Summary of Contents for Smithco SN FWR-001
- Page 1 Parts & Service Operators Fairway Ultra 10 Remote Hydraulics Model 12-501-A Self-Contained Hydraulics Model 12-500-A SN FWR-001 March 2015 updated May 2015 Product Support: Hwy SS & Poplar Ave; Cameron WI 54822 1-800-891-9435 productsupport@smithco.com...
-
Page 2: Table Of Contents
CONTENTS Introduction ...................1-5 Introduction .................. 1 Safe Practices ................2 Specifications ................3 Setup ..................4-5 Service ...................5-7 Maintenance ................6-7 Storage ..................8 Diagrams ..................9-13 12-501 Wiring ................9 12-500 Wiring ............... 10-11 12-500 Hydraulics ..............12 12-501 Hydraulics ..............13 Parts ...................14-27 12-500 Main Drawing .............. -
Page 3: Introduction
All Smithco machines have a Serial Number and Model Number. Both numbers are needed when ordering parts. For product and accessory information, help finding a dealer, or to register your product please contact us at www.Smithco.com. -
Page 4: Safe Practices
13. Never carry passengers. 14. Use parts and materials supplied by Smithco only. Do not modify any function or part. 15. Avoid sharp turns. Watch the tires of the tractor while turning to make sure they do not contact the drawbar of the Fairway Roller . -
Page 5: Specifications
SPECIFICATIONS FOR FAIRWAY ULTRA 10 WEIGHTS AND DIMENSIONS Length 81.5" (2.07 m) Folded Width x 147" (3.73 m) Overall Length Width 120" (3.05 m) Effective Rolling Width 125" (3.18 m) Overall Width Extended x 144" (3.66 m) Overall Length Water Weight Capacity 100 Gallons (378,5 l) Rolling Weight 2220 lbs (1007 kg) -
Page 6: Setup
SETUP ELECTRIC/HYDRAULIC LIFT SYSTEM 12-500 If you purchased a 12-500 Electric/hydraulic Lift System, it will come installed. Battery not included. If tongue is folded up, remove bracket, unfold tongue and hook up adjustment link. See Storage section for more information. 2. -
Page 7: Service
TOW VEHICLE CHARGING INSTRUCTIONS... -
Page 8: Maintenance
MAINTENANCE Before servicing or making adjustments to machine, stop engine on tow vehicle and remove key from igni- tion. Securely prop FairWay Roller on jack stands. Use all procedures and parts prescribed by the manufacturer. Before operating this machine, become familiar with all controls and functions of this unit and the tow vehicle. Also complete all maintenance requirements and read all safety warnings. - Page 9 MAINTENANCE WHEEL MOUNTING PROCEDURE 1. Set park brake on tow vehicle. Turn machine off and remove key. 2. Block one of the other wheels. 3. Loosen nuts slightly on wheel to be removed. 4. Lower unit fully to the ground until wheels lift off the ground. 5.
-
Page 10: Storage
BATTERY FOR 12-500 Batteries normally produce explosive gases which can cause personal injury. Do not allow flames, sparks or any ignited object to come near the battery. When charging or working near battery, always shield your eyes and always provide proper ventilation. -
Page 11: Diagrams
12-501 WIRING REF# PART# DESCRIPTION QUANTITY 12-558 KYB Elec/Hyd Actuator w/ Connectors 15-725 Mount Panel End 15-727 Rocker Switch, No Light 12-512 Main Wire Harness 12-501 Battery on Tow Vehicle 8975 30 AMP Breaker 8977 Red Breaker Boot... -
Page 12: 12-500 Wiring
12-500 WIRING... - Page 13 12-500 WIRING REF# PART# DESCRIPTION QUANTITY 12-558 KYB Elec/Hyd Actuator w/ Connectors 15-725 Mount Panel End 15-727 Rock Switch, No Light 15-728 Centering Switch, Momentary, On-Off-On 15-729 Mount Panel Middle 15-727 Rock Switch, No Light 12-728 Centering Switch, Momentary, On-Off-On 74-271 Power Connector 74-270...
-
Page 14: 12-500 Hydraulics
12-500 HYDRAULIC DIAGRAM REF# PART# DESCRIPTION QUANTITY 12-530 Motor Box 18-168 Straight Thread Elbow 74-229 Hose - 16" 74-230 Hose - 17" 12-546 Power Unit 12-517 Hose 12-518 Hose 18-464 Male Run Tee 12-514 Hydraulic Cylinder 12-515 Hose 12-516 Hose 12-519 Hydraulic Cylinder 42-040... -
Page 15: 12-501 Hydraulics
12-501 HYDRAULIC DIAGRAM REF# PART# DESCRIPTION QUANTITY 42-040 Yoke End 12-519 Hydraulic Cylinder 18-168 Straight Thread Elbow 12-515 Hose 12-516 Hose 12-514 Hydraulic Cylinder 74-246 Hose (to remote hydraulics) 18-464 Male Run Tee 18-467 " Street Elbow... -
Page 16: Parts
12-500-A MAIN DRAWING REF# PART# DESCRIPTION QUANTITY 78-221 Tire and Wheel 16-225-01 Tire 78-221-02 Wheel Left Roller Assembly (see Drawing) 12-530 Motor Box 74-248 Motor Box Cover 12-513 100 Gallon Tank 12-540 Tank Strap 12-542 Jack Stand 18-297 Cap Plug 12-543 Lift Relay 42-040... -
Page 17: 12-501 Main Drawing
12-501-A MAIN DRAWING REF# PART# DESCRIPTION QUANTITY 78-221 Tire and Wheel 16-225-01 Tire 78-221-02 Wheel Left Roller Assembly (see Drawing) 12-513 100 Gallon Tank 12-540 Tank Strap 12-542 Jack Stand 18-297 Cap Plug 12-543 Lift Relay 12-552 Adjustment Link 12-536 Drawbar 12-527 Switch Box... -
Page 18: 12-500 Power Box
POWER BOX DRAWING (12-500 ONLY) - Page 19 POWER BOX DRAWING (12-500 ONLY) REF# PART# DESCRIPTION QUANTITY 12-524 Knock Out Clamp 15-725 Mount Panel End 15-727 Rock Switch, No Light 15-728 Centering Switch, Momentary, On-Off-On 15-729 Mount Panel Middle 15-727 Rock Switch, No Light 15-728 Centering Switch, Momentary, On-Off-On 12-526 Switch Backing Plate 12-527...
