Remote Control - Dimplex Optimyst 3STEP-RGB-EU Operating Instructions Manual

REMOTE CONTROL

Display Screen
1
'Menu' Button
2
'Back' Button
3
'Advance' Button(ADV)
4
'Up and Down' Arrows
5
'Enter' Button (Press to
6
Activate the Remote)
TO FIT THE BATTERIES
The remote control is supplied with 2xAA batteries in a bag. Lift off the battery cover on the back of the remote control
and insert the batteries taking note of the polarity.
Batteries must be recycled or disposed of properly.
Check with your Local Authority or Retailer for recycling advice in your area .
Frequency band(s) this product operates in: 2.4GHz
Maximum radio-frequency power transmitter in the frequency band(s) this product operates in:
PAIRING THE REMOTE CONTROL
The remote control has already been paired to your product during factory assembly. In the unlikely event that the
remote control disconnects from the product, or you obtain a spare remote control, you will need to complete the pairing
process:
1.
Open the drawer and press the rocker switch to the on (I) position. You should hear an audible beep.
2.
Press and hold 'Button 6' until PAIR appears on the display
3.
Bring the remote control close to the product where the receiver is . See Fig 3C
4.
The product will start to beep and blink
5.
Press 'Button 6' to complete the pairing process. The product will go into standby mode.
GETTING THE DESIRED FLAME EFFECT
1.
Switch the appliance on by pressing the main switch to the on position.
2.
Activate the remote by pressing the ENTER button. With the remote activated,
navigate UP button to flash
between F1 and F6. F1 being the lowest setting and F6 being the highest setting.
3.
Alternatively if using the Manual controls, Press the
and buttons to adjust the flame to your desired level. Please give the flame generator time to react to the changes
you make.
Once you have made your adjustments to both the flame height and crackling sound, the appliance will keep these
settings even if you power off the appliance by either the on/standby button or by the main switch. The next time you
switch on the appliance, it will start up as normal, wait 45 seconds for the flames to start and then revert to the adjust-
ed settings.
1
2
3
6
and press ENTER. The current setting will be displayed. Press
7
button. The flames will start after 45seconds. Press the
4
5
2.71dBm
on the display will be flashing,
or to toggle
