5.
If your vehicle has a fixed voltage or temperature compensating alternator installed,
do not make connection to the Ignition Input Blade Terminal.
If your vehicle has a smart (variable voltage) alternator installed, the Ignition Input
Blade Terminal must be connected to the vehicle's ignition. At 12.2V ALT voltage,
the IDC25X will only operate when the vehicle's ignition is turned on (may take up
to 2 minutes to start charging). Fit a 1-2A fuse to the cable as close as possible to
the vehicle's ignition.
Consult the vehicles manufacture for type of alternator installed in your vehicle.
6.
To add 12Vdc solar panels to the system connect the solar panel positive terminal
(+) to the IDC25X solar input post (
to the Solar Panel positive (+) terminal (refer to the table below for fuse size).
NOTE: No solar controller is required with the IDC25X. If using portable
solar panels that include a solar controller, the controller will need to
be bypassed.
After the positive has been connected, connect the solar panel negative (-) terminal
to the (
) vehicle chassis ground.
Solar Panel Size
120W
160W
200W
240W
360W
7.
The LED output terminal provides about 5mA constant current output. It can power
an LED panel mount indicator without an external resistor.
This LED output terminal is not required to be wired into if you do not need an
external LED indicator. If an external LED indicator is required, connect the positive
(+) terminal of a LED Indicator to the LED input terminal (
Connect the negative terminal of the LED indicator to the vehicle chassis ground.
8.
The TEMP1 & TEMP2 input terminals are used to provide temperature compensated
battery charging. Attach the provided temperature sensing loom blade terminals
to TEMP1 & TEMP2 inputs on IDC25X, the ports are dual polarity allowing the
negative and positive to be plugged into either port. The temperature sensing loom
is provided with 5m wire, please cut the excess length to minimize voltage drops
and noise.
). Fit a fuse to the cable as close as possible
Fuse Size
15A
15A
20A
30A
50A
).
L.E.D
7
