Summary of Contents for EZ DUPE Flex PRO SD
- Page 1 Copyright 2015. All right reserved...
-
Page 2: Table Of Contents
I. INTRODUCTION ........................2 Features ..............................2 Control Panel Overview ........................3 Specifications ............................4 II. WARNING ..........................4 III. SYNCHRONOUS /ASYNCHRONOUS MODE..............5 Synchronous Mode ..........................5 Asynchronous Mode ..........................5 IV. MENU OVERVIEW ......................7 Copy..............................7 Compare ............................... 7 Copy + Compare........................... -
Page 3: Introduction
Dual Source Copy + Compare, Format + Capacity Check, and Set Slow Out Threshold. The compact and light weight Flex Pro SD/Micro SD duplicator is ideal for workplaces with space limitation, like small office and retail store. With expandable design, Flex Pro can be... -
Page 4: Control Panel Overview
Use ▲or ▼ button to scroll through the options and view the operation status of each channel on the 2-line backlit LCD display. Support Synchronous and Asynchronous copy modes for best operation efficiency. Powerful 32-bit CRC checksum to assure data integrity. Heavy-duty hardware construction for commercial production and personal use. -
Page 5: Specifications
Specifications Operation Standalone (No PC or Software is required) Target 23targets (up to 239 targets by Daisy chain) Copy Speed 25 MB/s Copy Mode Synchronous and Asynchronous Copy Area Whole Media, File and System(Fast Copy) Supported Media SD/Micro SD card (SD/SDHC/SDXC) Windows：FAT16/32, exFAT, NTFS Supported File Linux：Ext2/3/4... -
Page 6: Synchronous /Asynchronous Mode
Press and hold ESC button during the execution process of a task will stop and exit the execution of the task. DO NOT unplug SD or Micro SD card from the duplicator during the execution process of a task. It may cause damage to the duplicator system and media. It is strongly recommended that the capacities of the source and target media are equal or similar. - Page 7 duplicator can asynchronously execute a task if Asynchronous Mode is enabled. Insert source device into the source channel, select the task to execute from the menu, and press ENT button. Duplicator will start to execute the task now. Target devices can be plugged in during the execution process, and will start to execute the task immediately Target device can be removed when it finishes the execution process and its green LED is solid on.
-
Page 8: Menu Overview
IV. Menu Overview 1. Copy To copy from source device to target device(s), please go to 7.1 Copy Area to select the setting first before this step. 1.Copy 1.Copy Copy：4 1100M Source Not Ready Ready device: 4 P：0 F：0 No source device Source and target devices inserted Display copy progress Copy:4: number of targets... -
Page 9: Dual Source Copy + Compare
4. Dual Source Copy + Compare Two source devices with identical content will be used for this task. One source device is inserted into source port while the other inserted into the 1 target port. Duplicator starts copy process first and reads data content from the source port; duplicator then starts compare process after copy is done, and reads data content from the 1 target port. -
Page 10: Utility
6. Utility 6.1 Measure Speed This function allows to measure the actual Read and Write speed of all devices. It will NOT alter or erase existing data on the target devices. [Utility] [# 0] Read 21.6M 6.Utility 1.Measure Speed 1sec Write 15.1M Display read/write speed [# 1] Read... -
Page 11: Media Information
6.4 Media Information This function displays the information of selected device media, such as total capacity, file format and the size of data content. [Utility] [#0] 29.8G 6.Utility 4. Media Information FAT32 20.1G Use▲▼to select device Port # Total Capacity 6.5 System Information File Format Data Size This function displays general information of the duplicator system, including controller... -
Page 12: Setup
7. Setup 7.1 Copy Area This function allows to select the area on the source device to copy onto the target devices. You may select “System and Files” to skip all the unoccupied area on the source device or “W hole Media”. By default, the copy area is set up as System and Files (default). -
Page 13: Set Type Of Format
[Asynchronous Mode] 7.Setup [Setup] 2. Asynchronous Mode Disable Use▲▼to change option [Asynchronous Mode] Enable Use▲▼to change option 7.3 Set Type of Format This function allows to set up the target device format, and the setting will be applied by Command 5. Format + Capacity Check under the main menu. The options are FAT32, exFAT, and Depends On Size. -
Page 14: Set Slow Out Threshold
[Set Capacity Thresh>] 7.Setup [Setup] 4. Set Capacity Thresh> Capacity: OFF Use▲▼to changeo ption [Set Capacity Thresh>] [Set Capacity Thresh>] Setup Complete! Tolerance: 5% 1M=1000k Use▲▼to change option Use▲▼to change option 7.5 Set Slow Out Threshold This function allows to set up read/write speed threshold for target devices. When the target device is causing the copy or compare process delay due to its lower read/write speed and the rest of the devices in the same batch have to wait for it, the Slow Out Threshold strategy will be applied as the following: the system will stop the copy or compare process for that... -
Page 15: Performance
7.6 Performance This function allows to set up the performance for Copy function based on the following modes: Speed, Balance, and Compatibility. Speed mode is to execute the Copy function at the fastest speed, but may have compatibility issue with certain brands flash media. Balance mode is to execute the Copy function at stable speed, and have less compatibility issue with certain brands flash media. -
Page 16: Lock Menu
unauthorized use. The password must be 6 characters long. This function only works with single unit operation, but not multiple units with daisy chain. [Boot Password] 7.Setup [Setup] 8. Boot Password Enable Use▲▼to change option [Boot Password] [Boot Password] Setup Complete! ==>_ _ _ _ _ _ Disable Set password after Enable... -
Page 17: Clear Setup
[Setup] [Language] 7.Setup 10. Language English Use▲▼to change option Setup Complete! 7.11 Clear Setup This function resets the duplicator back to factory default settings. Clear Parameter To > 7.Setup [Setup] 11. Clear Setup Use▲▼to change option Clear Parameter To > Setup Complete! All Parameters were>... - Page 18 it is necessary and provide with 6.5 System Info. Please follow the instructions when update firmware, and delete the firmware file after the update is done. Without the consent of the manufacturer of any behavior in spreading the firmware file is considered violation of copyright law, and the company will retain the legal recourse liability.
