- Page 1 HDmini /HDmini Pro HDD Duplicator User Manual Copyright © 2021. All rights reserved...
- Page 2 (deleting) of data. It has nothing to do with EZ Dupe if there is any mistake in correcting (deleting) the data by user. In addition, EZ Dupe is not responsible for the risks and data losses incurred as a result of duplication.
- Page 3 Before Use 1. Please read this manual carefully before operation to avoid any misconduct. 2. Make sure that the storage device you want to use is of good quality and can be used normally. 3. The capacity of target storage device must be greater than or equal to the capacity of source storage device to avoid incomplete data backup.
-
Page 4: Table Of Contents
5.5. Full Erase ................................. 10 5.6. 3-Pass DoD Erase ............................11 5.7. 7-Pass DoD Erase ............................11 5.8. Secure Erase (Available on the HDmini Pro only) ................11 5.9. Enhance Secure Erase(Available on the HDmini Pro only) ..............12 5.10. - Page 5 6.2. Smaller Target ..............................14 6.3. Unknown Format ............................15 6.4. Check Before Copy ............................15 6.5. HPA Set (Available on the HDmini Pro only) ..................15 6.6. Display Mode ..............................16 6.7. Start-up Menu ..............................17 6.8. Button Beep ..............................17 6.9.
-
Page 6: Introduction
I. Introduction This duplicator system is designed and developed based on the FPGA from the world famous semiconductor company XILINX. Every processing channel is parallel to each other with its own control unit, therefore the duplicator will not sacrifice speed for the increasing number of targets loaded - always remain the same and intelligent copy speed. -
Page 7: Control Panel Overview
Control Panel Overview ▲Button ENT Button ESC Button ▼Button LCD Screen ▲Button: Up, Backward: To navigate backward in the menu. ▼Button: Down, Forward: To navigate forward in the menu. ENT Button: Enter, OK: Execute the function. ESC Button: Escape, Cancel: Go back to the previous level in the menu. -
Page 8: Specifications
Standalone (No PC or Software is required) Target HDmini：1 HDmini Pro：3 Copy Speed 150 MB/s for HDmini, 300 MB/s for HDmini Pro Copy Area Whole Media, System and Files (Intelligent Copy) 2.5” and 3.5” SATA HDD/SSD Supported Media Windows：FAT16/32, exFAT, NTFS Supported File Linux：ext2/3/4... -
Page 9: Menu Overview
III. Menu Overview 1. Copy To copy from source device to target device(s), please go to 6.1 Copy Area to select the setting first before this step. Copy：3 500G 1. Copy 1. Copy Source Not Ready Ready device: 3 P：0 F：0 No source device Source and target devices inserted Display copy progress... -
Page 10: Capacity Check
4. Capacity Check This command allows to verify the device capacity. It can detect the actual capacity of devices within 3 seconds. 4. Capacity Check Check：4 Result: P：0 F：0 Ready device: 4 Pass：4 Fail：0 ％ Source and target devices inserted Display progress status Final result 5. -
Page 11: Measure Speed
5.3. Measure Speed This option allows to measure the actual Read and Write speed of the target device. This option will NOT alter or erase existing data on the target device. [Utility] [# 0] Read 120M [# 1] Read 121M 3. -
Page 12: 3-Pass Dod Erase
Final result 5.8. Secure Erase (Available on the HDmini Pro only) The Secure Erase is dedicated to erasing SSD. It resets all its storage cells as empty - restoring the SSD to factory default settings and write performance. Secure Erase is... -
Page 13: Enhance Secure Erase(Available On The Hdmini Pro Only)
Fail：0 Final result 5.9. Enhance Secure Erase(Available on the HDmini Pro only) The Enhance Secure Erase is similar to Secure Erase. Beside the function of Secure Erase, it shall write predetermined data patterns to all user data areas. All previously written user data shall be overwritten, including sectors that are no longer in use due to reallocation. -
Page 14: Device Model
[Utility] [# 0] 60.0G Port Total Capacity 11. Media Information FAT32 20.1G File Format Data Use ▲or ▼ to select device 5.12. Device Model This option displays the model information of selected device, such as device model, serial information and firmware version. [# 1] P: 1 [Utility]... -
Page 15: Setup
6. Setup 6.1. Copy Area This option allows to select the area on the source device to copy onto the target devices. You may select either “System and Files” to skip all the unoccupied area on the source device or “Whole Media”. By default, the copy area is set up as System and Files. -
Page 16: Unknown Format
Use ▲or ▼ to select 6.5. HPA Set (Available on the HDmini Pro only) HPA, Host Protected Area or Hidden Protected Area, is kept invisible space for bootin g area, recovery data or blocked bad-sector, etc. By creating HPA, it resets max sectors and keeps some space for HPA. -
Page 17: Display Mode
Set Target HPA without Copy Copy data from source to target and set the target HDD the same HPA setting as the source HDD during Copy. Copy Copy data from source to target including data stored in HPA. 6.6. Display Mode There are three display modes: Basic, Show Timer, and Expert. -
Page 18: Start-Up Menu
6.7. Start-up Menu Choose one of the following as the default start-up function: Copy, Compare, Copy+Compare, Capacity Check, Utility and Setup. The default start-up function is Copy. [Start-up Menu] [Setup] Copy 7. Start-up Menu Use ▲or ▼ to select 6.8. Button Beep This option allows to set up button sound from the following options: Button &... -
Page 19: Language
[Setup Password] [Setup] Setup Password ===> _ _ _ _ _ _ 11. Setup Password Enable Use ▲or ▼ to select Use ▲or ▼ to select, Press ENT to confirm 6.12. Language This option allows to choose the language for display: English, Spanish, Portuguese, and Japanese. -
Page 20: Troubleshooting
When the duplicator malfunctions or you have questions about using the duplicator, you can first check the following related problems and eliminate them. If you still have problems, you can contact the EZ Dupe technical support department. The contact information is listed at www.ezdupe.com. - Page 21 The copy speed depends on the writing speed of the media device. When the writing speed of the media device is slow, the copy speed becomes slow. 2. There may be a slower media device in the batch of media. Remove it (press the up and down keys at the same time to remove the slowest media device during copy process) to speed up.
