Rotel RC-1070 Technical Manual

T echnical
Manual
Table of Contents
Specification...................................... 1
Parts List ........................................... 2~3
Case Outlines.................................... 4
Safety Caution................................... 4
PCB Assembly .................................. 5~6
Schematic Diagram .......................... 7~10
Specification
Total Harmonic Distortion (20 Hz-20 kHz)
Intermodulation Distortion
Input Sensitivity / Impedance
Output Level/Impedance
Usable Headphone Impedance
Frequency Response
Signal to Noise Ratio (IHF "A" weighted)
Phono Overload:
Power Requirements
Power Consumption
Dimensions (W x H x D)
Weight (net)
SHINSEN-BLD. 4F 10-10 SHINSEN-CHO, SHIBUYA-KU,
TOKYO 150-0045, JAPAN
Quality Uncompromised
®
STEREO CONTROL AMPLIFIER
RC-1070
< 0.006%
< 0.006% at 1 V output (60 kHz:7 kHz, 4: 1 )
Line Level: 150 mV / 24 kOhms
Phono (MM): 1.2 mV / 68 kOhms
1 V / l00 Ohms
8 - 2,000 Ohms
Line Level : 4 Hz - 100 kHz, +0, -3dB
Phono: 20 Hz - 20 kHz, ±0.5 dB
Line Level: 95 dB
Phono: 70 dB
70 mV
USA: 115 Volts, 60 Hz
CE: 230 Volt, 50 Hz
10 Watts
430 x 92 x 344 mm
17" x3 5/8 " X 13 5/8 "
5.4 kg, 11.9 lbs.
Serial. NO.
Beginning
Y-332A-00115C/S-S
