Rotel RC-1082 Command List

Table: RC 1082 Waveform format expected:
Baud Rate Parity
19200
Table: RC 1082 expected format of a request by RS232 controller:
Start Count Device ID
0xFE 0x03 0x06
Table 1: Command List
NOTE: The values in the table below show the exact byte sequence of all requests. The device
will expect the bytes only - no spaces, no delimiter, etc. The controlling device may implement its
own method to download each command sequence. The numerical values in the first column are
Hexadecimal.
RC 1082 HEX
FE 03 06 10 00 19
FE 03 06 10 01 1A
FE 03 06 10 02 1B
FE 03 06 10 03 1C
FE 03 06 10 04 1D
FE 03 06 10 05 1E
FE 03 06 10 06 1F
FE 03 06 10 07 20
FE 03 06 10 08 21
FE 03 06 10 09 22
FE 03 06 10 0A 23
FE 03 06 10 0B 24
FE 03 06 10 0C 25
FE 03 06 10 0D 26
FE 03 06 10 0E 27
FE 03 06 10 0F 28
FE 03 06 10 10 29
FE 03 06 10 11 2A
FE 03 06 10 12 2B
FE 03 06 10 13 2C
FE 03 06 10 14 2D
FE 03 06 10 15 2E
FE 03 06 10 1A 33
RC 1082
RS232 Controller Command List
Valid Data Bits
N 8
Type Key
0x10 0xXX
Command
Power
Power Off
Power On
Phono
CD
Tuner
Aux 1
Aux 2
Aux 3
Tape 1
Tape 2
Record Phono
Record CD
Record Tuner
Record Aux 1
Record Aux 2
Record Aux 3
Record Tape 1
Record Off
Vol+
Vol-
Mute
Record Function
Stop Bit Value Handshaking
1
Checksum
0xXX
Command Description
Power Toggle
Power Off
Power On
Listen Phono
Listen CD
Listen Tuner
Listen Aux 1
Listen Aux 2
Listen Aux 3
Listen Tape 1
Listen Tape 2
Record Phono
Record CD
Record Tuner
Record Aux 1
Record Aux 2
Record Aux 3
Record Tape 1
Record Off
Volume Up
Volume Down
Mute Toggle
Record Function Select
Data Type
None String
