device Model ............................15 5.13 Print Last Task Label ..........................15 5.14 System Info.............................. 16 5.15 5.16 System Update ............................16 5.17 Log Menu ..............................16 Setup ................................. 18 Copy Area..............................18 Smaller Target ............................19 Unknown Format .............................
-
Page 6: Introduction
I. Introduction This duplicator system is designed and developed based on the FPGA from the world famous semiconductor company XILINX. Every processing channel is parallel to each other with its own control unit, therefore the duplicator will not sacrifice speed for the increasing number of targets loaded - always remain the same and fast copy speed. -
Page 7: Duplicator Introduction
2. Duplicator Introduction The following picture shows the NVMe CyCLONE Duplicator as an example. The source slot supports M.2 NVMe & M.2 SATA. The appearance of the duplicator may be changed without notice. Source Port Control Panel... -
Page 8: Control Panel Overview
3. Control Panel Overview ▲Button: Up, Backward: To navigate backward in the menu. ▼Button: Down, Forward: To navigate forward in the menu. OK Button: Enter, OK: Execute the function. Back Button: Escape, Cancel: Go back to the previous level in the menu. 4. -
Page 9: Notice
II. Notice The duplicator tasks mentioned in this user’s manual are as following: Copy, Compare, Copy + Compare, Capacity Check, Format, Erase. The Green LED flashes during the execution process of a task. After the task is done, the Green LED will stay solid if the process is successful, otherwise the Red LED will be on if the process is failed. -
Page 10: Daisy Chain Operation
If the Target SSDs are not fully connected, pressing the OK button again will execute the function immediately. Otherwise, If the OK button is not pressed again, the function will be executed after 40 seconds. During the execution process, the status of each target device can be checked by using the ▲... -
Page 11: Menu Overview
V. Menu Overview 1. Copy To copy from source device to target device(s), please go to 6.1 Copy Area to select the setting first before this step. Press OK the copy task will be executed immediately. Other tasks have the same execution for other tasks. 1. -
Page 12: Capacity Check
4. Capacity Check This command allows to verify the device capacity. It can detect the actual capacity of devices within 3 seconds. 4. Capacity Check Check：5 Result: Ready device: 5 00:00 (00) Wait Pass：5 Fail：0 5. Utility 5.1 Format FAT32 The source port can be set to execute or not at 6.10.3 Erase source port. -
Page 13: Capacity Check + Format
5.3 Capacity Check + Format It will format the devices to the file format according to the system Setup (please refer to 6.6 Set Format Type), then sort out target devices based on the capacity threshold (please refer to 6.7 Set Capacity Threshold). Duplicator will display the device which is not in the capacity range and its red LED will flash. -
Page 14: Full Erase
5.6 Full Erase This option completely erases the content of target device. It takes longer time to erase and the content will not be retrieved by software. [Utility] Target data will be erased! Target data will be erased! 6. Full Erase F_Erase：7 Result: 03:40 Pass：7... -
Page 15: Secure Erase
5.9 Secure Erase The Secure Erase is dedicated to erasing SSD. It resets all its storage cells as empty - restoring the SSD to factory default settings and write performance. Secure Erase is recognized by the US National Institute for Standards and Technology (NIST), as an effective and secure way to meet legal requirements data sanitization attacks against up to laboratory level. -
Page 16: Remove Hpa
5.11 Remove HPA This option removes the HPA setting of the disks inserted into the target ports. [Utility Erase] Sure to Remove HPA? Sure to Remove HPA?? 11. Remove HPA ▲ Remove HPA：7 Result: 00:01 Pass：7 Fail：0 00:01 (03) 5.12 Media Information This option displays the information of selected device media, such as total capacity, file format and the size of data content. -
Page 17: System Info
5.15 System Info. This option displays general information of the duplicator, including controller model, system memory size, firmware version, number of targets and ID Number [Utility] H0201S 128MB r Model Controlle 15. System Info. V2.01.00 Memory ID Number: 123456789ABCDEF 5.16 System Update This option allows user to update the firmware of duplicator when necessary. - Page 18 [Log Function] Download: [Utility] 55/500 17.Log 1.Load Data Function Signatures Download: Result: Downloading/Toal records Pass：1 Fail：0 Open the file from computer. The file name of log file is “LOG_DATA_XXXX.txt”. XXXX is from 0000 to 9999 in sequence. If no log file in the disk, it starts from 0000. If 0000 is exist in the disk, it will be added 1 to be 0001 and so on.
