Summary of Contents for EZ DUPE Gold Premier
- Page 1 Copyright 2015. All right reserved...
-
Page 2: Table Of Contents
I. INTRODUCTION ..................3 Features .......................... 3 LCD Front Panel Overview .................... 3 Specifications ........................ 4 II. WARNING ....................5 III. MENU ......................5 Copy ............................ 5 Test ............................. 5 Copy + Verify ........................ ... - Page 3 11.5 Power on Eject ........................ 1 3 11.6 Reader Speed ........................ 1 3 11.7 Compare Speed ...................... 1 4 11.8 Skip Read Error ...................... 1 4 11.9 Language ......................... 1 4 11.10 Clear Setup ........................ 1 5 ...
-
Page 4: Introduction
I. Introduction Thank you for purchasing DVD/CD Duplicator. This duplicator is specifically engineered to run stand-alone without additional computer. With a simple four-button interface, the Duplicator provides a fast and reliable solution for DVD and CD duplication up to 11 targets from one single master disc. 1. -
Page 5: Specifications
Specifications DVD/CD Duplicator Model Target Up to 11 target. Standalone (No PC or Software is required) Operation ROM, DVD-R, DVD-RW, DVD+R, Supported Format DVD+RW, CD-DA, CD ROM, CD-R, CD-RW, for Disc Multi-session Photo CDT, CD-I, Video CD, CD ROM XA, & CD Extra (CD Plus) 4 button Control Button DVD-R: 24X, DVD+R: 24X, DVD-RW: 6X,... -
Page 6: Warning
II. Warning 1. DO NOT turn off the machine when the task is under execution. It may damage the duplicator or drives. 2. DO NOT remove drives when the task is under execution. It may damage the duplicator or drives. 3. -
Page 7: Copy + Verify
Note: Test mode can only be done with DVD-R and CD-R media. 3. Copy + Verify This command will perform the copy process, and immediately follow with a verification process on all target discs automatically. This command is useful especially for audio CD duplication. -
Page 8: Verify
5. Verify This command verified readability on the all target discs. This command is especially useful for audio CD duplication. 5. Verify Verify 2048M Result # 0: 2048MB => 1024M Pass: 3 Fail: 0 ENT Verify in process 3 target discs are inserted Final result 6. -
Page 9: Track Edit
This command will allow you to change the source drive to any one of the drive(s) inside the unit, including the HDD (if installed). 8. Source Select [ Source Select ] [ Source Select ] First Drive [D# 1] Port: 0 ENT ... -
Page 10: Close Disc
Note: 1. The function can be executed again if the Audio CD has free space. 2. Please execute Close Disc when the space is full or the disc will not be added tracks on it. 9.2 Close Disc This command can closes edited audio CDs. After finishing track copied above, the Close Disc is needed to be executed to finalize disc. -
Page 11: Full Erase
Note: Do NOT perform this function on recordable (R) media. 10.3 Full Erase Perform a full erase of rewritable (RW) media for next use. [ Utility ] [ Full erase ] Result: 3. Full erase 00 : 27 Pass: 1 Fail: 0 ENT ... -
Page 12: System Information
10.7 System Information Check the model number, buffer memory and firmware version of the duplicator system. [ Utility ] A0111B 128M 7. System Information v1.05.16 ENT System information menu A0111B:The controller’s type 128MB: Controller’s memory v1.05.16: Version of firmware 10.8 Update BIOS This command allows you to update the firmware of duplicator when necessary. -
Page 13: Clear Counter
This command can turn the counter function enabled (default) or disabled. [ Utility ] 10. Utility [ Copy Counter ] 9. Copy Counter 2. Enable Counter ENT Copy counter menu Enable Counter menu [ Enable Counter ] [ Enable Counter ] Enable Disable ▲... -
Page 14: Beep