- Page 20 DRAWBAR DRAWING...
- Page 21 DRAWBAR DRAWING REF# PART# DESCRIPTION QUANTITY 12-525 Main Frame 12-542 Jack Stand 18-297 Cap Plug HCP-34-300 Clevis Pin, HCP-100-325 Clevis Pin, 1 x 3 12-543 Lift Relay 12-552 Adjustment Link 13-652 Hose Clamp (12-501 ONLY) 12-536 Draw Bar HHP-.177 Bridge Pin, HCP-100-325 Clevis Pin, 1 x 3 HP-18-200...
- Page 22 LEFT ROLLER DRAWING...
- Page 23 LEFT ROLLER DRAWING REF# PART# DESCRIPTION QUANTITY HB-58-11-200 Bolt, - 11 x 2 HB-516-18-100 Bolt, - 18 x 1 HW-516 Washer, HNTL-516-18 Lock Nut, - 18 18-153 Bushing (come with 12-531) 75-511 Pillow Block 12-550 LH Brush Mount 12-539 Roller Drum 12-533 LH Roller Frame HMB-114-14...
-
Page 24: Right Roller
RIGHT ROLLER DRAWING... - Page 25 RIGHT ROLLER DRAWING REF# PART# DESCRIPTION QUANTITY HCP-58-250 Clevis Pin, 12-556 RH Wing Pad HB-38-16-125 Bolt, - 16 x 1 HNTL-38-16 Lock Nut, - 16 12-537 Wing Pivot Pin 12-532 RH Wing HB-58-11-300 Bolt, - 11 x 3 HNTL-58-11 Lock Nut, - 11 HNA-114-12 Axle Nut, 1...
-
Page 26: Rear Roller / Rear Axle
REAR ROLLER/ REAR AXLE DRAWING... - Page 27 REAR ROLLER / REAR AXLE DRAWING REF# PART# DESCRIPTION QUANTITY 78-221 Tire and Wheel 78-221-01 Tire 78-221-02 Wheel 30-071 30-071-01 Inner and Outter Bearing 30-071-02 Seal 12-545 Leveling Shim 4 (as needed) HCP-100-325 Clevis Pin, 1 x 3 HP-18-200 Cotter Pin, HB-12-13-175 Bolt, - 13 x 1...
-
Page 28: Tank Drawing
TANK DRAWING REF# PART# DESCRIPTION QUANTITY 12-525 Main Frame 16-960 Ball Valve, 3/4" 16-163 Close Nipple, 1 x 3/4" 12-513 100 Gallon Tank 12-554 Decal, Fairway Ultra 10 HB-516-18-175 Bolt, - 18 x 1 HW-516 Washer, HWL-516 Lock Washer, HNTL-516-18 Lock Nut, - 18 12-540... -
Page 29: Hitch Options
HITCH OPTIONS DRAWING REF# PART# DESCRIPTION QUANTITY 74-257 Hitch Pin HHP-18 Bridge Pin, Clevis (comes on machine) 78-244 78-356 2" Ball Coupling 78-245 Ball Coupling - 11 x 4 (comes on machine) HB-58-11-400 Bolt, HNCL-58-11 Center Lock Nut, - 11 (comes on machine) -
Page 30: Reference
12-779 Decal, On/Off B 12-522 Decal, Control Box Bottom C 12-554 Decal, Fairway Ultra 10 D 25-277 Decal, Battery Warning E 25-286 Decal, Pinch Points F 25-357 Decal, Smithco G 34-147 Decal, Smithco Star H 25-355 Decal, Tire Pressure, 18psi... - Page 31 NOTES...
-
Page 32: Quick Reference Replacement Parts
QUICK REFERENCE Battery (not supplied) Automotive type 24F-12 Volt Hydraulic Fluid 1.50 Gal (5.68 liter) MileMaster 303 Tractor HYD Fluid or equivilent 12-519-P Hydraulic Cylinder 15-519-01P Sea lKit 15-514-P Hydraulic Cylinder 15-514-01P Seal Kit... - Page 33 30 days from discovery of the condition. If you need help locating an Authorized Smithco Distributor, or if you have questions regarding your warranty rights or responsibilities, you may contact us at: Smithco Product Support Department 200 West Poplar Ave.
- Page 34 This warranty does not apply to normal “wear and tear” items. Normal “Wear and Tear” includes, but is not limited to, damage to seats due to wear or abrasion, worn painted surfaces, scratched decals or windows, etc. Smithco may require the return of failed parts or components in order to determine the validity of any warranty claim.