-
Page 19: Setup
5.17.2 Clear Data This option clears all the log data in duplicator. Sure to clear? [Utility] [Log Function] 2.Clear Data 11.Log Clear Data: Result: 55/500 Pass：1 Fail：0 5.17.3 Space Info This option shows the number of log records and amount of free space available. [Log Function] Used [Utility]... -
Page 20: Smaller Target
All Partition When selected, the duplicator copies all partitions in the drive. It will not copy the area that have not been partitioned. None-Zero When selected, the duplicator will analyze the data first where the none zero data located and then store on the DDR. -
Page 21: Unknown Format
6.3 Unknown Format This option allows you to Copy or Skip unknown format. If option Skip is selected here, the unknown format from source will not be copied during copy process. Copy unknown format is the default setting. [Setup] [Unknown Format] 3. -
Page 22: Set Format Type
6.Setup [Setup] [Set Slow Out Thresh>] 5. Set Slow Out Thresh> Read: OFF Use▲▼to change option [Set Slow Out Thresh>] [Set Slow Out Thresh>] Setup Complete! Write: OFF Duration: 5sec Use▲▼to change option Use▲▼to change option 6.6 Set Format Type This function allows to set up the target device format, and the setting will be applied by Command 4.3 Capacity Check + Format under the main menu. -
Page 23: Clear Setup
[Setup] [Set Capacity Thresh>] 6.Setup Capacity: OFF 7. Set Capacity Thres> Use▲▼to change option [Set Capacity Thresh>] [Set Capacity Thresh>] Setup Complete! Tolerance: 15% 1M=1000k Use▲▼to change option Use▲▼to change option Clear Setup This option resets the duplicator back to factory default settings. Clear parameter to default? [Setup] Clear parameter to default? -
Page 24: Advance Setup
6.10 Advance Setup 6.10.1 Check Before Copy This option allows to check device real capacity before copying. By default this option is Disable. [Advance Setup] [Check Before Copy] 1. Check Before Copy Disable Use ▲or ▼ to select 6.10.2 HPA Set HPA, Host Protected Area or Hidden Protected Area, is kept invisible space for booting area, recovery data or blocked bad-sector, etc. -
Page 25: Erase Source Port
6.10.3 Erase Source Port This option allows you to set if the master disk can be erased or not. Disable is the default setting. [Advance Setup] [Erase Source Port] 3. Erase Source Port Disable 6.10.4 Display Mode There are four display modes: Auto, Basic, Show Timer, and Expert. Basic shows the copy progress in general;... -
Page 26: Start-Up Menu
6.10.5 Start-up Menu Choose one of the following as the default start-up function: Duplicate, Data Erase, Quality Check, Utility and Setup. The default start-up function is Duplicate. [Advance Setup] [Start-up Menu] Duplicate 5. Start-up Menu Use ▲or ▼ to select 6.10.6 Button Beep This option allows to set up button sound from the following options: Button &... -
Page 27: Language
When the duplicator malfunctions or you have questions about using the duplicator, you can first check the following related problems and eliminate them. If you still have problems, you can contact the EZ Dupe technical support department. The contact information is listed at www.ezdupe.com. - Page 28 Q2：Why can’t the duplicator recognize the media device? Please check if the media device can be used normally on a computer. Please insert the media device into different ports for testing. If some ports can recognize the media device and some cannot, it may be that some ports have been used for too long, resulting in poor connection.
- Page 29 Q6：Why is copy failed? 1. Data on the source media device cannot be read normally. The source media device may be of poor quality or has bad sectors. The copying process to all target media devices will stop. Target media device cannot be written normally. The target media device may be of poor quality or has bad sectors.