“Basic (default)” mode displays a progress bar, along with the amount of total data in MB on the master DVD (or in time for the master CD). “Expert” mode displayed the percentage of the process completed, the amount of data transferred and the total amount of data on the master disc. “Show Timer”... -
Page 15: Compare Speed
[ Setup ] 11. Setup [ Reader Speed ] 6. Reader Speed CD: 56X ENT Reader Speed menu Press ▲▼ to select speed Press ENT to confirm [ Reader Speed ] DVD: 24X Press ▲▼ to select speed Press ENT to confirm ... -
Page 16: Clear Setup
[ Setup ] 11. Setup [ Language ] 9. Language English ENT Language menu Press ▲▼ to select function Press ENT to confirm 11.10 Clear Setup Reset the duplicator back to factory default settings. [ Setup ] 11. Setup Clear Parameter To default? 10. -
Page 17: Boot Password
[ Setup ] [ Advance Setup ] 11. Setup 11. Advance Setup 2. CD Overburn ENT Press ENT to continue [ CD Overburn ] Disable Press ▲▼ to select choice Press ENT to confirm 11.11.3 Boot Password Sets password protection for the duplicator before the boot-up process can be started. -
Page 18: Copy Cd Text
[ Setup ] 11. Setup [ Advance Setup ] 11. Advance Setup 4. Setup Password ENT Press ENT to continue [ Setup Password ] [ Setup Password ] [ Setup Password ] ==> _ Disable ==> M A S T E R OK? ENT ... -
Page 19: Auto Erase
Allow the copying of CD+G files on the master disc(s) to the target disc(s). The default is Disable. [ Setup ] 11. Setup [ Advance Setup ] 11. Advance Setup 7. Copy CD+G ENT Press ENT to continue [ Copy CD+G ] Disable Press ▲▼... -
Page 20: L0 Break Point
11.11.10 L0 Break Point The layer 0 break point is the place to switch from the first layer (L0) to second layer (L1). Duplicator allows user to set option for this breaking point. By Source (default): Duplicator will burn the breaking point to target disc, following by break point place of source disc. -
Page 21: Set Time Zone
[ Setup ] 11. Setup [ Advance Setup ] 11. Advance Setup 12. Performance ENT Press ENT to continue [ Performance ] Speed Press ▲▼ to select mode Press ENT to confirm 11.11.13 Set Time Zone Allows you setup a time zone for your specific region based on GMT to time stamp your copies. -
Page 22: Hdd Manager
12. HDD Manager This command is for the management of the hard disk drive (HDD) installed in the duplicator. Note: This feature is only available on duplicators with a HDD installed. If there is no HDD present in the duplicator, this feature will NOT show in the menu of commands. -
Page 23: Image Information
12.3 Image Information Shows the image in sequential order, the file name of the image stored on the HDD, the type of image stored, and the amount of data the image contains. [ HDD Manager ] 1.[ IMG_0001.dup ] 12. -
Page 24: Hdd Information
12.6 HDD Information Show the number of images and amount of free space available. 12. HDD Manager [ HDD Manager ] Image 6. HDD Information Free 476056MB ENT HDD Information menu Info display Image 1: Number of Images Free 476056MB: Total free space of this HDD. -
Page 25: Failed Image
[ HDD Manager ] 12. HDD Manager [ HDD Setup ] 8. HDD Setup 1. Load and Copy ENT HDD Setup menu Press ENT to continue [ Load and Copy ] Press ▲▼ to select mode Press ENT to confirm choice 12.8.2 Failed Image delete (default) -
Page 26: Ⅳ.basic Troubleshooting
Ⅳ. Basic Troubleshooting Follow these simple steps for quick and proper troubleshooting. Issue 1: Power does not turn on or unit receives no power. a. Check power cord and outlet to make sure power connections are secured. b. Check voltage switch on the back of the duplicator to make sure power supply is set for correct outlet rating. - Page 27 b. Possible faulty button. Contact your technical support department for further information. Issue 6: One of the drives does not open and/or LED does not light up a. Check USB and/or Fire wire port switch and make sure the switch is in the OFF position before machine power is turned on.
